ASUS X870 MAX GAMING WIFI7, Motherboard, ATX, Socket AM5, AMD X870 Chipset, USB4, USB-C 3.2 Gen 2x2, USB 3.2 Gen 2, USB 3.2 Gen 1, Wi-Fi 7, 2.5 Gigabit LAN, Bluetooth, onboard graphics (CPU required), HD Audio (8-channel)
$454.76 inc GST
✓ In Stock - 50 available
✓ Free NZ Delivery
50 in stock
Ships from: Auckland or Christchurch
- Allow 1–2 days for delivery
- Add 1–2 days if you are rural
- No collections
Description
The ASUS X870 MAX GAMING WIFI7 motherboard offers a robust foundation for gaming and computing performance. Equipped with support for Ryzen 7000/8000/9000 Series processors, this motherboard utilizes the AMD X870 chipset and provides an array of features that ensure fast data processing and an enhanced user experience. With support for DDR5 RAM running up to 4000 MHz, users can enjoy faster load times and better multitasking capabilities.
Connectivity is optimized with a range of high-speed options, including multiple USB ports, 2.5 Gigabit Ethernet, and Wi-Fi 7 technology. For gamers and professionals seeking reliability, this motherboard includes features such as ASUS Q-Design for easy installation, extensive thermal management options, and ASUS Aura Sync for customizable RGB lighting. Whether building a new system or upgrading an existing setup, the X870 MAX GAMING WIFI7 offers the necessary tools to achieve high performance in any computing task.
- Supports Ryzen 7000/8000/9000 Series processors
- Equipped with the AMD X870 chipset for efficient processing
- DDR5 RAM support with speeds up to 4000 MHz
- Comprehensive connectivity with USB 3.2 and Wi-Fi 7 capabilities
- Includes advanced cooling and protection features for durability
- Processor Support
Compatible with Ryzen 7000/8000/9000 Series processors, ensuring optimal performance for gaming and demanding applications. - Expansion Options
Features various expansion slots including 4 PCIe slots and M.2 connectors for increased storage and graphics capabilities. - High-Speed Connectivity
Offers USB 3.2 Gen 2, USB-C, and 2.5 Gigabit Ethernet for rapid data transfers and network access. - Thermal Management
Includes features like a dedicated heatsink design and M.2 heatsink to prevent overheating and maintain performance. - Customizable Lighting
ASUS Aura Sync compatibility allows for personalized RGB lighting setups that enhance the aesthetic of any build.
What’s in the Box
- ASUS X870 MAX GAMING WIFI7
- 2 x Serial ATA cable
- 1 x M.2 rubber package, M.2 screw package, ASUS Wi-Fi Q-antenna
- Software
Main Specifications
Product Description | ASUS X870 MAX GAMING WIFI7 – motherboard – ATX – Socket AM5 – AMD X870 |
Product Type | Motherboard – ATX |
Chipset Type | AMD X870 |
Processor Socket | 1 x Socket AM5 |
Compatible Processors | Ryzen (supports Ryzen 7000/8000/9000 Series) |
Max RAM Size | 256 GB |
RAM Supported | 4 DIMM slots – DDR5, on-die ECC, non-ECC, ECC, unbuffered |
Storage Ports | 4 x SATA-600 (RAID), 3 x M.2 |
