Teltonika RUTM09, Router, WWAN 3-port switch, 1GbE, PPP, 3G, 4G, DIN rail mountable, surface-mountable, wall-mountable
$617.33 inc GST
✓ In Stock - 30 available
✓ Free NZ Delivery
30 in stock
Ships from: Christchurch
- Allow 2–3 days for delivery to the North Island
- Allow 1–2 days for delivery to the South Island
- Add 1–2 days if you are rural
- Collection can be arranged
Description
The Teltonika RUTM09 is designed for modern connectivity needs, featuring built-in GPS, GLONASS, Galileo, and QZSS for precise location tracking. This robust router operates in extreme conditions, with a temperature range of -40°C to 75°C and supports up to 90% humidity. With advanced security protocols and multiple networking capabilities, it ensures reliable communication across various applications. The 16 MB flash memory and ample connectivity options, including LTE CAT6 for mobile broadband, provide flexibility and performance for businesses and IoT integrations. Features like load balancing, Quality of Service (QoS), and mobile quota control make it a suitable choice for efficient networking solutions, while the compact design allows for easy placement in any workspace.
- Temperature resilience from -40°C to 75°C
- Built-in GPS and multiple wireless connectivity options
- Supports various network protocols for versatile performance
- Enhanced security with multiple encryption methods
- Compact design with extensive expandability options
- Versatile connectivity options
The Teltonika RUTM09 is equipped with various connectivity technologies, including LTE, WAN, LAN, and USB ports. This allows for flexible integration into existing networks while ensuring robust performance for different communication types. - Robust performance in extreme environments
With a minimum operating temperature of -40°C and a maximum of 75°C, the device ensures reliable operation even in harsh conditions. This makes it suitable for use in diverse locations and industries. - Advanced security features
The router offers multiple encryption algorithms and authentication methods, ensuring data protection and secure remote management. This includes support for WPA3 and VPN capabilities, solidifying its role in secure network environments. - Efficiency through load balancing
Load balancing enhances network performance by distributing traffic evenly across connections. This feature optimizes data transfer rates and ensures reliable service, especially in high-demand scenarios. - Built-in GPS tracking
The integration of GPS, GLONASS, Galileo, and QZSS provides precise location tracking, making the RUTM09 suitable for fleet management and other location-dependent applications.
What’s in the Box
- Teltonika RUTM09
- Network cable – 1.5 m
- Antenna cable – 3 m
- External power adapter, GNSS aerial, 2 x LTE aerials, SIM card adapter kit, power adapter
Main Specifications
Product Description | Teltonika RUTM09 – router – WWAN – 3G, 4G – DIN rail mountable, surface-mountable, wall-mountable |
Device Type | Router – wireless cellular modem – 3-port switch (integrated) |
Enclosure Type | DIN rail mountable, surface-mountable, wall-mountable |
Mobile Communication Protocol | LTE CAT6 |
Generation | 3G, 4G |
WAN Ports Qty | 1 |
Data Link Protocol | Ethernet, Fast Ethernet, Gigabit Ethernet, PPP |
Network / Transport Protocol | TCP, UDP, IPv4, IPv6, NTP, DNS, HTTP, HTTPs, FTP, SMTP, ARP, PPPoE, DHCP, Telnet |
Routing Protocol | BGP, OSPFv2, RIP-1, RIP-2, EIGRP, NHRP, VRRP, PPPoE, VXLAN, VRF |
Platform | Clouds of Things, ThingWorx, Cumulocity, Azure IoT Hub |
Remote Management Protocol | ICMP, DNS, HTTP, HTTPS, TLS, SSH, DHCP, Telnet, SMPP, SNMP, MQTT |
VoIP Protocols | SIP, H.323 |
Features | Aluminium housing, 3GPP Release 12, reset button, black list, white list, USSD support, SIM idle protection service, auto APN, static routing, dynamic routing, policy based routing, PPP, UPnP, WOL, connection monitoring, QoS, SQM, load balancing, Hotspot Access Point Capability, SSHFS support, traffic management, PSK, digital certificates, DDoS Protection, VLAN support, mobile quota control, Web Filtering, SSL certificate generation, GRE tunneling, DMVPN, SSTP client instance support, VPN client, VPN Server, Tailscale encryption, DLMS support, API support, SIM switching, SIM PIN management, band management, VRF, network backup, Auto MDIX, OpenVPN encryption, port forwarding, Tinc encryption, WireGuard, ZeroTier VPN client support, FOTA, Teltonika RMS, TR-069 Remote Management |
