Description
Do you need a reliable enterprise-class tower server that can easily meet your budget? The HPE ProLiant ML30 Gen11 Plus server is a powerful yet affordable tower server designed for small offices, remote and branch offices to run on-premises and hybrid cloud solutions, delivering enterprise-class performance, security, reliability, and expandability at a low cost. Hewlett Packard Enterprise builds security right into the server with HPE iLO silicon root of trust. A redundant power supply option and up to 4 LFF or 8 SFF hot-plug HDDs provide availability and flexibility. The enhanced expansion capability, now including PCIe Gen5, allows you to upgrade with serial attached SCSI (SAS) controllers or networking cards as your business grows, which can give you an extra edge. Power your business now with an HPE ProLiant ML30 Gen11 server.
- The HPE ProLiant ML30 Gen11 server is powered by up to 8 cores Intel Xeon E Processor and up to 128 GB 4400 MT/s DDR5 ECC UDIMM, delivering abundant performance for small- to mid-sized business applications.
- The HPE ProLiant ML30 Gen11 server offers flexibility in different storage needs. With a choice of 4 Large Form Factor (LFF) non-hot-plug, hot-plug, or 8 Small Form Factor (SFF) hot-plug drive options, you can find a right fit for your growing business.
- The HPE ProLiant ML30 Gen11 protects your business with innovations in firmware protection, malware detection, and firmware recovery — right down to the silicon.
- The HPE ProLiant ML30 Gen11 server simplifies and automates management tasks, establishing a solid foundation for a hybrid cloud platform enabled by automation.
- Powerful Yet Affordable Server for Your Daily Office Workloads
The HPE ProLiant ML30 Gen11 server is powered by up to 8 cores Intel Xeon E Processor and up to 128 GB 4400 MT/s DDR5 ECC UDIMM, delivering abundant performance for small- to mid-sized business applications.
With up to 80 TB storage capacity, the HPE ProLiant ML30 Gen11 is an ideal data storage platform allowing your business to accommodate an increasing amount of data as you grow. An onboard M.2 slot with NVMe SSD support delivers outstanding speed for a boot drive.
An optional dedicated HPE iLO port allows you to dedicate more bandwidth to network functions and achieve higher network speeds.
The embedded Intel VROC SATA software RAID ships standard, and the HPE Smart Array essentials and performance controllers allow you the flexibility to choose the 12Gbps controller best suited to your environment.
Four expansion slots for more flexible usage, including one PCIe Gen5 x16 for increased bandwidth. - A Variety of Enterprise-Class Features to Achieve Business Growth with Low TCO
The HPE ProLiant ML30 Gen11 server offers flexibility in different storage needs. With a choice of 4 Large Form Factor (LFF) non-hot-plug, hot-plug, or 8 Small Form Factor (SFF) hot-plug drive options, you can find a right fit for your growing business.
The selective HPE 500W, 800W and 1000W Flex Slot redundant power supplies enhance the reliability, and lets you share spares across multiple server platforms.
The HPE ProLiant ML30 Gen11 server offers a complete set of embedded HPE Integrated Lights Out (iLO 6) management features. - Security Innovations
The HPE ProLiant ML30 Gen11 protects your business with innovations in firmware protection, malware detection, and firmware recovery – right down to the silicon.
Millions of lines of firmware code run before the server operating system boots. Runtime firmware validation, enabled by HPE iLO Advanced Premium Security Edition, checks the server firmware every 24 hours verifying the validity and credibility of essential system firmware.
Secure recovery allows server firmware to roll back to the last known-good state or to factory settings after the detection of compromised code.
The HPE Trusted Platform Module (TPM) works to increase data security by storing the encryption startup key in hardware on the server, providing a more secure environment. - Intelligent Management Automation
The HPE ProLiant ML30 Gen11 server simplifies and automates management tasks, establishing a solid foundation for a hybrid cloud platform enabled by automation.
Embedded in Hewlett Packard Enterprise servers, HPE Integrated Lights-Out (iLO) is an exclusive core intelligence that monitors server status, providing the means for reporting, ongoing management, service alerting, and local or remote management to quickly identify and resolve issues.
Automation and software-defined control reduce time spent on provisioning and maintenance, as well as reduce deployment times.
