Milesight Pro Plus MS-C8266-RFIPG1, Network surveillance camera, bullet, vandal / weatherproof, colour (Day&Night), 8 MP, 3840 x 2160, f17 mount, auto and manual iris, motorized, audio, LAN 10/100, H.265+, H.264, H.265, H.264+, MJPEG, HEVC, DC 10, 28 V / PoE Plus
$1,153.31 inc GST
✓ In Stock - 15 available
✓ Free NZ Delivery
15 in stock
Ships from: Christchurch
- Allow 2–3 days for delivery to the North Island
- Allow 1–2 days for delivery to the South Island
- Add 1–2 days if you are rural
- Collection can be arranged
Description
The Milesight Pro Plus MS-C8266-RFIPG1 is a versatile network surveillance camera engineered for reliable performance in various conditions. With a wide operating temperature range from -40°C to 60°C and a humidity tolerance of 0 to 95% RH, this camera is designed to withstand diverse environments, ensuring consistent surveillance coverage. Equipped with a powerful optical sensor and a motorized zoom lens, users can achieve image clarity with resolutions reaching up to 3840 x 2160 pixels. The features, including automatic and manual focus adjustments, enhance the overall functionality, making it suitable for a plethora of applications.
- Wide operating temperature range for versatile environmental adaptability
- High-resolution imaging with 8 million total pixels
- Motorized zoom lens for flexible focal length control
- Comprehensive protocol support for seamless connectivity
- Robust weatherproof and vandal-proof design
- Reliable environmental resilience
The camera operates effectively in challenging environments with temperatures ranging from -40°C to 60°C and a humidity range of 0 to 95% RH, ensuring durability and performance. - High-quality imaging capabilities
Equipped with an optical sensor that supports resolutions up to 3840 x 2160, this surveillance camera captures crisp and detailed video, enhancing monitoring accuracy. - Versatile lens options
Featuring a motorized zoom lens with focal length capabilities from 2.8 mm to 12 mm, the camera allows for precise focus adjustments both automatically and manually. - Extensive connectivity support
Offers compatibility with multiple networking protocols, including IPv4, IPv6, and HTTP, ensuring integration within various security systems. - Robust protection features
Built to IP67 and IK10 standards, the camera is resistant to both weather conditions and physical vandalism, ideal for outdoor applications.
Main Specifications
Product Description | Milesight Pro Plus MS-C8266-RFIPG1 – network surveillance camera – bullet |
Device Type | Network surveillance camera – fixed – bullet – vandal / weatherproof |
Audio | Yes |
Dimensions (WxDxH) | 13.4 cm x 32 cm x 12.6 cm |
Weight | 1.6 kg |
Connectivity Technology | Wired |
Camera | Colour – Day&Night |
Optical Zoom | 4.3 x |
Max Resolution | 3840 x 2160 |
Frame Rate (max) | 60 frames per second |
Motion Detection | Yes |
Optical Sensor Type | Progressive Scan CMOS – 1/1.8″ – 8 MP |
Minimum Illumination | 0.0008 lux – colour – F1.2 0 lux – B&W – infrared LEDs on |
Focal Length Control | Motorized zoom |
Focal Length | 2.8 mm – 12 mm |
Lens Mounting | F17 mount |
Focus Adjustment | Automatic, manual |
Lens Iris | F/1.2 – auto and manual iris (P-Iris) |
Interfaces | Ethernet 10Base-T/100Base-TX |
Voltage | DC 10 – 28 V / PoE Plus |
Features | 120 dB wide dynamic range, Super WDR, >55 dB SNR, DORI coverage, 850nm illuminator, Constant Bitrate (CBR), Variable Bitrate (VBR), 4 video streams, AI-powered ISP, privacy masking (up to 8 areas), brightness control, contrast control, saturation control, sharpness control, 180° image rotation, 90° image rotation, image flip, Backlight Compensation (BLC), Highlight Compensation (HLC), Defog, 2D digital noise reduction (DNR), 3D digital noise reduction (DNR), Automatic Whiteness Balance (AWB), Automatic Gain Control (AGC), deblur, anti-flicker, Lens Distortion Compensation (LDC), 32x hybrid zoom, Automatic Network Replenishment (ANR), NAS-Ready, intrusion detection, region entrance detection, region exiting detection, Advanced Motion Detection, Line Crossing Detection, loitering detection, Object Left detection, Object Removed, attribute extraction, clothing color recognition, hat recognition, vehicle type classification, face detection, face attribute recognition, Object Counting, Heat Map, tamper-detection, Edge Storage, 802.1x authentication, ONVIF (Profile G) support, ONVIF (Profile M) support, ONVIF (Profile S) support, ONVIF (Profile T) support, 6KV surge protection |
