Description
Hewlett Packard Enterprise HPE ProLiant ML30 Gen11 is a tower server designed for small to midsize deployments that need a balance of performance, scalability, and manageability. It supports a single Intel Xeon processor and DDR5 memory across four DIMM slots, enabling responsive handling of typical business workloads while leaving room for future upgrades. Integrated Lights-Out 6 provides remote systems management and service access, and multiple Gigabit Ethernet ports with Wake-on-LAN and PXE support help maintain network reliability and remote boot capabilities.
The chassis offers a compact, rack-friendly 4U height with practical security features such as a padlock eye and Kensington security slot, and it includes versatile expansion with PCIe 5.0 and PCIe 4.0 slots plus M.2 support for modern storage options. Built-in display outputs and a front service USB port simplify setup and maintenance, while broad environmental compatibility and industry-standard compliance help integrate the server into existing IT environments.
- Single-socket Xeon platform for predictable, upgradeable compute capacity
- DDR5 memory support with four DIMM slots for responsive multitasking
- Integrated Lights-Out 6 for secure remote management and diagnostics
- Flexible expansion with PCIe 5.0 x16 and additional PCIe 4.0 slots
- Reliable management
Integrated Lights-Out 6 delivers remote access, monitoring, and service capabilities to simplify administration and reduce on-site intervention. - Flexible expansion
A combination of PCIe 5.0 and PCIe 4.0 slots plus M.2 support allows installation of accelerator cards, additional NICs, or modern storage to adapt to evolving workloads. - Secure design
Physical security features including a padlock eye and Kensington security slot, together with firmware compliance and cryptographic standards, help protect hardware and data.
Main Specifications
Product Description | HPE ProLiant ML30 Gen11 – tower Xeon 6325P 3.5 GHz – 32 GB – HDD 2 x 1 TB |
Type | Server – tower |
Height (Rack Units) | 4U |
Server Scalability | 1-way |
Processor | 1 x Intel Xeon 6325P / 3.5 GHz (up to 5.2 GHz, (Quad-Core) |
Processor Main Features | Hyper-Threading Technology, Intel Turbo Boost Technology 2, 8 Threads, 55W TDP |
Cache Memory | 12 MB L3 Cache |
Cache Per Processor | 12 MB |
RAM | 32 GB (installed) / 128 GB (max) – DDR5 SDRAM |
Storage Controller | RAID (Serial ATA-600 / SAS 3.0 / PCI Express (NVMe)) (HPE MR216i-p Gen11 SPDM) |
Server Storage Bays | Hot-swap 3.5" |
Hard Drive | 2 x HDD 1 TB – SATA 6Gb/s – 7200 rpm |
Optical Storage | No optical drive |
Video Memory | 16 MB |
Networking | 1GbE |
Power Redundancy | Optional |
OS Provided | No operating system |
Software Included | HPE iLO Standard with Intelligent Provisioning, HPE OneView Standard (free download) |
Dimensions (WxDxH) | 17.53 cm x 47.5 cm x 36.83 cm |
Weight | 10.2 kg |
Environmental Standards | ENERGY STAR Qualified EPEAT Bronze |
Documents
Extended Specifications
General
Type | Server |
|---|
Product Form Factor | Tower – 4U |
|---|
Built-in Devices | Led panel |
|---|
Embedded Security | Trusted Platform Module (TPM 2.0) Security Chip |
|---|
Server Scalability | 1-way |
|---|
Hot-Swap Bays Qty | 4 |
|---|
Processor / Chipset
CPU | Intel Xeon 6325P |
|---|
Clock Speed | 3.5 GHz |
|---|
Max Turbo Speed | 5.2 GHz |
|---|
Number of Cores | Quad-Core |
|---|
