Description
Do you need to efficiently expand or refresh your IT infrastructure to propel the business? Adaptable to diverse workloads and environments, the compact 1U 1P HPE ProLiant DL320 Gen11 delivers enhanced performance with the right balance of expandability and density. Designed for supreme versatility and resiliency, the HPE ProLiant DL320 Gen11 is ideal for IT infrastructure, either physical, virtual, or containerized.
The HPE ProLiant DL320 Gen11 supports the Intel Xeon, plus 4800 MT/s HPE DDR5 Smart Memory. Introducing PCIe Gen5 and Intel Software Guard Extensions (SGX) support on the single socket segment, the HPE ProLiant DL320 Gen11 delivers premium compute, memory, I/O, and security capabilities for customers focused on performance at 1P economics. DL320 Gen11 is an excellent choice for daily business and workloads in Data Management, Virtualization, Content Delivery Network (CDN), Intelligent Video Analytics (IVA), General Compute, Data Collection, Software Defined Storage, Software Defined Compute, Cold Storage, Compute Storage, Edge AI, and Virtual Desktop Infrastructure (VDI).
- 12-core Xeon Silver processor for high-speed performance
- Supports RAID 0, 1, 10, 5, 50, and 60 for versatile storage configurations
- 16 GB DDR5 SDRAM with HPE SmartMemory for enhanced processing speed
- Hot-plug power supply with an option for an additional unit for redundancy
- Dual Gigabit Ethernet ports and HPE iLO for comprehensive connectivity and remote management
- Advanced performance
Equipped with a 12-core Xeon Silver processor and a clock speed of 2 GHz, boosting up to 3.9 GHz, this server delivers reliable and high-speed performance for demanding applications. - Robust storage options
With 8 hot-swap bays and support for RAID 0, 1, 10, 5, 50, and 60 configurations, the HPE ProLiant DL320 Gen11 offers flexible and secure storage solutions, ensuring data integrity and performance. - High-speed memory
Features 16 GB of DDR5 SDRAM with an 8-channel memory architecture and HPE SmartMemory technology, enhancing data processing speeds and system reliability. - Efficient power management
The server includes a hot-plug power supply with the capability to support an additional unit, ensuring uninterrupted power and operational efficiency. - Comprehensive connectivity
Offers a variety of interface options including HPE iLO for remote management, USB 3.2 Gen 1, VGA, and dual Gigabit Ethernet ports, facilitating easy integration and management.
What’s in the Box
- HPE ProLiant DL320 Gen11
- 7 x standard fans
Main Specifications
Product Description | HPE ProLiant DL320 Gen11 – rack-mountable Xeon Silver 4514Y 2 GHz – 64 GB – SSD 2 x 480 GB |
Type | Server – rack-mountable |
Height (Rack Units) | 1U |
Server Scalability | 1-way |
Processor | 1 x Intel Xeon Silver 4514Y / 2 GHz (up to 3.4 GHz, (16-core) |
Processor Main Features | Intel Turbo Boost Technology |
Cache Memory | 30 MB L3 Cache |
Cache Per Processor | 30 MB |
RAM | 64 GB (installed) / 2.04 TB (max) – DDR5 SDRAM |
Storage Controller | RAID (Serial ATA-600 / SAS 3.0 / PCI Express (NVMe)) – OCP (HPE MR408i-o Gen11 SPDM) |
Server Storage Bays | Hot-swap 2.5″ |
Hard Drive | 2 x SSD 480 GB – SATA |
Optical Storage | No optical drive |
Video Memory | 16 MB |
Networking | 1GbE |
Power Redundancy | Optional |
OS Provided | No operating system |
Dimensions (WxDxH) | 60 cm x 91.6 cm x 24.1 cm |
Weight | 25.8 kg |
Manufacturer Selling Program | HPE Smart Choice |
Environmental Standards | ENERGY STAR Qualified |
Documents
Extended Specifications
General
Type | Server |
|---|
