Edge-Core ECS1100 Series, Switch, smart, 8 x 10/100/1000 (PoE Class 8) + 2 x 1 Gigabit SFP, rack-mountable, PoE Class 8 (250 W)
$130.36 inc GST
✓ In Stock - 1 available
✓ Free NZ Delivery
1 in stock (can be backordered)
- Allow 1–2 days for delivery to the North Island
- Allow 2–3 days for delivery to the South Island
- Add 1–2 days if you are rural
- Collection can be arranged
Description
The Edge-Core ECS1100 Series switch is engineered to meet the demands of modern networks, offering a blend of performance, flexibility, and reliability. With a 20 Gbps switching capacity and a 14.9 Mpps forwarding rate, it ensures smooth and efficient data transmission across the network. This switch is equipped with 8 PoE (Power over Ethernet) ports, supporting up to 250 W of power budget, allowing for the direct powering of devices over the network, which simplifies the infrastructure and reduces installation costs. Additionally, it features advanced networking capabilities including VLAN support, Quality of Service (QoS), and port mirroring, enabling sophisticated network management and optimization. The Edge-Core ECS1100 Series is designed for durability, boasting an MTBF (Mean Time Between Failures) of 200,000 hours, and adheres to multiple safety and operational standards, ensuring its reliability in various environments. Whether for small businesses or large enterprises, this switch offers a comprehensive solution for building efficient, secure, and scalable networks.
- 20 Gbps switching capacity for high-speed data processing
- 10 ports including 8 PoE Class 8 for flexible connectivity
- 250 W PoE budget to power devices directly through network cables
- Comprehensive network management features for optimized performance
- 200,000 hours MTBF for long-term reliability
- Robust performance
With a switching capacity of 20 Gbps and a forwarding rate of 14.9 Mpps, this switch ensures efficient data flow and high-speed connectivity for all connected devices. - Enhanced connectivity
Equipped with 8 10/100/1000 (PoE Class 8) ports and 2 1 Gigabit SFP ports, the Edge-Core ECS1100 Series offers versatile connection options for a wide range of devices. - Advanced networking features
Features such as VLAN support, QoS, and port mirroring enable sophisticated network management and optimization, ensuring reliable and secure data transmission. - Durable and reliable
Designed for longevity with an MTBF of 200,000 hours and compliance with multiple safety standards, this switch is built to withstand rigorous use in various environments. - Power over Ethernet
With a generous PoE budget of 250 W, this switch can power multiple devices over the network, reducing the need for additional power supplies and simplifying installations.
Main Specifications
Product Description | Edge-Core ECS1100 Series – switch – 10 ports – smart – rack-mountable |
Device Type | Switch – 10 ports – smart |
Enclosure Type | Rack-mountable |
Subtype | Gigabit Ethernet |
Ports | 8 x 10/100/1000 (PoE Class 8) + 2 x 1 Gigabit SFP |
Power Over Ethernet (PoE) | PoE Class 8 |
PoE Budget | 250 W |
Performance | Switching capacity: 20 Gbps Forwarding rate: 14.9 Mpps |
Capacity | Packet buffer size: 4 Mbit |
MAC Address Table Size | 8K entries |
Jumbo Frame Support | 15KB |
Routing Protocol | IGMPv2, IGMP |
Remote Management Protocol | Web GUI |
Features | Auto-negotiation, VLAN support, auto-uplink (auto MDI/MDI-X), IGMP snooping, port mirroring, Broadcast Storm Control, Multicast Storm Control, firmware upgradable, LACP support, DHCP client, port isolation, IP source guard, rate limit, DDM, PoE timer, dynamic power allocation, Unknown Storm Control, VLAN trunking, DDoS Protection, NTP support, PD-Alive, ecCLOUD support, WRR queuing, QoS |
Compliant Standards | IEEE 802.3, IEEE 802.3u, IEEE 802.3z, IEEE 802.3ab, IEEE 802.3af, IEEE 802.3x, IEEE 802.3at, IEEE 802.3bt |
Power | AC 100-240 V (50/60 Hz) |
Dimensions (WxDxH) | 29.4 cm x 18 cm x 4.4 cm |
Weight | 1.56 kg |
Extended Specifications
General
Device Type | Switch – 10 ports – smart |
|---|---|
Enclosure Type | Rack-mountable |
Subtype | Gigabit Ethernet |
Ports | 8 x 10/100/1000 (PoE Class 8) + 2 x 1 Gigabit SFP |
Power Over Ethernet (PoE) | PoE Class 8 |
PoE Budget | 250 W |
Performance | Switching capacity: 20 Gbps Forwarding rate: 14.9 Mpps |
Capacity | Packet buffer size: 4 Mbit |
MAC Address Table Size | 8K entries |
Jumbo Frame Support | 15KB |
Routing Protocol | IGMPv2, IGMP |
Remote Management Protocol | Web GUI |
Features | Auto-negotiation, VLAN support, auto-uplink (auto MDI/MDI-X), IGMP snooping, port mirroring, Broadcast Storm Control, Multicast Storm Control, firmware upgradable, LACP support, DHCP client, port isolation, IP source guard, rate limit, DDM, PoE timer, dynamic power allocation, Unknown Storm Control, VLAN trunking, DDoS Protection, NTP support, PD-Alive, ecCLOUD support, WRR queuing, QoS |
Compliant Standards | IEEE 802.3, IEEE 802.3u, IEEE 802.3z, IEEE 802.3ab, IEEE 802.3af, IEEE 802.3x, IEEE 802.3at, IEEE 802.3bt |
RAM | 256 KB |
Flash Memory | 8 MB |
Expansion / Connectivity
Interfaces | 8 x 1000Base-T RJ-45 2 x 1000Base-SX/LX/LHX/ZX SFP |
|---|
Power
Power Device | Internal power supply |
|---|---|
Voltage Required | AC 100-240 V (50/60 Hz) |
Power Consumption Operational | 270 Watt |
Miscellaneous
MTBF | 200,000 hours |
|---|---|
Compliant Standards | VCCI, BSMI, LVD, EN 62368-1, IEC/EN 62368-1, UKCA, FCC-A |
Dimensions & Weight
Width | 29.4 cm |
|---|---|
Depth | 18 cm |
Height | 4.4 cm |
Weight | 1.56 kg |
Environmental Parameters
Min Operating Temperature | 0 °C |
|---|---|
Max Operating Temperature | 50 °C |
Humidity Range Operating | 10 – 90% (non-condensing) |
Min Storage Temperature | -40 °C |
Max Storage Temperature | 70 °C |
Humidity Range Storage | 10 – 90% (non-condensing) |
