Description
The TP-Link VIGI C540-4G V1 network surveillance camera is engineered for precision and durability, offering a comprehensive solution for outdoor monitoring. With its robust environmental adaptability, it operates flawlessly in temperatures ranging from -30 °C to 60 °C and withstands humidity up to 95%, making it an ideal choice for any location. The camera’s optical system, featuring a wide angular field of view and a large aperture lens, captures clear and detailed images. Nighttime security is enhanced with infrared LEDs, providing visibility up to 30 m in complete darkness. Connectivity is a strong suit of the VIGI C540-4G V1, supporting a variety of network interfaces and protocols for easy integration into existing systems. It also offers flexible installation options, thanks to its compatibility with both wired and wireless networks. The camera’s intelligent surveillance capabilities, including two-way audio, smart detection, and intrusion alerts, empower users to respond promptly to any security challenges. With its comprehensive feature set and reliable performance, the TP-Link VIGI C540-4G V1 is a versatile and effective choice for safeguarding your premises.
- Outdoor weatherproof design for reliable operation in any climate
- 4 million total pixels CMOS sensor for high-quality images
- Supports both wired and wireless connectivity for flexible installation
- Two-way audio capability for interactive surveillance
- Smart IR technology for clear night vision up to 30 m
- Robust environmental adaptability
Designed to withstand extreme temperatures ranging from -30 °C to 60 °C and humidity up to 95% (non-condensing), ensuring reliable operation in any weather condition. - Advanced optical performance
Features a high-quality lens with a wide angular field of view (94° diagonal, 80° horizontal, 43° vertical) and a large aperture of f/1.6, providing clear and broad coverage. - Enhanced night vision
Equipped with infrared LEDs and capable of illuminating up to 30 m, this camera ensures detailed monochrome images under zero-light conditions, with a minimum illumination of 0 lux. - Comprehensive connectivity
Supports a wide range of network interfaces including 4G, LTE, WCDMA, and Ethernet, alongside various network protocols, offering flexible and secure options for remote access and monitoring. - Intelligent surveillance features
Boasts functionalities such as two-way audio capability, smart detection, human and vehicle filtering, and intrusion detection, enhancing security and operational efficiency.
Main Specifications
Product Description | TP-Link VIGI C540-4G V1 – network surveillance camera – turret |
Device Type | Network surveillance camera – pan / tilt – turret – outdoor – weatherproof |
Audio | Yes: built-in speaker, built-in microphone, two-way audio capability |
Camera Mount Type | Wall mount, ceiling mount, pole mount |
Dimensions (WxDxH) | 12 cm x 18.2 cm x 20.1 cm |
Weight | 690 g |
Connectivity Technology | Wired, wireless |
Camera | Colour – Day&Night |
Max Resolution | 2560 x 1440 |
Frame Rate (max) | 30 frames per second |
Motion Detection | Yes |
Optical Sensor Type | CMOS – 1/3.06″ – 4 MP |
Minimum Illumination | 0.005 lux – colour
0 lux – white light |
Focal Length Control | Fixed focal |
Focal Length | 4 mm |
Lens Mounting | M12 mount |
Lens Iris | F/1.6 |
Panning Range (degree) | 0 to 348 |
Tilting Range (degree) | 0 to 120 |
Interfaces | 4G, Ethernet 10Base-T/100Base-TX, LTE, WCDMA |
Voltage | DC 12 V |
Features | Backlight Compensation (BLC), sharpness control, saturation control, brightness control, contrast control, image mirror, Wide Dynamic Range (WDR), ONVIF support, Privacy Mask Function, Digital Wide Dynamic Range (D-WDR), programmable white balance, Smart IR, reset button, password protection, auto tracking, 2-way voice communication, Region of Interest (ROI), intrusion detection, exposure control, plastic housing, digest authentication, Line Crossing Detection, IP address filtering, 3D digital noise reduction (DNR), Zoom compatible, HTTPs encryption, human detection, Smart Detection, instant notification, PoE support, password reset via e-mail, 2 video streams, video tampering detection, human and vehicle filtering, slow shutter, Nano-Sim card slot, Constant Bitrate (CBR), Variable Bitrate (VBR) |
Environmental Parameters (operating) | -30 °C – 60 °C; up to 95% (non-condensing) relative humidity |
Extended Specifications
General
Device Type | Network surveillance camera |
|---|
Audio Support | Yes: built-in speaker, built-in microphone, two-way audio capability |
|---|
Audio Formats | G.711 A-law |
|---|
Form Factor | Turret |
|---|
Camera Mount Type | Wall mount, ceiling mount, pole mount |
|---|
Connectivity Technology | Wired, wireless |
|---|
Width | 12 cm |
|---|
Depth | 18.2 cm |
|---|
Height | 20.1 cm |
|---|
Weight | 690 g |
|---|
Camera
Type | Colour – Day&Night – pan / tilt – outdoor – weatherproof |
|---|
Digital Video Format | H.264, H.265, H.265+, H.264+ |
|---|
Max Digital Video Resolution | 2560 x 1440 |
|---|
Motion Detection | Yes |
|---|
Exposure Range | 1/3 sec – 1/10000 sec |
|---|
Minimum Illumination | 0.005 lux – colour
0 lux – white light |
|---|
Infrared LEDs | Yes |
|---|
Infrared Distance | 30 m |
|---|
Digital Video Capture Resolution | 320 x 240, 352 x 288, 640 x 480, 1280 x 720, 1920 x 1080, 2048 x 1280, 2304 x 1296, 2560 x 1440 |
|---|
Frame Rate (max) | 30 frames per second |
|---|
Features | Backlight Compensation (BLC), sharpness control, saturation control, brightness control, contrast control, image mirror, Wide Dynamic Range (WDR), ONVIF support, Privacy Mask Function, Digital Wide Dynamic Range (D-WDR), programmable white balance, Smart IR, reset button, password protection, auto tracking, 2-way voice communication, Region of Interest (ROI), intrusion detection, exposure control, plastic housing, digest authentication, Line Crossing Detection, IP address filtering, 3D digital noise reduction (DNR), Zoom compatible, HTTPs encryption, human detection, Smart Detection, instant notification, PoE support, password reset via e-mail, 2 video streams, video tampering detection, human and vehicle filtering, slow shutter, Nano-Sim card slot, Constant Bitrate (CBR), Variable Bitrate (VBR) |
|---|
Image Sensor
Lens Construction
Type | M12 mount – fixed focal |
|---|
Focal Length | 4 mm |
|---|
Lens Iris | F/1.6 |
|---|
Horizontal Field of View (degree) | 80 |
|---|
Vertical Field of View (degree) | 43 |
|---|
Diagonal Field of View (degree) | 94 |
|---|
Panning
Tilting
Interfaces
Network Interface | 4G, Ethernet 10Base-T/100Base-TX, LTE, WCDMA |
|---|
Network Protocols | DHCP, DNS, HTTP, NTP, TCP/IP, UDP/IP, ICMP, RTSP, HTTPS, UPnP, TLS, SSL |
|---|
Expansion / Connectivity
Ports | LAN – RJ-45 |
|---|
Supported Memory Cards | microSD Card |
|---|
Miscellaneous
Included Accessories | Mounting hardware, waterproof cable attachments |
|---|
Compliant Standards | RCM, BSMI, RoHS, NCC |
|---|
Power
Power Requirements | DC 12 V |
|---|
Dimensions & Weight (Shipping)
Environmental Parameters
Min Operating Temperature | -30 °C |
|---|
Max Operating Temperature | 60 °C |
|---|
Relative Humidity (operating) | Up to 95% (non-condensing) |
|---|