What’s in the Box
- HPE ProLiant ML30 Gen11 Performance
- Non-hot plug non-redundant system fan
Main Specifications
Product Description | HPE ProLiant ML30 Gen11 Performance – tower Xeon E-2434 3.4 GHz – 16 GB – no HDD |
Type | Server – tower |
Height (Rack Units) | 4U |
Server Scalability | 1-way |
Processor | 1 x Intel Xeon E-2434 / 3.4 GHz (up to 5 GHz, (Quad-Core) |
Processor Main Features | Intel Smart Cache |
Cache Memory | 12 MB L3 Cache |
Cache Per Processor | 12 MB |
RAM | 16 GB (installed) / 128 GB (max) – DDR5 SDRAM – ECC |
Storage Controller | SATA (SATA 6Gb/s) (Intel VROC SATA Software RAID) |
Server Storage Bays | Hot-swap 2.5″ |
Hard Drive | No HDD |
Optical Storage | No optical drive |
Video Memory | 16 MB |
Networking | 1GbE |
Power Redundancy | Optional |
Software Included | HPE iLO Standard with Intelligent Provisioning, HPE OneView Standard (free download) |
Dimensions (WxDxH) | 17.53 cm x 47.5 cm x 36.83 cm |
Weight | 10.2 kg |
Environmental Standards | ENERGY STAR Qualified EPEAT Bronze |
Documents
Extended Specifications
General
Type | Server |
|---|
Product Form Factor | Tower – 4U |
|---|
Built-in Devices | Led panel |
|---|
Embedded Security | Trusted Platform Module (TPM 2.0) Security Chip |
|---|
Server Scalability | 1-way |
|---|
Hot-Swap Bays Qty | 8 |
|---|
Processor / Chipset
CPU | Intel Xeon E-2434 |
|---|
Clock Speed | 3.4 GHz |
|---|
Max Turbo Speed | 5 GHz |
|---|
Number of Cores | Quad-Core |
|---|
CPU Qty | 1 |
|---|
Max CPU Qty | 1 |
|---|
CPU Upgradability | Upgradable |
|---|
Processor Main Features | Intel Smart Cache |
|---|
Chipset Type | Intel C262 |
|---|
Cache Memory
Installed Size | L3 Cache – 12 MB |
|---|
Cache Per Processor | 12 MB |
|---|
RAM
Installed Size | 16 GB (installed) / 128 GB (max) |
|---|
Technology | DDR5 SDRAM – ECC |
|---|
Effective Memory Speed | 4800 MHz |
|---|
Rated Memory Speed | 4800 MHz |
|---|
Form Factor | DIMM 288-pin |
|---|
Slots | 4 (Total) / 3 (empty) |
|---|
Features | Unbuffered, HPE Standard Memory |
|---|
Configuration Features | 1 x 16 GB |
|---|
Hard Drive
Storage Controller
Type | 1 x SATA |
|---|
Controller Interface Type | SATA 6Gb/s |
|---|
Storage Controller Name | Intel VROC SATA Software RAID |
|---|
RAID Level | RAID 0, RAID 1, RAID 5, RAID 10 |
|---|
Optical Storage
Monitor
Graphics Controller
Video Memory | 16 MB |
|---|
Video Interfaces | VGA, DisplayPort |
|---|
Networking
Ethernet Ports | 4 x Gigabit Ethernet |
|---|
Data Link Protocol | Ethernet, Fast Ethernet, Gigabit Ethernet |
|---|
Remote Management Controller | Integrated Lights-Out 6 |
|---|
Features | Wake on LAN (WoL), PXE support |
|---|
Expansion / Connectivity
Bays | 8 (total) / 8 (free) x hot-swap 2.5″ SFF |
|---|
Slots | 1 (total) / 1 (free) x PCIe 5.0 x16 – full-length, full-height (x16 mode, processor)
1 (total) / 1 (free) x PCIe 4.0 x8 – full-length, full-height (x4 mode, processor)
2 (total) / 2 (free) x PCIe 4.0 x8 – half-length, full-height (x4 mode, PCH)
1 (total) / 1 (free) x M.2 Card |
|---|
Interfaces | 1 x DisplayPort
1 x VGA
3 x LAN (Gigabit Ethernet) – RJ-45 (3 rear)
1 x HPE iLO – Type A (1 front) (service port)
5 x USB 3.2 Gen 1 (1 front, 4 rear)
1 x LAN (Gigabit Ethernet) / HPE iLO – RJ-45 (1 rear) |
|---|
Miscellaneous
Included Accessories | Non-hot plug non-redundant system fan |
|---|
Theft/Intrusion Protection | Security lock slot (cable lock sold separately), padlock eye |
|---|
Security Slot Type | Kensington security slot |
|---|
Compliant Standards | AES, Triple DES, TLS v1.2, ASHRAE Class A4, ASHRAE Class A3, Redfish API, ACPI 6.3, Active Directory v1.0, UEFI 2.9, EU Lot 9 |
|---|
Power
Device Type | Power supply – hot-plug |
|---|
Power Redundancy | Optional |
|---|
Power Redundancy Scheme | 1+1 (with optional power supply) |
|---|
Installed Qty | 1 |
|---|
Max Supported Qty | 2 |
|---|
Power Provided | 500 watt |
|---|
80 PLUS Certification | 80 PLUS Platinum |
|---|
Operating System / Software
Software | HPE iLO Standard with Intelligent Provisioning, HPE OneView Standard (free download) |
|---|
Sustainability Information
EPEAT Compliant | EPEAT Bronze |
|---|
ENERGY STAR Certified | Yes |
|---|
ENERGY STAR Version | 4.0 |
|---|
Dimensions & Weight
Width | 17.53 cm |
|---|
Depth | 47.5 cm |
|---|
Height | 36.83 cm |
|---|
Weight | 10.2 kg |
|---|
Environmental Parameters
Min Operating Temperature | 10 °C |
|---|
Max Operating Temperature | 35 °C |
|---|
Humidity Range Operating | 8 – 90% RH (non-condensing) |
|---|
Sound Emission | 24 dBA |
|---|
