Description
The HPE ProLiant DL380 Gen12 is a versatile rack-mountable server designed for a variety of business applications. This model features a hot-swap storage bay capable of accommodating 2.5-inch drives, ensuring efficient data management without downtime. Operating efficiently in temperatures ranging from 10°C to 35°C and a humidity range of 8 to 90% RH meets environmental adaptability needs, making it suitable for various operating conditions. Integrated management options, such as HPE iLO, provide remote access for monitoring and configuration, allowing for operational flexibility. Built with modern architecture including support for DDR5 SDRAM and offering extensive expansion options, the HPE ProLiant DL380 Gen12 is engineered to grow alongside evolving business needs, ensuring reliability and performance in demanding environments.
- Rack-mountable design suitable for various setups
- Hot-swap storage bays for easy drive replacement
- Efficient operating temperature and humidity range
- Integrated management for remote server access
- Support for DDR5 SDRAM for enhanced performance
- Flexible storage options
The server features hot-swap storage bays for 2.5-inch drives, allowing for easy maintenance and quick replacement without system downtime. - Efficient environmental adaptability
With an operating temperature range of 10°C to 35°C and a humidity range of 8 to 90% RH, the server can perform reliably in various environmental conditions. - Comprehensive remote management
Equipped with Integrated Lights-Out 7, this server enables remote access and management, facilitating efficient operations and troubleshooting. - Advanced RAM technology
Supporting DDR5 SDRAM and HPE SmartMemory, this server provides enhanced performance with 32 slots, ensuring ample memory capacity for demanding applications. - Robust security features
Built-in Trusted Platform Module (TPM 2.0) enhances data protection and ensures secure operations, making it suitable for critical business environments.
What’s in the Box
- HPE ProLiant Compute DL380 Gen12
- 4 standard fans
Main Specifications
Product Description | HPE ProLiant Compute DL380 Gen12 – rack-mountable Xeon 6505P 2.2 GHz – 64 GB – SSD 2 x 480 GB |
Type | Server – rack-mountable |
Height (Rack Units) | 2U |
Server Scalability | 2-way |
Processor | 1 x Intel Xeon 6505P / 2.2 GHz (up to 4.1 GHz, (12-core) |
Processor Main Features | Hyper-Threading Technology, Intel Turbo Boost Technology 2, 24 Threads, 150W TDP |
Cache Memory | 48 MB L3 Cache |
Cache Per Processor | 48 MB |
RAM | 64 GB (installed) / 8 TB (max) – DDR5 SDRAM |
Storage Controller | RAID (Serial ATA-600 / SAS 3.0 / PCI Express (NVMe)) – OCP 3.0 (HPE MR408i-o Gen11 SPDM) |
Server Storage Bays | Hot-swap 2.5″ |
Hard Drive | 2 x SSD 480 GB |
Optical Storage | No optical drive |
Video Memory | 16 MB |
Power Redundancy | Yes |
Software Included | HPE iLO Standard with Intelligent Provisioning, HPE OneView Standard (free download), HPE Compute Ops Management (subscription included) |
Dimensions (WxDxH) | 44.8 cm x 72.7 cm x 8.75 cm |
Weight | 18 kg |
Environmental Standards | EPEAT Silver |
Documents
Extended Specifications
General
Type | Server |
|---|
Product Form Factor | Rack-mountable – 2U |
|---|
Built-in Devices | Led panel |
|---|
Embedded Security | Trusted Platform Module (TPM 2.0) Security Chip |
|---|
Server Scalability | 2-way |
|---|
Hot-Swap Bays Qty | 8 |
|---|
Processor / Chipset
CPU | Intel Xeon 6505P |
|---|
Clock Speed | 2.2 GHz |
|---|
Max Turbo Speed | 4.1 GHz |
|---|
Number of Cores | 12-core |
|---|
CPU Qty | 1 |
|---|
Max CPU Qty | 2 |
|---|
CPU Upgradability | Upgradable |
|---|
Processor Main Features | Hyper-Threading Technology, Intel Turbo Boost Technology 2, 24 Threads, 150W TDP |
|---|
Cache Memory
Installed Size | L3 Cache – 48 MB |
|---|
Cache Per Processor | 48 MB |
|---|
RAM
Installed Size | 64 GB (installed) / 8 TB (max) |
|---|
Technology | DDR5 SDRAM |
|---|
Form Factor | DIMM 288-pin |
|---|
Slots | 32 (Total) / 30 (empty) |
|---|
Features | Registered, HPE SmartMemory, slots 17 – 32 are available in two-processor configuration only |
|---|
Configuration Features | 2 x 32 GB |
|---|
Hard Drive
Type | SSD |
|---|
Capacity | 2 x 480 GB |
|---|
Storage Controller
Type | 1 x RAID – OCP 3.0 |
|---|
Controller Interface Type | Serial ATA-600 / SAS 3.0 / PCI Express (NVMe) |
|---|
Storage Controller Name | HPE MR408i-o Gen11 SPDM |
|---|
Channel Qty | 8 |
|---|
RAID Level | RAID 0, RAID 1, RAID 5, RAID 6, RAID 10, RAID 50, RAID 60 |
|---|
Buffer Size | 4 GB |
|---|
Optical Storage
Monitor
Graphics Controller
Video Memory | 16 MB |
|---|
Video Interfaces | VGA |
|---|
Networking
Remote Management Controller | Integrated Lights-Out 7 |
|---|
Expansion / Connectivity
Bays | 8 (total) / 6 (free) x hot-swap 2.5″ SFF |
|---|
Slots | 1 (total) / 1 (free) x PCIe 5.0 x16 – full-length, full-height (x16 mode)
1 (total) / 1 (free) x PCIe 5.0 x16 – full-length, full-height (x8 mode)
1 (total) / 1 (free) x PCIe 5.0 x16 – half-length, full-height (x8 mode)
1 (total) / 0 (free) x Open Compute Project mezzanine (OCP) 3.0 |
|---|
Interfaces | 1 x USB-C (1 in front) (HPE iLO Service Port)
3 x USB 3.2 Gen 1 (1 front, 2 rear)
2 x USB 3.0 (2 internal)
1 x HPE iLO – RJ-45 (1 rear) (management port)
1 x VGA (1 rear) |
|---|
Miscellaneous
Included Accessories | 4 standard fans |
|---|
Compliant Standards | TLS v1.2, ASHRAE Class A4, ASHRAE Class A3, WEEE 2002/95/EC, Redfish API, Active Directory v1.0, UEFI Class 3, APML, ACPI 6.5, SMBIOS 3.7, UEFI 2.10 |
|---|
Power
Device Type | Power supply – hot-plug |
|---|
Power Redundancy | Yes |
|---|
Power Redundancy Scheme | 1+1 |
|---|
Installed Qty | 2 |
|---|
Max Supported Qty | 2 |
|---|
Power Provided | 800 watt |
|---|
80 PLUS Certification | 80 PLUS Platinum |
|---|
Operating System / Software
Software | HPE iLO Standard with Intelligent Provisioning, HPE OneView Standard (free download), HPE Compute Ops Management (subscription included) |
|---|
Sustainability Information
EPEAT Compliant | EPEAT Silver |
|---|
Dimensions & Weight
Width | 44.8 cm |
|---|
Depth | 72.7 cm |
|---|
Height | 8.75 cm |
|---|
Weight | 18 kg |
|---|
Environmental Parameters
Min Operating Temperature | 10 °C |
|---|
Max Operating Temperature | 35 °C |
|---|
Humidity Range Operating | 8 – 90% RH (non-condensing) |
|---|
