Gigabyte B650EM FORCE WIFI6E, Motherboard, micro ATX, Socket AM5, AMD B650 Chipset, USB 3.2 Gen 2, USB 3.2 Gen 1, USB-C 3.2 Gen 1, 2.5 Gigabit LAN, Wi-Fi 6E, Bluetooth, onboard graphics (CPU required), HD Audio (8-channel)
$225.47 inc GST
✓ In Stock - 59 available
✓ Free NZ Delivery
59 in stock
Ships from: Auckland or Christchurch
- Allow 1–2 days for delivery
- Add 1–2 days if you are rural
- No collections
Description
GIGABYTE B650EM FORCE WIFI6E is a micro ATX motherboard designed for builders who want a compact platform for modern Ryzen processors. It supports Ryzen 7000, 8000, and 9000 Series CPUs and delivers a balance of performance and expandability with DDR5 dual-channel memory support, PCIe 5.0 expansion, and multiple M.2 storage options. The board helps maintain fast, reliable network connections with integrated 2.5 Gigabit Ethernet and Wi‑Fi 6E with Bluetooth 5.3, while a broad set of USB and display outputs supports common peripherals and external displays.
The design focuses on convenience and system longevity with features such as an 8+2+2 phase power design, pre-mounted I/O shield, Q-Flash Plus, and GIGABYTE Smart Fan 6 for thermal control. Storage flexibility comes from three M.2 slots plus four SATA ports with RAID support, and the board includes user-friendly hardware like PCIe EZ Latch and WIFI EZ-Plug to simplify installation and upgrades.
- Supports Ryzen 7000, 8000, and 9000 Series processors for modern performance
- DDR5 dual-channel memory support with AMD EXPO and XMP compatibility
- Integrated 2.5 Gigabit Ethernet and MediaTek Wi‑Fi 6E with Bluetooth 5.3 for versatile networking
- Three M.2 slots and four SATA ports with RAID support for flexible storage configurations
- Versatile connectivity
A broad assortment of rear and internal ports, including USB 3.2 Gen 2, USB-C, HDMI, DisplayPort, and multiple USB headers, makes it easy to connect displays, peripherals, and accessories. - Efficient power delivery
An 8+2+2 phase power design provides stable power to the CPU and components to support sustained workloads and overclocking headroom. - Robust storage support
Three 2280 M.2 slots plus four SATA-600 ports and RAID options enable high-speed NVMe storage alongside ample capacity for large data libraries. - Reliable networking
Onboard 2.5 Gigabit Ethernet and MediaTek Wi‑Fi 6E deliver faster wired and wireless connectivity for gaming, streaming, and large file transfers. - Builder-friendly design
Features such as a pre-mounted I/O shield, PCIe EZ Latch, WIFI EZ-Plug, and Q-Flash Plus simplify installation, upgrades, and BIOS recovery.