Environmental Parameters (operating) | -40 °C – 60 °C; 0 – 95% RH (non-condensing) relative humidity |
Documents
Extended Specifications
General
Device Type | Network surveillance camera |
|---|---|
Audio Support | Yes |
Audio Formats | AAC, G.711, G.722, G.726 |
Form Factor | Bullet |
Connectivity Technology | Wired |
Width | 13.4 cm |
Depth | 32 cm |
Height | 12.6 cm |
Weight | 1.6 kg |
Camera
Type | Colour – Day&Night – fixed – vandal / weatherproof |
|---|---|
Digital Video Format | H.265+, H.264, H.265, H.264+, MJPEG, HEVC |
Max Digital Video Resolution | 3840 x 2160 |
Motion Detection | Yes |
Exposure Range | 1 sec – 1/100000 sec |
Minimum Illumination | 0.0008 lux – colour – F1.2 0 lux – B&W – infrared LEDs on |
Infrared LEDs | 6 |
Infrared Distance | 80 m |
Digital Video Capture Resolution | 3840 x 2160, 3072 x 2048, 2592 x 1944, 2592 x 1520, 2048 x 1536, 1920 x 1080, 1280 x 960, 1280 x 720, 704 x 576, 640 x 480, 640 x 360 |
Frame Rate (max) | 60 frames per second |
Features | 120 dB wide dynamic range, Super WDR, >55 dB SNR, DORI coverage, 850nm illuminator, Constant Bitrate (CBR), Variable Bitrate (VBR), 4 video streams, AI-powered ISP, privacy masking (up to 8 areas), brightness control, contrast control, saturation control, sharpness control, 180° image rotation, 90° image rotation, image flip, Backlight Compensation (BLC), Highlight Compensation (HLC), Defog, 2D digital noise reduction (DNR), 3D digital noise reduction (DNR), Automatic Whiteness Balance (AWB), Automatic Gain Control (AGC), deblur, anti-flicker, Lens Distortion Compensation (LDC), 32x hybrid zoom, Automatic Network Replenishment (ANR), NAS-Ready, intrusion detection, region entrance detection, region exiting detection, Advanced Motion Detection, Line Crossing Detection, loitering detection, Object Left detection, Object Removed, attribute extraction, clothing color recognition, hat recognition, vehicle type classification, face detection, face attribute recognition, Object Counting, Heat Map, tamper-detection, Edge Storage, 802.1x authentication, ONVIF (Profile G) support, ONVIF (Profile M) support, ONVIF (Profile S) support, ONVIF (Profile T) support, 6KV surge protection |
Image Sensor
Type | 8 MP Progressive Scan CMOS 1/1.8″ |
|---|
Lens Construction
Type | F17 mount – motorized zoom |
|---|---|
Optical Zoom | 4.3 x |
Focal Length | 2.8 mm – 12 mm |
Lens Iris | F/1.2 auto and manual iris (P-Iris) |
Focus Adjustment | Automatic, manual |
Horizontal Field of View (degree) | 46.8 – 105.3 |
Vertical Field of View (degree) | 26.2 – 55.6 |
Diagonal Field of View (degree) | 53.9 – 122.6 |
Interfaces
Network Interface | Ethernet 10Base-T/100Base-TX |
|---|---|
Network Protocols | IPv4, IPv6, ARP, TCP, UDP, RTCP, RTP, RTSP, RTMP, HTTP, HTTPS, DNS, DDNS, DHCP, FTP, NTP, SMTP, SNMP, UPnP, Bonjour, LLDP, SIP, PPPoE, QOS, IGMP, ICMP, SSL, TLS |
Alarm Inputs Qty | 2 |
Alarm Outputs Qty | 2 |
Expansion / Connectivity
Ports | LAN/power – RJ-45 Audio line in/line out |
|---|---|
Supported Memory Cards | microSD Card, microSDHC Card, microSDXC Card |
Encryption Algorithm | TLS 1.2 |
Miscellaneous
Compliant Standards | IP67, IK10, NDAA, IEEE 802.3af |
|---|
Power
Power Requirements | DC 10 – 28 V / PoE Plus |
|---|
Dimensions & Weight (Shipping)
Shipping Weight | 2.4 kg |
|---|
Environmental Parameters
Min Operating Temperature | -40 °C |
|---|---|
Max Operating Temperature | 60 °C |
Relative Humidity (operating) | 0 – 95% RH (non-condensing) |
