Description
The Milesight Pro 7000 Series MS-N7032-G offers robust standalone NVR capabilities for secure management of video surveillance systems. With the ability to support up to 32 channels, this device can handle video recording at resolutions up to 12 megapixels, ensuring that every detail is captured clearly. Designed for flexibility, it provides extensive connectivity options, including USB 3.0, RS-485, and 10/100/1000Base-T network ports, making integration into existing setups seamless. The environmental resilience of this NVR encompasses a broad operating temperature range from -10°C to 55°C, suitable for various installations. Enhanced security features include support for multiple RAID configurations and advanced motion detection capabilities, ensuring reliable data protection and surveillance performance.
- Supports up to 32 video channels for comprehensive surveillance
- High video recording resolutions up to 12-megapixels
- Multiple RAID configurations for enhanced data security
- Robust environmental resistance with wide temperature operating range
- Extensive connectivity options including USB 3.0 and multiple network protocols
- Robust connectivity options
This NVR features a variety of ports including USB 3.0, RS-485, and network connectivity through 10/100/1000Base-T, allowing for easy integration with other devices and cameras. - Extensive video resolution capabilities
Capable of recording in various resolutions including 1920×1080 and up to 12-megapixels, this NVR ensures high-quality video capture for effective surveillance. - Advanced motion detection features
Equipped with sophisticated motion detection and analytics capabilities, this device alerts users to relevant activity, improving security response times. - Multiple RAID support for data integrity
The NVR supports various RAID levels including RAID 1, 5, and 10, which ensures protection against data loss while optimizing performance. - Environmentally resilient design
Designed to operate in challenging conditions, this NVR functions effectively in temperatures ranging from -10°C to 55°C, making it suitable for diverse environments.
Main Specifications
Product Description | Milesight Pro 7000 Series MS-N7032-G – standalone NVR – 32 channels |
Device Type | NVR – 32 channels – networked – rack-mountable – 1.5U |
IP Cameras Supported | 32 |
Frame Rate | 30 fps (playback) |
Compression Format | H.265+, H.265, H.264+, H.264, G.711, AAC, G.722, G.726 |
Image Resolution | 3840×2160, 1920×1080, 1280×1024, 1024×768, 1280×720 |
Hard Drive(s) Supported | Quantity: 4 – total capacity: 40 TB |
Voltage | 100 – 240 V |
Dimensions (WxDxH) | 44 cm x 32 cm x 6.68 cm |
Weight | 4.1 kg |
Extended Specifications
Environmental Parameters
Humidity Range Operating | 10 – 90% |
|---|
Max Operating Temperature | 55 °C |
|---|
Dimensions & Weight
Power
Hard Drive
Dimensions & Weight
General
Video Channels | 32 |
|---|
IP Cameras Supported | 32 |
|---|
Dimensions & Weight
Environmental Parameters
Min Operating Temperature | -10 °C |
|---|
Security DVR
Connections
Camera Control Interface (PTZ) | RS-485 |
|---|
Dimensions & Weight
Hard Drive
Interface | Serial ATA |
|---|
Supported Max Total Capacity | 40 TB |
|---|
Power
Security DVR
Frame Rate (Playback) | 30 fps |
|---|
Connections
Audio Input Ports | RCA x 1 |
|---|
Audio Output Ports | RCA x 1 |
|---|
Network Port | 10/100/1000Base-T |
|---|
Networking
General
Device Type | NVR – rack-mountable – 1.5U |
|---|
Power
Power Consumption Details | Without HDD |
|---|
Connections
Alarm Ports | Alarm input x 16, alarm output x 4 |
|---|
Security DVR
Record Events | Motion detection, alarm, analytics |
|---|
General
Compression Format | H.265+, H.265, H.264+, H.264, G.711, AAC, G.722, G.726 |
|---|
Security DVR
Video Recording Resolution | 12 Megapixels, 8 Megapixels, 6 Megapixels, 5 Megapixels, 4 Megapixels, 3 Megapixels, 1920×1080, 1280×720 |
|---|
General
Image Resolution | 3840×2160, 1920×1080, 1280×1024, 1024×768, 1280×720 |
|---|
Networking
Supported Protocols | ONVIF, IPv4, IPv6, TCP/IP, UDP/IP, RTP, RTSP, RTCP, HTTP, HTTPS, DNS, DDNS, DHCP, NTP, SNTP, SMTP, SNMP, UPnP, NFS |
|---|
Connections
Other Ports | USB 3.0 x 1, USB 2.0 x 2, serial RS-485 x 1, serial RS-232 x 1 |
|---|
Security DVR
Features | Dual stream support, 256 Mbps Outgoing Bandwidth, 256 Mbps Incoming Bandwidth, RAID 0 support, RAID 1 support, RAID 5 support, RAID 6 support, RAID 10 support, automatic number-plate recognition (ANPR), region entrance, region exiting, motion detection, tamper detection, Line Crossing Detection, loitering detection, people counting, object left detection, object removed detection |
|---|
