Description
The Milesight AI Motorized MS-CQ8131-FHYPG1 is designed for effective surveillance in a variety of challenging environments. With an operating temperature range from -40°C to 60°C, this camera remains functional in extreme weather conditions. Its IP67 and IK10 ratings ensure protection against dust and water, making it ideal for outdoor installations. Equipped with a high-resolution Progressive Scan CMOS sensor, it captures vivid color images at a maximum digital video resolution of 3840 x 2160, providing clarity for critical surveillance scenarios.
This network surveillance camera features an advanced lens system with a maximum focal length of 13.5 mm and a fast lens aperture of f/1.4, offering excellent low-light performance. It supports multiple network protocols, facilitating seamless connectivity through Ethernet interfaces. With built-in audio support and motion detection capabilities, the MS-CQ8131-FHYPG1 enhances monitoring efficiency while ensuring reliable performance through Power over Ethernet (PoE) capabilities.
- Operating temperature range from -40°C to 60°C
- IP67 and IK10 ratings for dust and water protection
- High-resolution image capture at 3840 x 2160
- Fast lens aperture of f/1.4 for low-light conditions
- Motion detection capability for enhanced surveillance
- Robust environmental protection
This camera is rated IP67 for water and dust protection, along with IK10 for vandal resistance, making it durable in various outdoor environments. - High-resolution imaging
Equipped with a Progressive Scan CMOS sensor, the camera delivers sharp and clear images with total pixels of 8,000,000, ensuring details are captured effectively. - Advanced lens system
The lens features a maximum focal length of 13.5 mm and a wide aperture of f/1.4, allowing the camera to perform well in different lighting situations. - Multiple network protocols
Supports a comprehensive range of networking protocols, ensuring compatibility and versatility for different monitoring applications. - Integrated audio support
This camera includes a built-in microphone, allowing for two-way audio communication, enhancing the overall surveillance capability.
Main Specifications
Product Description | Milesight AI Motorized MS-CQ8131-FHYPG1 – network surveillance camera – dome |
Device Type | Network surveillance camera – fixed – dome – vandal / weatherproof |
Audio | Yes: built-in microphone |
Dimensions (WxDxH) | 12.2 cm x 12.2 cm x 12.8 cm |
Weight | 1.1 kg |
Connectivity Technology | Wired |
Camera | Colour – Day&Night |
Max Resolution | 3840 x 2160 |
Frame Rate (max) | 30 frames per second |
Motion Detection | Yes |
Optical Sensor Type | Progressive Scan CMOS – 1/2.65″ – 8 MP |
Focal Length | 2.7 mm – 13.5 mm |
Lens Mounting | F16 mount |
Lens Iris | F/1.4 |
Interfaces | Ethernet 10Base-T/100Base-T |
Voltage | DC 12 V / PoE |
Environmental Parameters (operating) | -40 °C – 60 °C; 0 – 95% (non-condensing) relative humidity |
Documents
Extended Specifications
General
Device Type | Network surveillance camera |
|---|
Audio Support | Yes: built-in microphone |
|---|
Audio Formats | G.711, ACC, G.722, G.726 |
|---|
Form Factor | Dome |
|---|
Connectivity Technology | Wired |
|---|
Width | 12.2 cm |
|---|
Depth | 12.2 cm |
|---|
Height | 12.8 cm |
|---|
Weight | 1.1 kg |
|---|
Camera
Type | Colour – Day&Night – fixed – vandal / weatherproof |
|---|
Digital Video Format | H.265+, H.265, H.264+, H.264, MJPEG |
|---|
Max Digital Video Resolution | 3840 x 2160 |
|---|
Motion Detection | Yes |
|---|
Exposure Range | 1 sec – 1/100000 sec |
|---|
Digital Video Capture Resolution | 3840 x 2160, 3200 x 1800, 2688 x 1520, 1920 x 1080, 1280 x 720, 704 x 576, 640 x 480, 640 x 360 |
|---|
Frame Rate (max) | 30 frames per second |
|---|
Image Sensor
Type | 8 MP Progressive Scan CMOS 1/2.65″ |
|---|
Lens Construction
Type | F16 mount |
|---|
Focal Length | 2.7 mm – 13.5 mm |
|---|
Lens Iris | F/1.4 |
|---|
Interfaces
Network Interface | Ethernet 10Base-T/100Base-T |
|---|
Network Protocols | IPv4, IPv6, ARP, TCP, UDP, RTCP, RTP, RTSP, RTMP, HTTP, HTTPS, DNS, DDNS, DHCP, FTP, NTP, SMTP, SNMP, UPnP, Bonjour, SIP, PPPoE, QOS, IGMP, ICMP, SSL, NFS, SMB, CIFS |
|---|
Expansion / Connectivity
Ports | LAN/power – RJ-45 |
|---|
Supported Memory Cards | microSD Card, microSDHC Card, microSDXC Card |
|---|
Miscellaneous
Compliant Standards | IP67, IK10 |
|---|
Power
Power Requirements | DC 12 V / PoE |
|---|
Dimensions & Weight (Shipping)
Environmental Parameters
Min Operating Temperature | -40 °C |
|---|
Max Operating Temperature | 60 °C |
|---|
Relative Humidity (operating) | 0 – 95% (non-condensing) |
|---|
