Description
The HPE ProLiant DL360 Gen12 is a rack-mountable server designed for performance and flexibility in demanding environments. With 10 hot-swap bays and support for 2.5″ swappable drives, this server offers storage capabilities, ensuring quick and easy replacement of components without downtime. It also features advanced connectivity options, including multiple USB and Ethernet ports, facilitating management and integration into existing systems. The integrated Lights-Out 7 controller enhances remote management, making it easier to monitor and maintain server operations from virtually anywhere.
Designed to operate in a range of environmental conditions, the HPE ProLiant DL360 Gen12 supports temperatures from 10°C to 35°C and operates effectively in humidity levels between 8% and 90% RH. Its robust build meets various compliance standards, including ENERGY STAR and AES, ensuring the server’s performance aligns with regulatory requirements. With expandable options including PCIe 5.0 slots and support for up to 32 DIMM slots, this server is built to grow alongside organizational needs, providing a reliable and secure computing environment.
- Rack-mountable design for efficient space management
- 10 hot-swap bays for quick drive replacement
- Integrated Lights-Out 7 for enhanced remote management
- Supports multiple connectivity options for versatile integration
- Robust compliance standards ensuring reliability and security
- Flexible storage capacity
With 10 hot-swap bays, the HPE ProLiant DL360 Gen12 provides flexibility in storage management, allowing for quick drive replacement and expansion as needed. - Efficient environmental operation
This server is designed to function effectively across a wide range of operating conditions, supporting temperatures from 10°C to 35°C and a humidity range of 8% to 90% RH. - Expanded expansion options
The inclusion of 2 PCIe 5.0 x16 slots offers room for graphical and networking enhancements, catering to changing technological needs. - Enhanced management capabilities
Integrated Lights-Out 7 technology allows for comprehensive remote management, enabling system monitoring and troubleshooting from any location. - Robust security features
Equipped with a Trusted Platform Module (TPM 2.0) security chip, the HPE ProLiant DL360 Gen12 ensures that data integrity and security remain a priority.
Main Specifications
Product Description | HPE ProLiant Compute DL360 Gen12 – rack-mountable Xeon 6505P 2.2 GHz – 64 GB – no HDD |
Type | Server – rack-mountable |
Height (Rack Units) | 1U |
Server Scalability | 1-way |
Processor | 1 x Intel Xeon 6505P / 2.2 GHz (up to 4.1 GHz, (12-core) |
Processor Main Features | Hyper-Threading Technology, Intel Turbo Boost Technology 2, 24 Threads, 150W TDP |
Cache Memory | 48 MB L3 Cache |
Cache Per Processor | 48 MB |
RAM | 64 GB DDR5 SDRAM |
Storage Controller | (Intel VROC NVMe Software RAID) |
Server Storage Bays | Hot-swap 2.5″ |
Hard Drive | No HDD |
Optical Storage | No optical drive |
Video Memory | 16 MB |
Power Redundancy | Optional |
OS Provided | No operating system |
Dimensions (WxDxH) | 43.46 cm x 77.31 cm x 4.29 cm |
Environmental Standards | EPEAT Silver |
Extended Specifications
General
Type | Server |
|---|
Product Form Factor | Rack-mountable – 1U |
|---|
Built-in Devices | Led panel |
|---|
Embedded Security | Trusted Platform Module (TPM 2.0) Security Chip |
|---|
Server Scalability | 1-way |
|---|
Hot-Swap Bays Qty | 10 |
|---|
Processor / Chipset
CPU | Intel Xeon 6505P |
|---|
Clock Speed | 2.2 GHz |
|---|
Max Turbo Speed | 4.1 GHz |
|---|
Number of Cores | 12-core |
|---|
CPU Qty | 1 |
|---|
Max CPU Qty | 1 |
|---|
CPU Upgradability | Upgradable |
|---|
Processor Main Features | Hyper-Threading Technology, Intel Turbo Boost Technology 2, 24 Threads, 150W TDP |
|---|
Cache Memory
Installed Size | L3 Cache – 48 MB |
|---|
Cache Per Processor | 48 MB |
|---|
RAM
Installed Size | 64 GB |
|---|
Technology | DDR5 SDRAM |
|---|
Effective Memory Speed | 6400 MT/s |
|---|
Rated Memory Speed | 6400 MT/s |
|---|
Form Factor | DIMM 288-pin |
|---|
Slots | 32 (Total) / 30 (empty) |
|---|
Features | Registered, HPE SmartMemory, slots 17 – 32 are available in two-processor configuration only |
|---|
Configuration Features | 2 x 32 GB |
|---|
Hard Drive
Storage Controller
Type | 1 |
|---|
Storage Controller Name | Intel VROC NVMe Software RAID |
|---|
Optical Storage
Monitor
Graphics Controller
Video Memory | 16 MB |
|---|
Video Interfaces | VGA |
|---|
Networking
Remote Management Controller | Integrated Lights-Out 7 |
|---|
Expansion / Connectivity
Bays | 10 (total) / 10 (free) x hot-swap 2.5″ SFF / 2 x EDSFF shared |
|---|
Slots | 3 (total) / 3 (free) x PCIe 5.0 x16
2 (total) / 2 (free) x Open Compute Project mezzanine (OCP) 3.0 |
|---|
Interfaces | 1 x HPE iLO – Type C (1 in front) (service port)
1 x management (Gigabit Ethernet) – RJ-45 (1 front) (HPE iLO Service Port)
5 x USB 3.2 Gen 1 – Type A (1 front, 2 rear, 2 internal)
1 x VGA (1 rear) |
|---|
Miscellaneous
Compliant Standards | AES, Triple DES, TLS v1.2, ASHRAE Class A4, ASHRAE Class A3, Redfish API, ErP Lot 9, Energy Star, ACPI 6.4, SMBIOS 3.4, Active Directory v1.0 |
|---|
Power
Device Type | Power supply – hot-plug |
|---|
Power Redundancy | Optional |
|---|
Power Redundancy Scheme | 1+1 (with optional power supply) |
|---|
Installed Qty | 2 |
|---|
Max Supported Qty | 2 |
|---|
Power Provided | 800 watt |
|---|
Operating System / Software
OS Provided | No operating system |
|---|
Sustainability Information
EPEAT Compliant | EPEAT Silver |
|---|
Dimensions & Weight
Width | 43.46 cm |
|---|
Depth | 77.31 cm |
|---|
Height | 4.29 cm |
|---|
Environmental Parameters
Min Operating Temperature | 10 °C |
|---|
Max Operating Temperature | 35 °C |
|---|
Humidity Range Operating | 8 – 90% RH (non-condensing) |
|---|
