Description
The DNR-F4432-16P is a standalone wired network video recorder (NVR) which supports multichannel network cameras with H.265 and H.264 recording and four high-speed SATA hard disks for backup. Thanks to a powerful embedded system, the NVR can record video from network cameras located in local or remote sites into a dedicated HDD storage without having to turn on a PC. The DNR-F4432-16P NVR supports real-time monitoring and playback from everywhere via browser, HDMI or VGA port. The triplex function enables the device to continue recording while simultaneously allowing the user to watch the live view and search for playback videos. Complete video management, display and playback capabilities make the DNR-F4432-16P a convenient and stable asset to your network.
- Automated surveillance
- Extensive monitoring and recording features
- Smooth streaming from anywhere
- Automated surveillance
Users are provided with a variety of options for viewing live streams and camera footage on-screen as well as automatically recording events as they happen, with or without an operator on-site. Event-based recording is available for cameras with motion detection and alarm-in connections are supported for triggers such as door and window sensors for automated recording during unusual events. User-defined scheduled recording and continuous recording with automatic overwriting options help ensure the surveillance system is running reliably, even when no one is around. - Extensive monitoring and recording features
The DNR-F4432-16P’s intuitive interface allows for easy configuration of many functions, including compression, resolution, and frame rate for all connected Xameras. Support for multiple encoding formats provides administrators the flexibility to prioritize storage space and video quality. Featuring live viewing of multiple channels, users can simply drag and drop selected Cameras to the viewing area. A single camera may be viewed full-screen with two-way audio support. Advanced search features including calendar filters help administrators quickly find the specific footage they need. - Smooth streaming from anywhere
The DNR-F4432-16P also enables users to remotely view and manage the NVR from anywhere via a web browser. The Gigabit Ethernet port provides superior bandwidth for viewing 32 camera streams simultaneously, so critical moments can be monitored and captured at all times.
Main Specifications
Product Description | D-Link DNR-F4432-16P – standalone NVR – 32 channels |
Device Type | NVR – 32 channels – networked – rack-mountable |
Compression Format | G.711, H.264, AAC, H.265 |
Image Resolution | 1280×720, 1920×1080, 3840×2160 |
Hard Drive(s) Supported | Quantity: 4 – total capacity: 48 TB |
Voltage | 100 – 240 V |
Dimensions (WxDxH) | 44 cm 7 cm |
Weight | 4.65 kg |
Extended Specifications
General
Device Type | NVR – rack-mountable |
|---|
Video Channels | 32 |
|---|
Image Resolution | 1280×720, 1920×1080, 3840×2160 |
|---|
Compression Format | G.711, H.264, AAC, H.265 |
|---|
Package Content | Mounting kit |
|---|
Software Included (Y) | Drivers & Utilities |
|---|
Compliant Standards | Plug and Play, FCC, RCM, IEEE 802.3af, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3x |
|---|
Security DVR
Display Modes | Live view |
|---|
Playback Search | Smart search |
|---|
Record Events | Motion detection, scheduled, event, manual, continuous, face detection |
|---|
Networked | Yes |
|---|
Features | RAID 5 support, RAID 10 support, RAID 6 support, Pan/Tilt/Zoom support, Al detection, 320 Mbps date rate recording |
|---|
Hard Drive
Quantity Supported | 4 |
|---|
Interface | Serial ATA |
|---|
Supported Max Total Capacity | 48 TB |
|---|
Networking
Network Interfaces | Ethernet 10Base-T/100Base-TX/1000Base-T |
|---|
Supported Protocols | DDNS, DHCP, DNS, HTTP, NTP, SMTP, TCP/IP, UDP/IP, ARP, ICMP, SNMP 1, SNMP 2c, SNMP 3, RTSP, RTP, HTTPS, IPv4, RTCP |
|---|
Features | Power over Ethernet (PoE), auto-uplink (auto MDI/MDI-X), DHCP server, DHCP client, ONVIF support, DynDNS, web GUI management portal, LED status indicators, 160W PoE power budget |
|---|
Connections
Video Input Ports | RJ-45 x 16 |
|---|
Video Output Ports | HDMI x 1, VGA x 1 |
|---|
Audio Input Ports | Mini-phone 3.5 mm x 1 |
|---|
Audio Output Ports | Mini-phone 3.5 mm x 1 |
|---|
Alarm Ports | Alarm input x 2, alarm output x 2 |
|---|
Network Port | 10/100/1000Base-T |
|---|
Other Ports | USB 2.0 x 2, eSATA x 1, USB 3.0 x 1 |
|---|
Power
Voltage | 100 – 240 V |
|---|
Frequency | 50/60 Hz |
|---|
Power Consumption | 160 Watt |
|---|
Dimensions & Weight
Width | 44 cm |
|---|
Height | 7 cm |
|---|
Weight | 4.65 kg |
|---|
Environmental Parameters
Min Operating Temperature | 0 °C |
|---|
Max Operating Temperature | 50 °C |
|---|
Humidity Range Operating | Up to 90% (non-condensing) |
|---|