CPU Qty | 1 |
|---|
Max CPU Qty | 1 |
|---|
CPU Upgradability | Upgradable |
|---|
Processor Main Features | Hyper-Threading Technology, Intel Turbo Boost Technology 2, 8 Threads, 55W TDP |
|---|
Chipset Type | Intel C262 |
|---|
Cache Memory
Installed Size | L3 Cache – 12 MB |
|---|
Cache Per Processor | 12 MB |
|---|
RAM
Installed Size | 32 GB (installed) / 128 GB (max) |
|---|
Technology | DDR5 SDRAM |
|---|
Effective Memory Speed | 3600 MT/s |
|---|
Rated Memory Speed | 3600 MT/s |
|---|
Form Factor | DIMM 288-pin |
|---|
Slots | 4 (Total) / 3 (empty) |
|---|
Features | Unbuffered, HPE Standard Memory |
|---|
Configuration Features | 1 x 32 GB |
|---|
Hard Drive
Type | HDD |
|---|
Capacity | 2 x 1 TB |
|---|
Interface Type | SATA 6Gb/s |
|---|
Spindle Speed | 7200 rpm |
|---|
Features | Business critical, HPE Multi Vendor |
|---|
Storage Controller
Type | 1 x RAID |
|---|
Controller Interface Type | Serial ATA-600 / SAS 3.0 / PCI Express (NVMe) |
|---|
Storage Controller Name | HPE MR216i-p Gen11 SPDM |
|---|
Channel Qty | 16 |
|---|
RAID Level | RAID 0, RAID 1, RAID 5, RAID 6, RAID 10, RAID 50, RAID 60 |
|---|
Optical Storage
Monitor
Graphics Controller
Video Memory | 16 MB |
|---|
Video Interfaces | VGA, DisplayPort |
|---|
Networking
Ethernet Ports | 4 x Gigabit Ethernet |
|---|
Ethernet Controller | Broadcom BCM5719 |
|---|
Data Link Protocol | Ethernet, Fast Ethernet, Gigabit Ethernet |
|---|
Remote Management Controller | Integrated Lights-Out 6 |
|---|
Features | Wake on LAN (WoL), PXE support |
|---|
Expansion / Connectivity
Bays | 4 (total) / 2 (free) x hot-swap 3.5" LFF |
|---|
Slots | 1 (total) / 1 (free) x PCIe 5.0 x16 – full-length, full-height (x16 mode, processor)
1 (total) / 1 (free) x PCIe 4.0 x8 – full-length, full-height (x4 mode, processor)
2 (total) / 2 (free) x PCIe 4.0 x8 – half-length, full-height (x4 mode, PCH)
1 (total) / 1 (free) x M.2 Card (PCIe 3.0 x2/NVMe) |
|---|
Interfaces | 1 x DisplayPort
1 x VGA
3 x LAN (Gigabit Ethernet) – RJ-45 (3 rear)
1 x HPE iLO – Type A (1 front) (service port)
5 x USB 3.2 Gen 1 (1 front, 4 rear)
1 x LAN (Gigabit Ethernet) / HPE iLO – RJ-45 (1 rear) |
|---|
Miscellaneous
Theft/Intrusion Protection | Security lock slot (cable lock sold separately), padlock eye |
|---|
Security Slot Type | Kensington security slot |
|---|
Compliant Standards | AES, Triple DES, TLS v1.2, ASHRAE Class A4, ASHRAE Class A3, Redfish API, ACPI 6.3, Active Directory v1.0, UEFI 2.9 |
|---|
Power
Device Type | Power supply – hot-plug |
|---|
Power Redundancy | Optional |
|---|
Power Redundancy Scheme | 1+1 (with optional power supply) |
|---|
Installed Qty | 1 |
|---|
Max Supported Qty | 2 |
|---|
Voltage Required | AC 100-120/200-240 V |
|---|
Power Provided | 500 watt |
|---|
80 PLUS Certification | 80 PLUS Platinum |
|---|
Operating System / Software
OS Provided | No operating system |
|---|
Software | HPE iLO Standard with Intelligent Provisioning, HPE OneView Standard (free download) |
|---|
Sustainability Information
EPEAT Compliant | EPEAT Bronze |
|---|
ENERGY STAR Certified | Yes |
|---|
ENERGY STAR Version | 4.0 |
|---|
Dimensions & Weight
Width | 17.53 cm |
|---|
Depth | 47.5 cm |
|---|
Height | 36.83 cm |
|---|
Weight | 10.2 kg |
|---|
Environmental Parameters
Min Operating Temperature | 10 °C |
|---|
Max Operating Temperature | 35 °C |
|---|
Humidity Range Operating | 8 – 90% RH (non-condensing) |
|---|