Compliant Standards | IEEE 802.3, IEEE 802.3u, IEEE 802.3az |
Dimensions (WxDxH) | 11.5 cm x 9.51 cm x 4.42 cm |
Weight | 457 g |
Extended Specifications
General
Flash Memory | 16 MB |
|---|
Aerial
Antenna Qty | 3 |
|---|
Environmental Parameters
Min Operating Temperature | -40 °C |
|---|---|
Max Operating Temperature | 75 °C |
Dimensions & Weight
Width | 11.5 cm |
|---|
Internet of Things (IoT)
Internet of Things (IoT) Compatible | Yes |
|---|
Dimensions & Weight
Weight | 457 g |
|---|
Communications
Max Transfer Rate | 300 Mbps |
|---|---|
Type | Wireless cellular modem |
General
Data Link Protocol | Ethernet, Fast Ethernet, Gigabit Ethernet, PPP |
|---|
Aerial
Aerial | External detachable |
|---|
Dimensions & Weight
Height | 4.42 cm |
|---|
General
Connectivity Technology | Wired |
|---|---|
RAM | 256 MB DDR3 SDRAM |
Environmental Parameters
Humidity Range Operating | 10 – 90% (non-condensing) |
|---|
General
Device Type | Router – 3-port switch (integrated) |
|---|
Communications
Generation | 3G, 4G |
|---|
Dimensions & Weight
Depth | 9.51 cm |
|---|
Power
Power Device | External power adapter – 18 Watt |
|---|
Software / System Requirements
OS Provided | RutOS |
|---|
Expansion / Connectivity
Expansion Slots | 2 (total) / 2 (free) x Mini-SIM |
|---|
Aerial
Configuration Details | 2 detachable external LTE aerials, 1 detachable GPS aerial |
|---|
Internet of Things (IoT)
Platform | Clouds of Things, ThingWorx, Cumulocity, Azure IoT Hub |
|---|
Communications
Mobile Communication Protocol | LTE CAT6 |
|---|
IP Telephony
VoIP Protocols | SIP, H.323 |
|---|
General
Enclosure Type | DIN rail mountable, surface-mountable, wall-mountable |
|---|---|
Processor | MediaTek MIPS 1004Kc 880 MHz |
Routing Protocol | BGP, OSPFv2, RIP-1, RIP-2, EIGRP, NHRP, VRRP, PPPoE, VXLAN, VRF |
Built-in Devices | Beidou, GPS, Galileo, QZSS, GLONASS |
Miscellaneous
Cables Included | 1 x network cable – 1.5 m 1 x antenna cable – 3 m |
|---|
General
Authentication Method | RADIUS, TACACS+, X.509 certificates |
|---|---|
Network / Transport Protocol | TCP, UDP, IPv4, IPv6, NTP, DNS, HTTP, HTTPs, FTP, SMTP, ARP, PPPoE, DHCP, Telnet |
Remote Management Protocol | ICMP, DNS, HTTP, HTTPS, TLS, SSH, DHCP, Telnet, SMPP, SNMP, MQTT |
Encryption Algorithm | MODBUS, SSL, 128-bit AES, 128-bit AES-GCM, 192-bit AES, 256-bit AES, 3DES, AES-OFB, DES, TLS, IKE, IKEv2 |
Features | Aluminium housing, 3GPP Release 12, reset button, black list, white list, USSD support, SIM idle protection service, auto APN, static routing, dynamic routing, policy based routing, PPP, UPnP, WOL, connection monitoring, QoS, SQM, load balancing, Hotspot Access Point Capability, SSHFS support, traffic management, PSK, digital certificates, DDoS Protection, VLAN support, mobile quota control, Web Filtering, SSL certificate generation, GRE tunneling, DMVPN, SSTP client instance support, VPN client, VPN Server, Tailscale encryption, DLMS support, API support, SIM switching, SIM PIN management, band management, VRF, network backup, Auto MDIX, OpenVPN encryption, port forwarding, Tinc encryption, WireGuard, ZeroTier VPN client support, FOTA, Teltonika RMS, TR-069 Remote Management |
Compliant Standards | IEEE 802.3, IEEE 802.3u, IEEE 802.3az, IP30, UKCA, RCM, CB, EN 55032:2015+A11:2020+A1:2020, EN 55035:2017 + A11:2020, EN 61000-3-3:2013 + A1:2019 + A2:2021, EN IEC 61000-3-2:2019+A1:2021, EN 61000-4-2:2009, EN IEC 61000-4-3:2020, EN 61000-4-4:2012, EN 61000-4-5:2014+A1:2017, EN 61000-4-6:2014, EN IEC 61000-4-11:2020, EN 301 908-1 V13.1.1, EN 301 908-2 V13.1.1, EN 301 908-13 V13.1.1, EN 303 413 V1.2.1, EN IEC 62368-1:2020 + A11:2020, EN IEC 62311:2020, AS/NZS 62368.1:2022, IEC 62368-1:2018 |
Status Indicators | WAN, LAN, signal strength, power, mobile network type |
Expansion / Connectivity
Interfaces | WAN: 1 x 10/100/1G Ethernet – RJ-45 LAN: 3 x 10/100/1G Ethernet – RJ-45 Antenna: 2 x SMA – LTE Antenna: 1 x SMA – GNSS aerial USB 2.0: 1 x Type A 1 x DI 1 x DO |
|---|
Miscellaneous
Included Accessories | GNSS aerial, power adapter, SIM card adapter kit, 2 x LTE aerials |
|---|
