Description
The Back-UPS CS provides professional-grade power protection for office and home office systems. Battery powered & surge protected power outlets, built-in phone/fax/modem line (DSL compatible) protection, safe system shutdown software with sophisticated power management features and pro-active audio-visual status indicators ensure office systems and their valuable data are protected from dangerous power surges, spikes and blackouts. Easy access to a hot-swappable, user-replaceable battery also makes servicing the Back-UPS CS hassle-free. These features along with its classic styling make the Back-UPS CS a perfect choice for protecting your important office and home office systems.
Main Specifications
Product Description | APC Back-UPS CS 500 – UPS – 300 watt – 500 VA |
Device Type | UPS – external |
Weight | 6 kg |
Load Rating | Individual PC |
Input Voltage | AC 230 V |
Output Voltage | AC 230 V ± 8% |
Power Capacity | 300 watt / 500 VA |
Input Connectors | 1 x power IEC 60320 C14 |
Output connectors | 1 x power IEC 60320 C13 (surge)
3 x power IEC 60320 C13 (UPS and surge) |
Battery | Lead Acid |
Battery Form Factor | Internal |
Batteries Qty | 1 |
Run Time (Up To) | 2.4 min at full load |
Networking | RS-232, USB |
Colour | Beige |
System Requirements | Apple MacOS 9, Apple MacOS 9.0.4 or later, Microsoft Windows 98/ME/2000/XP |
Dimensions (WxDxH) | 9.1 cm x 28.4 cm x 16.5 cm |
Documents
Extended Specifications
General
Device Type | UPS – external |
|---|
Battery Enclosure Type | Internal |
|---|
Colour | Beige |
|---|
Power Device
Load Rating | Individual PC |
|---|
UPS Technology | Off-line |
|---|
Input Voltage | AC 230 V |
|---|
Input Voltage Range | AC 196 – 280 V |
|---|
Input Voltage Range (Adjustable) | AC 160 – 300 V |
|---|
Input Voltage Margin | ± 5% |
|---|
Frequency Required | 50/60 Hz |
|---|
Input Connectors | 1 x power IEC 60320 C14 |
|---|
Power Output Connectors Details | 1 x power IEC 60320 C13 (surge)
3 x power IEC 60320 C13 (UPS and surge) |
|---|
Output Voltage | AC 230 V ± 8% |
|---|
Power Capacity | 300 watt / 500 VA |
|---|
Dataline Surge Protection | Phone line – RJ-11 |
|---|
Output Waveform | Stepped approximation to a sinewave |
|---|
Surge Suppression | Yes |
|---|
Surge Energy Rating | 300 joules |
|---|
Circuit Protection | Circuit breaker |
|---|
Battery
Quantity | 1 |
|---|
Technology | Lead Acid |
|---|
Run Time (Up To) | 2.4 min at full load |
|---|
Recharge Time | 8 hours |
|---|
Networking
Remote Management Interface | RS-232, USB |
|---|
Expansion / Connectivity
Interfaces | 1 x management (RS-232/USB) – RJ-45 |
|---|
Miscellaneous
Cables Included | USB cable – external |
|---|
Equipment Protection Value | 100000 Euros |
|---|
Features | LED display, audible alarm |
|---|
Compliant Standards | C-Tick, GOST, UL 1449, VDE, EN 50091-2, EN 50091-1 |
|---|
Software / System Requirements
Software Included | APC PowerChute Personal Edition |
|---|
OS Required | Apple MacOS 9, Apple MacOS 9.0.4 or later, Microsoft Windows 98/ME/2000/XP |
|---|
Environmental Parameters
Min Operating Temperature | 0 °C |
|---|
Max Operating Temperature | 40 °C |
|---|
Min Storage Temperature | -15 °C |
|---|
Max Storage Temperature | 45 °C |
|---|
Humidity Range Operating | 0 – 95% |
|---|
Humidity Range Storage | 0 – 95% |
|---|
Sound Emission | 40 dBA |
|---|
Dimensions & Weight
Width | 9.1 cm |
|---|
Depth | 28.4 cm |
|---|
Height | 16.5 cm |
|---|
Weight | 6 kg |
|---|
Dimensions & Weight (Shipping)
Shipping Width | 24.1 cm |
|---|
Shipping Depth | 36.8 cm |
|---|
Shipping Height | 17.8 cm |
|---|
Shipping Weight | 7.1 kg |
|---|
