Description
Are you searching for an affordable tower server with enterprise-class reliability and performance to meet the requirements of your growing business? The HPE ProLiant ML110 Gen11 server is an enhanced single processor tower with performance, expansion, and security at an affordable price. It supports the 4th and 5th Gen Intel Xeon Scalable processor, HPE DDR5 SmartMemory with a maximum capacity of 1536 GB, 4 x16 PCIe Gen5 slots, 1 x16 OCP3 slot, eight large form factor (LFF) or 16 small form factor (SFF) disk drives. It can easily be converted to a rack using 5.5U of rack space. The HPE ProLiant ML110 Gen11 server also offers optional redundant fan and redundant power supply to satisfy automatic fail-over needs, making this the ideal server for small- to mid-sized businesses, and remote and branch offices.
- HPE ProLiant ML110 Gen11 servers are engineered for your hybrid world. HPE ProLiant Gen11 servers simplify the way you control your business’s compute—from edge to cloud—with a cloud operating experience.
- HPE ProLiant ML110 Gen11 server uses the silicon root of trust to anchor the firmware of an HPE ASIC, creating an immutable fingerprint for the Intel Processor that must be matched exactly before the server will boot. This verifies that malicious code is contained, and healthy servers are protected.
- The HPE ProLiant ML110 Gen11 server is an excellent choice for compute and data storage balanced workloads (IT infrastructure, Data Management, VDI, ERP/CRM) requiring outstanding performance, network and I/O bandwidth.
- The HPE ProLiant ML110 Gen11 server comes with a complete set of HPE Services, delivering confidence, reducing risk, and helping customers realize agility and stability.
- Intuitive Cloud Operating Experience: Simple, Unified, and Automated
HPE ProLiant ML110 Gen11 servers are engineered for your hybrid world. HPE ProLiant Gen11 servers simplify the way you control your business’s compute-from edge to cloud-with a cloud operating experience.
Transform business operations and pivot your team from reactive to proactive with global visibility and insight through a single console.
Automate tasks for efficiency in deployment, instant scalability, and seamless, simplified support and lifecycle management, effectively reducing tasks and shortening maintenance windows.
These experiences are engineered and built into HPE ProLiant Gen11 servers, whether purchased as physical servers or consume as-a-service using HPE GreenLake as your compute and storage demands grow.
Simplify and secure server management from edge to cloud with HPE Compute Ops Management. HPE Compute Ops Management is an as-a-service compute management experience that delivers greater simplicity, agility, and speed across your entire compute landscape, globally. - Trusted Security by Design: Uncompromising, Fundamental, and Protected
HPE ProLiant ML110 Gen11 server uses the silicon root of trust to anchor the firmware of an HPE ASIC, creating an immutable fingerprint for the Intel Processor that must be matched exactly before the server will boot. This verifies that malicious code is contained, and healthy servers are protected.
HPE ProLiant Gen11 servers continuously protect healthy servers at the edge by providing rapid detection of security-compromised servers, even to the point of not allowing them to boot if it identifies and contains malicious code, with IDevID certificates installed by default.
HPE ProLiant Gen11 servers provide automated recovery from a security event, including restoration of validated firmware, and facilitating recovery of the operating system, application, data connections, and providing a fast path to bring a server back online and into normal operations.
From silicon to software, from factory to cloud, and from generation to generation, HPE ProLiant Gen11 is engineered with a fundamental security approach to defend against increasingly complex threats through an uncompromising commitment to constant security advancements that are built into our DNA. - Customized Performance for your Workloads: Accelerated, Open, and Efficient
The HPE ProLiant ML110 Gen11 server is an excellent choice for compute and data storage balanced workloads (IT infrastructure, Data Management, VDI, ERP/CRM) requiring outstanding performance, network and I/O bandwidth.
Harness advanced compute performance. HPE ProLiant ML110 Gen11 server is powered by 4th and 5th Gen Intel Xeon Scalable Processors that support up to 32 cores at 185W TDP.
Enjoy advanced data transfer rates and higher network speeds from the PCIe Gen5 serial expansion bus, with up to 4 x16 PCIe Gen5 and 1 x16 OCP slots to improve I/O throughput and reduce latency.
Utilize 16 DIMM slots for up to 1.5 TB DDR5 memory with increased memory bandwidth and performance, and lower power requirements. - Industry-leading Services and Ease of Deployment
The HPE ProLiant ML110 Gen11 server comes with a complete set of HPE Services, delivering confidence, reducing risk, and helping customers realize agility and stability.
HPE Services simplify all stages of the IT journey. Advisory and Transformation Services professionals understand customer challenges and design an effective solution. Professional Services enable rapid deployment of solutions and Operational Services provide ongoing support.
Services provided under Operational Services include: HPE Flexible Capacity, HPE Datacenter Care, HPE Infrastructure Automation, HPE Campus Care, HPE Proactive Services and multi-vendor coverage.
HPE IT investment solutions help you transform to a digital business with IT economics that align to your business goals.
Benefit from real-time operational feedback on server performance plus recommendations for fine-tuning BIOS settings to customize for changing business needs.