Product Form Factor | Rack-mountable – 1U |
|---|
Built-in Devices | Led panel |
|---|
Embedded Security | Trusted Platform Module (TPM 2.0) Security Chip |
|---|
Server Scalability | 1-way |
|---|
Hot-Swap Bays Qty | 8 |
|---|
Processor / Chipset
CPU | Intel Xeon Silver 4514Y |
|---|
Clock Speed | 2 GHz |
|---|
Max Turbo Speed | 3.4 GHz |
|---|
Number of Cores | 16-core |
|---|
CPU Qty | 1 |
|---|
Max CPU Qty | 1 |
|---|
CPU Upgradability | Upgradable |
|---|
Processor Main Features | Intel Turbo Boost Technology |
|---|
Chipset Type | Intel C741 |
|---|
Cache Memory
Installed Size | L3 Cache – 30 MB |
|---|
Cache Per Processor | 30 MB |
|---|
RAM
Installed Size | 64 GB (installed) / 2.04 TB (max) |
|---|
Technology | DDR5 SDRAM |
|---|
Effective Memory Speed | 4800 MT/s |
|---|
Rated Memory Speed | 4800 MT/s |
|---|
Form Factor | DIMM 288-pin |
|---|
Slots | 16 (Total) / 14 (empty) |
|---|
Features | Registered, HPE SmartMemory, 8-channel memory architecture |
|---|
Configuration Features | 2 x 32 GB |
|---|
Hard Drive
Type | SSD |
|---|
Capacity | 2 x 480 GB |
|---|
Interface Type | SATA |
|---|
Storage Controller
Type | 1 x RAID – OCP |
|---|
Controller Interface Type | Serial ATA-600 / SAS 3.0 / PCI Express (NVMe) |
|---|
Storage Controller Name | HPE MR408i-o Gen11 SPDM |
|---|
Channel Qty | 8 |
|---|
RAID Level | RAID 0, RAID 1, RAID 5, RAID 10, RAID 50, RAID 60 |
|---|
Buffer Size | 4 GB |
|---|
Optical Storage
Monitor
Graphics Controller
Video Memory | 16 MB |
|---|
Video Interfaces | VGA |
|---|
Networking
Ethernet Ports | 2 x Gigabit Ethernet |
|---|
Ethernet Controller | Broadcom BCM5720 |
|---|
Data Link Protocol | Ethernet, Fast Ethernet, Gigabit Ethernet |
|---|
Remote Management Protocol | IPMI 2.0, SNMP 3 |
|---|
Remote Management Controller | Integrated Lights-Out 6 |
|---|
Features | ACPI support, PXE support, Wake on LAN (WoL) |
|---|
Expansion / Connectivity
Bays | 8 (total) / 6 (free) x hot-swap 2.5″ SFF |
|---|
Slots | 2 (total) / 2 (free) x PCIe 5.0 x16 – full-length, full-height (x16 mode)
1 (total) / 1 (free) x PCIe 5.0 x16 / Open Compute Project mezzanine (OCP) 3.0 (x16 mode) |
|---|
Interfaces | 1 x HPE iLO (1 in front) (service port)
3 x USB 3.2 Gen 1 (1 front, 2 rear)
1 x USB 2.0
1 x VGA
2 x LAN (Gigabit Ethernet) |
|---|
Miscellaneous
Included Accessories | 7 x standard fans |
|---|
Compliant Standards | AES, FIPS 140-2, Triple DES, IPv6 Ready, PCI DSS, TLS v1.2, ASHRAE Class A4, ASHRAE Class A3, WEEE 2002/95/EC, ACPI 6.3 |
|---|
Manufacturer Selling Program | HPE Smart Choice |
|---|
Power
Device Type | Power supply – hot-plug |
|---|
Power Redundancy | Optional |
|---|
Power Redundancy Scheme | 1+1 (with optional power supply) |
|---|
Installed Qty | 2 |
|---|
Max Supported Qty | 2 |
|---|
Voltage Required | AC 100-240 V |
|---|
Power Provided | 500 Watt |
|---|
80 PLUS Certification | 80 PLUS Titanium |
|---|
Operating System / Software
OS Provided | No operating system |
|---|
OS Certified | Microsoft Windows Server 2019, Microsoft Windows Server 2022, VMware ESXi 7.0 update 3, VMware ESXi 8.0, VMware ESXi 8.0 update 1, Red Hat Enterprise Linux 8.6, Red Hat Enterprise Linux 9.0, SUSE Linux Enterprise Server 15 SP4, Ubuntu 22.04 LTS, CentOS |
|---|
Sustainability Information
ENERGY STAR Certified | Yes |
|---|
ENERGY STAR Version | 4.0 |
|---|
Dimensions & Weight
Width | 60 cm |
|---|
Depth | 91.6 cm |
|---|
Height | 24.1 cm |
|---|
Weight | 25.8 kg |
|---|
Environmental Parameters
Min Operating Temperature | 10 °C |
|---|
Max Operating Temperature | 35 °C |
|---|
Humidity Range Operating | 8 – 90% RH (non-condensing) |
|---|
