Description
The HPE ProLiant ML350 Gen12 is a reliable server designed to support a wide range of business applications. With its tower form factor, it is ideal for offices with limited space while providing ample power and performance. The server is equipped with an Intel Xeon processor, ensuring capable processing power for demanding tasks. Featuring hot-swap storage bays and expansion slots, it offers flexibility and ease of maintenance for growing businesses. This server operates within a balanced environmental range, making it adaptable in various conditions. It is compliant with several standards such as ASHRAE and Redfish API, ensuring it meets operational and security requirements. The built-in Trusted Platform Module (TPM 2.0) enhances security, safeguarding sensitive information while enabling robust management via the Integrated Lights-Out 7 controller. The HPE ProLiant ML350 Gen12 combines performance, scalability, and dependability for businesses.
- Intel Xeon processor for efficient performance
- Hot-swap storage bays enhance flexibility
- Expanded memory capacity with DDR5 SDRAM support
- Integrated security features to protect data
- Robust management capabilities via Integrated Lights-Out 7
- Flexible storage options
The HPE ProLiant ML350 Gen12 features hot-swap storage bays, allowing users to replace drives without powering down the system, ensuring minimal downtime and operational efficiency. - Robust memory support
With support for up to 32 slots of DDR5 SDRAM, this server provides substantial memory capabilities, catering to applications that require high bandwidth and quick data access. - Advanced security measures
Equipped with a Trusted Platform Module (TPM 2.0), the server enhances data security by providing hardware-based protection against unauthorized access. - Comprehensive expansion capabilities
The server includes various expansion slots, allowing for the addition of components like network cards or storage controllers, paving the way for tailored configurations according to specific business needs. - Efficient thermal management
Operating within a temperature range of 10 °C to 35 °C, the server is designed to maintain optimal functioning conditions while supporting a wide array of environmental operating scenarios.
What’s in the Box
- HPE ProLiant Compute ML350 Gen12
- 3 standard fans
Main Specifications
Product Description | HPE ProLiant Compute ML350 Gen12 – tower Xeon 6505P 2.2 GHz – 32 GB – HDD 2 x 4 TB |
Type | Server – tower |
Height (Rack Units) | 4U |
Server Scalability | 2-way |
Processor | 1 x Intel Xeon 6505P / 2.2 GHz (up to 4.1 GHz, (12-core) |
Processor Main Features | Intel Turbo Boost Technology 2, Hyper-Threading Technology, 24 Threads, 150W TDP |
Cache Memory | 48 MB L3 Cache |
Cache Per Processor | 48 MB |
RAM | 32 GB (installed) / 8 TB (max) – DDR5 SDRAM |
Storage Controller | RAID (Serial ATA-600 / SAS 3.0 / PCI Express (NVMe)) – OCP 3.0 (HPE MR408i-o Gen11 SPDM) |
Server Storage Bays | Hot-swap 2.5″ |
Hard Drive | 2 x HDD 4 TB |
Optical Storage | No optical drive |
Video Memory | 16 MB |
Power Redundancy | Yes |
Software Included | HPE iLO Standard with Intelligent Provisioning, HPE OneView Standard (free download), HPE Compute Ops Management (subscription included) |
Dimensions (WxDxH) | 17.4 cm x 71.2 cm x 46.2 cm |
Weight | 23.96 kg |
Documents
Extended Specifications
General
Type | Server |
|---|
Product Form Factor | Tower – 4U |
|---|
Built-in Devices | Led panel |
|---|
Embedded Security | Trusted Platform Module (TPM 2.0) Security Chip |
|---|
Server Scalability | 2-way |
|---|
Hot-Swap Bays Qty | 8 |
|---|
Processor / Chipset
CPU | Intel Xeon 6505P |
|---|
Clock Speed | 2.2 GHz |
|---|
Max Turbo Speed | 4.1 GHz |
|---|
Number of Cores | 12-core |
|---|
CPU Qty | 1 |
|---|
Max CPU Qty | 2 |
|---|
CPU Upgradability | Upgradable |
|---|
Processor Main Features | Intel Turbo Boost Technology 2, Hyper-Threading Technology, 24 Threads, 150W TDP |
|---|
Cache Memory
Installed Size | L3 Cache – 48 MB |
|---|
Cache Per Processor | 48 MB |
|---|
RAM
Installed Size | 32 GB (installed) / 8 TB (max) |
|---|
Technology | DDR5 SDRAM |
|---|
Form Factor | DIMM 288-pin |
|---|
Slots | 32 (Total) / 31 (empty) |
|---|
Features | HPE SmartMemory, registered, slots 17 – 32 are available in two-processor configuration only |
|---|
Configuration Features | 1 x 32 GB |
|---|
Hard Drive
Storage Controller
Type | 1 x RAID – OCP 3.0 |
|---|
Controller Interface Type | Serial ATA-600 / SAS 3.0 / PCI Express (NVMe) |
|---|
Storage Controller Name | HPE MR408i-o Gen11 SPDM |
|---|
Channel Qty | 8 |
|---|
RAID Level | RAID 0, RAID 1, RAID 5, RAID 6, RAID 10, RAID 50, RAID 60 |
|---|
Buffer Size | 4 GB |
|---|
Optical Storage
Monitor
Graphics Controller
Video Memory | 16 MB |
|---|
Video Interfaces | DisplayPort, VGA |
|---|
Networking
Remote Management Controller | Integrated Lights-Out 7 |
|---|
Expansion / Connectivity
Bays | 8 (total) / 7 (free) x hot-swap 2.5″ SFF |
|---|
Slots | 4 (total) / 4 (free) x PCIe 5.0 x16 (x8 mode)
1 (total) / 1 (free) x Open Compute Project mezzanine (OCP) (for NIC adapter)
1 (total) / 0 (free) x Open Compute Project mezzanine (OCP) (for OROC/NIC adapter) |
|---|
Interfaces | 1 x DisplayPort 1.1a (1 in front)
1 x VGA (1 rear)
5 x USB 3.2 Gen 1 (1 front, 2 rear, 2 internal)
1 x HPE iLO – Type C (1 in front)
1 x HPE iLO – RJ-45 (management port) |
|---|
Miscellaneous
Included Accessories | 3 standard fans |
|---|
Theft/Intrusion Protection | Padlock eye, security lock slot (cable lock sold separately) |
|---|
Security Slot Type | Kensington security slot |
|---|
Compliant Standards | ACPI 6.5, ASHRAE Class A3, ASHRAE Class A4, SMBIOS 3.7, Active Directory v1.0, Redfish API, UEFI 2.10, UEFI Class 3, APML, TLS v1.3 |
|---|
Power
Device Type | Power supply – hot-plug |
|---|
Power Redundancy | Yes |
|---|
Power Redundancy Scheme | 1+1 |
|---|
Installed Qty | 2 |
|---|
Max Supported Qty | 2 |
|---|
Power Provided | 800 Watt |
|---|
80 PLUS Certification | 80 PLUS Platinum |
|---|
Operating System / Software
Software | HPE iLO Standard with Intelligent Provisioning, HPE OneView Standard (free download), HPE Compute Ops Management (subscription included) |
|---|
Dimensions & Weight
Width | 17.4 cm |
|---|
Depth | 71.2 cm |
|---|
Height | 46.2 cm |
|---|
Weight | 23.96 kg |
|---|
Environmental Parameters
Min Operating Temperature | 10 °C |
|---|
Max Operating Temperature | 35 °C |
|---|
Humidity Range Operating | 8 – 90% RH (non-condensing) |
|---|