Main Specifications
Product Description | Gigabyte B650EM FORCE WIFI6E – motherboard – micro ATX – Socket AM5 – AMD B650 |
Product Type | Motherboard – micro ATX |
Chipset Type | AMD B650 |
Processor Socket | 1 x Socket AM5 |
Compatible Processors | Ryzen (supports Ryzen 7000/8000/9000 Series) |
RAM Supported | 2 DIMM slots – DDR5, non-ECC, unbuffered |
Storage Ports | 4 x SATA-600 (RAID), 3 x M.2 |
USB / FireWire Ports | 1 x USB 3.2 Gen 2 + 1 x USB-C 3.2 Gen 1 + 2 x USB 3.2 Gen 1 + 2 x USB 2.0 + (1 x USB-C 3.2 Gen 1 + 2 x USB 3.2 Gen 1 + 4 x USB 2.0 via headers) |
Audio | HD Audio (8-channel) |
LAN | 2.5 Gigabit Ethernet, 802.11a/b/g/n/ac/ax (Wi-Fi 6E), Bluetooth 5.3 |
Extended Specifications
General
Product Type | Motherboard – micro ATX |
|---|---|
Chipset Type | AMD B650 |
Processor Socket | Socket AM5 |
Max Processors Qty | 1 |
Compatible Processors | Ryzen (supports Ryzen 7000/8000/9000 Series) |
Supported RAM
Technology | DDR5 |
|---|---|
Bus Clock | 4400 MT/s, 4800 MT/s, 5200 MT/s, 5600 MT/s (O.C.), 6000 MT/s (O.C.), 6200 MT/s (O.C.), 6400 MT/s (O.C.), 6600 MT/s (O.C.), 6666 MT/s (O.C.), 6800 MT/s (O.C.), 7000 MT/s (O.C.), 7200 MT/s (O.C.), 7600 MT/s (O.C.), 7800 MT/s (O.C.), 8000 MT/s (O.C.), 8200 MT/s (O.C.), 8400 MT/s (O.C.), 8600 MT/s (O.C.), 8800 MT/s (O.C.), 9200 MT/s (O.C.), 9600 MT/s (O.C.) |
Supported RAM Integrity Check | Non-ECC |
Registered or Buffered | Unbuffered |
Features | Dual channel memory architecture, AMD EXPO technology, Intel Extreme Memory Profiles (XMP) |
Audio
Type | HD Audio (8-channel) |
|---|---|
Compliant Standards | High Definition Audio |
LAN
Network Controller | MediaTek Wi-Fi 6E MT7902 |
|---|---|
Network Interfaces | 2.5 Gigabit Ethernet, 802.11a/b/g/n/ac/ax (Wi-Fi 6E), Bluetooth 5.3 |
Expansion / Connectivity
Expansion Slots | 1 x CPU 2 x DIMM 288-pin 1 x PCIe 5.0 x16 1 x PCIe 4.0 x16 (x4 mode) 3 x M.2 socket (2280 M.2 Key M slot) |
|---|---|
Storage Interfaces | SATA-600 -connectors: 4 x 7pin Serial ATA – RAID 0 / RAID 1 / RAID 10 PCIe 4.0 -connectors: 2 x M.2 – RAID 0 / RAID 1 / RAID 10 / RAID 5 PCIe 5.0 -connectors: 1 x M.2 – RAID 0 / RAID 1 / RAID 10 / RAID 5 |
Interfaces | 1 x HDMI 1 x DisplayPort 1 x audio line-out – mini-jack 1 x microphone – mini-jack 1 x audio line-in – mini-jack 1 x USB 3.2 Gen 2 2 x USB 3.2 Gen 1 1 x USB-C 3.2 Gen 1 2 x USB 2.0 2 x aerial 1 x LAN (2.5Gigabit Ethernet) 1 x PS/2 keyboard / mouse |
Internal Interfaces | 4 x USB 2.0 – header 2 x USB 3.2 Gen 1 – header 1 x USB-C 3.2 Gen 1 – header 1 x audio – header 1 x SPI – header |
Power Connectors | 24-pin main power connector, 8-pin ATX12V connector |
Features
BIOS Type | AMI |
|---|---|
BIOS Features | UEFI BIOS, PnP 1.0a support, DMI 2.7 support, WfM 2.0 support, SMBIOS 2.7 support, ACPI 5.0 support |
Hardware Monitoring | Fan fail warning, fan control, fan speed detection, temperature detection, water cooling flow rate, system voltage |
Hardware Features | 8+2+2 Phase Power Design, Ultra Durable, DIY Friendly Design, GIGABYTE Smart Fan 6, RGB FUSION, pre-mounted I/O shield, PCIe EZ Latch, WIFI EZ-Plug, Q-Flash Plus |
Miscellaneous
Software Included | Norton Internet Security (OEM Version) |
|---|---|
Width | 24.4 cm |
Depth | 24.4 cm |