What’s in the Box
- HPE ProLiant ML110 Gen11
- 2 x standard fans
Main Specifications
Product Description | HPE ProLiant ML110 Gen11 – tower Xeon Bronze 3508U 2.1 GHz – 32 GB – HDD 2 x 2 TB |
Type | Server – tower |
Height (Rack Units) | 4.5U |
Server Scalability | 1-way |
Processor | 1 x Intel Xeon Bronze 3508U / 2.1 GHz (up to 2.2 GHz, (8-core) |
Processor Main Features | Intel Turbo Boost Technology 2, 125W TDP |
Cache Memory | 22.5 MB L3 Cache |
Cache Per Processor | 22.5 MB |
RAM | 32 GB (installed) / 1 TB (max) – DDR5 SDRAM – ECC |
Storage Controller | SATA (SATA-600 / NVMe) (Intel VROC SATA Software RAID) |
Server Storage Bays | Hot-swap 3.5″ |
Hard Drive | 2 x HDD 2 TB – SATA 6Gb/s – 7200 rpm |
Optical Storage | No optical drive |
Video Memory | 16 MB |
Networking | 1GbE |
Power Redundancy | Optional |
Software Included | HPE iLO Standard with Intelligent Provisioning, HPE OneView Standard (free download) |
Dimensions (WxDxH) | 19.5 cm x 58.7 cm x 46.2 cm |
Weight | 20.4 kg |
Environmental Standards | ENERGY STAR Qualified EPEAT Bronze |
Documents
Extended Specifications
General
Type | Server |
|---|
Product Form Factor | Tower – 4.5U |
|---|
Built-in Devices | Led panel |
|---|
Embedded Security | Trusted Platform Module (TPM 2.0) Security Chip |
|---|
Server Scalability | 1-way |
|---|
Front Accessible Bays Qty | 1 |
|---|
Hot-Swap Bays Qty | 4 |
|---|
Processor / Chipset
CPU | Intel Xeon Bronze 3508U |
|---|
Clock Speed | 2.1 GHz |
|---|
Max Turbo Speed | 2.2 GHz |
|---|
Number of Cores | 8-core |
|---|
CPU Qty | 1 |
|---|
Max CPU Qty | 1 |
|---|
CPU Upgradability | Upgradable |
|---|
Processor Main Features | Intel Turbo Boost Technology 2, 125W TDP |
|---|
Chipset Type | Intel C741 |
|---|
Cache Memory
Installed Size | L3 Cache – 22.5 MB |
|---|
Cache Per Processor | 22.5 MB |
|---|
RAM
Installed Size | 32 GB (installed) / 1 TB (max) |
|---|
Technology | DDR5 SDRAM – ECC |
|---|
Effective Memory Speed | 2200 MHz |
|---|
Rated Memory Speed | 2800 MHz |
|---|
Form Factor | DIMM 288-pin |
|---|
Slots | 16 (Total) / 15 (empty) |
|---|
Features | Registered, HPE SmartMemory |
|---|
Configuration Features | 1 x 32 GB |
|---|
Hard Drive
Type | HDD |
|---|
Capacity | 2 x 2 TB |
|---|
Interface Type | SATA 6Gb/s |
|---|
Spindle Speed | 7200 rpm |
|---|
Features | Business critical, HPE Multi Vendor |
|---|
Storage Controller
Type | 1 x SATA |
|---|
Controller Interface Type | SATA-600 / NVMe |
|---|
Storage Controller Name | Intel VROC SATA Software RAID |
|---|
Optical Storage
Monitor
Graphics Controller
Video Memory | 16 MB |
|---|
Video Interfaces | VGA, DisplayPort |
|---|
Networking
Ethernet Ports | 2 x Gigabit Ethernet |
|---|
Ethernet Controller | Broadcom BCM5720 |
|---|
Data Link Protocol | Ethernet, Fast Ethernet, Gigabit Ethernet |
|---|
Remote Management Protocol | SNMP 3, IPMI 2.0, SMASH CLP |
|---|
Remote Management Controller | Integrated Lights-Out 6 |
|---|
Features | Wake on LAN (WoL), PXE support |
|---|
Expansion / Connectivity
Bays | 1 (total) / 1 (free) x external 5.25″
4 (total) / 2 (free) x hot-swap 3.5″ LFF |
|---|
Slots | 2 (total) / 2 (free) x PCIe 5.0 x16
1 (total) / 1 (free) x PCIe 5.0 x16 / Open Compute Project mezzanine (OCP) 3.0 (x16 mode) |
|---|
Interfaces | 1 x DisplayPort 1.1a
1 x VGA
2 x LAN (Gigabit Ethernet)
1 x HPE iLO – Type A (1 in front)
1 x HPE iLO – RJ-45 (1 rear)
4 x USB 3.2 Gen 1 (1 front, 2 rear, 1 internal)
1 x USB 2.0 (1 internal) |
|---|
Miscellaneous
Included Accessories | 2 x standard fans |
|---|
Compliant Standards | AES, Triple DES, TLS v1.2, ASHRAE Class A4, ASHRAE Class A3, Redfish API, ACPI 6.4, SMBIOS 3.4, UEFI 2.7, Active Directory v1.0, UEFI Class 3, APML, MCTP |
|---|
Power
Device Type | Power supply – hot-plug |
|---|
Power Redundancy | Optional |
|---|
Power Redundancy Scheme | 1+1 (with optional power supply) |
|---|
Installed Qty | 1 |
|---|
Max Supported Qty | 2 |
|---|
Power Provided | 500 watt |
|---|
80 PLUS Certification | 80 PLUS Platinum |
|---|
Operating System / Software
Software | HPE iLO Standard with Intelligent Provisioning, HPE OneView Standard (free download) |
|---|
Sustainability Information
EPEAT Compliant | EPEAT Bronze |
|---|
ENERGY STAR Certified | Yes |
|---|
ENERGY STAR Version | 4.0 |
|---|
Dimensions & Weight
Width | 19.5 cm |
|---|
Depth | 58.7 cm |
|---|
Height | 46.2 cm |
|---|
Weight | 20.4 kg |
|---|
Environmental Parameters
Min Operating Temperature | 10 °C |
|---|
Max Operating Temperature | 35 °C |
|---|
Humidity Range Operating | 8 – 90% RH (non-condensing) |
|---|