USB / FireWire Ports | 2 x USB4 + 1 x USB 3.2 Gen 2 + 3 x USB 3.2 Gen 1 + 4 x USB 2.0 + (1 x USB-C 3.2 Gen 2×2 + 2 x USB 3.2 Gen 1 + 4 x USB 2.0 via headers) |
Audio | HD Audio (8-channel) |
LAN | 802.11a/b/g/n/ac/ax/be (Wi-Fi 7), 2.5 Gigabit Ethernet, Bluetooth 5.4 |
Extended Specifications
General
Product Type | Motherboard – ATX |
|---|---|
Chipset Type | AMD X870 |
Processor Socket | Socket AM5 |
Max Processors Qty | 1 |
Compatible Processors | Ryzen (supports Ryzen 7000/8000/9000 Series) |
Supported RAM
Max Size | 256 GB |
|---|---|
Technology | DDR5 |
Bus Clock | 8000 MT/s (O.C.) |
Supported RAM Integrity Check | On-die ECC, non-ECC, ECC |
Registered or Buffered | Unbuffered |
Features | Dual channel memory architecture, AMD EXPO technology |
Audio
Type | HD Audio (8-channel) |
|---|---|
Compliant Standards | High Definition Audio |
LAN
Network Interfaces | 802.11a/b/g/n/ac/ax/be (Wi-Fi 7), 2.5 Gigabit Ethernet, Bluetooth 5.4 |
|---|
Expansion / Connectivity
Expansion Slots | 1 x CPU 4 x DIMM 288-pin 1 x PCIe 5.0 x16 2 x PCIe 4.0 x16 (x1 mode) 1 x PCIe 3.0 x16 (x1 mode) 2 x M.2 socket (2280 M.2 slot) M.2 socket (2242/2260/2280 M.2 Key M slot) |
|---|---|
Storage Interfaces | SATA-600 -connectors: 4 x 7pin Serial ATA – RAID 0 / RAID 1 / RAID 10 / RAID 5 PCIe 5.0 -connectors: 1 x M.2 PCIe 4.0 -connectors: 2 x M.2 |
RAID Features | AMD RAID Xpert2 Technology |
Interfaces | 1 x HDMI 1 x LAN (2.5Gigabit Ethernet) 1 x audio line-in – mini-jack 1 x microphone – mini-jack 1 x audio line-out – mini-jack |
Internal Interfaces | 1 x USB-C 3.2 Gen 2×2 – header 2 x USB 3.2 Gen 1 – header 4 x USB 2.0 – header 1 x serial – header 1 x audio – header 1 x SPDIF out – header 1 x SPI – header |
Power Connectors | 24-pin main power connector, 2 x 8-pin ATX12V connectors |
Features
BIOS Type | AMI |
|---|---|
BIOS Features | UEFI BIOS, ASUS EZ Flash 3, ASUS UEFI BIOS EZ Mode |
Sleep / Wake Up | Wake on LAN (WOL), wake on PME |
Hardware Features | ASUS Enhanced Memory Profile (AEMP), 12+2+1 Phase Power Design, CrashFree BIOS 3, Preboot eXecution Environment (PXE), TUF LANGuard, BIOS FlashBack button, ASUS Aura Sync, ASUS DIGI+ VRM, ASUS EZ DIY, ASUS Overvoltage Protection, ASUS ProCool, ASUS Q-Design, ASUS SafeDIMM, ASUS SafeSlot, ASUS Stainless Steel Back I/O, ASUS TUF Protection, BIOS FlashBack LED, ESD Guards, M.2 heatsink, M.2 Q-Latch, PCIe Slot Q-Release, pre-mounted I/O shield, Q-Antenna, Q-Dashboard, Q-DIMM, Q-LED, Q-Slot, VRM heatsink design, 16+2+1 Phase Power Design, AI Overclocking, AI Cooling II, AI Networking II, chipset heatsink, AMD Precision Boost Overdrive (PBO), 8 Layer PCB |
Miscellaneous
Included Accessories | ASUS Wi-Fi Q-antenna, 1 x M.2 rubber package, M.2 screw package |
|---|---|
Cables Included | 2 x Serial ATA cable |
Software Included | Armoury Crate, ASUS AURA Creator, ASUS DriverHub, ASUS Fan Xpert 4, ASUS GlideX, ASUS TUF GAMING CPU-Z, DTS Audio Processing, Norton 360 for Gamers (60 days trial), TurboV Core, USB Wattage Watcher, WinRAR (40 days trial) |
Width | 30.5 cm |
Depth | 24.4 cm |
