Description
Security never shuts down. 4-channel PoE network video recorder.
- 4K HDMI video output and 16MP decoding capacity
- Dedicated 4 PoE+ ports for simplified IP camera deployment
- Simple HDD installation
- 4-channel simultaneous playback
- More compression, more savings
- Two-way audio
- 4K HDMI video output and 16MP decoding capacity
Sharp image definition up to 8MP and a 4-channel display ensure you capture every detail, from every angle. - Dedicated 4 PoE+ ports for simplified IP camera deployment
Features 4x 10/100 Mbps PoE+ ports, the NVR supports up to 30 W on each PoE+ port. Designed to use a single Ethernet cable for both data and power transmission, it offers flexible installation to fit in various surveillance scenarios for small businesses, such as groceries, warehouses, restaurants, and financial institutions. - Simple HDD installation
Install and remove the HDD manually with easy side access. - 4-channel simultaneous playback
Replay the feed from up to 4 cameras at the same time, increase replay speed, and find events in the video schedule to easily review footage. - More compression, more savings
Without using any extra bandwidth, your cameras transmit compressed crystal-clear video to save disk space, ease network loads, and reduce monitoring costs without sacrificing image quality. - Two-way audio
With voice intercom support, carry two-way conversations while watching your feed from anywhere. Suitable for management.
What’s in the Box
- VIGI NVR1104H-4P V1
- Mouse, HDD screws
Main Specifications
Product Description | TP-Link VIGI NVR1104H-4P V1 – standalone NVR – 4 channels |
Device Type | NVR – 4 channels – networked |
IP Cameras Supported | 4 |
Compression Format | H.265+, H.265, H.264+, H.264 |
Image Resolution | 3840×2160, 1920×1080, 1680×1050, 1440×900, 1280×1024, 1024×768, 1280×720 |
Hard Drive(s) Supported | Quantity: 1 – total capacity: 10 TB |
Voltage | 53.5 V |
Dimensions (WxDxH) | 20.03 cm x 20.03 cm x 4.3 cm |
Extended Specifications
General
Device Type | NVR |
|---|
Video Channels | 4 |
|---|
IP Cameras Supported | 4 |
|---|
Image Resolution | 3840×2160, 1920×1080, 1680×1050, 1440×900, 1280×1024, 1024×768, 1280×720 |
|---|
Compression Format | H.265+, H.265, H.264+, H.264 |
|---|
Package Content | HDD screws, mouse |
|---|
Compliant Standards | IEEE 802.3af, IEEE 802.3at, Plug and Play |
|---|
Security DVR
Networked | Yes |
|---|
Features | 80 Mbps Incoming Bandwidth, 60 Mbps Outgoing Bandwidth, built-in speaker |
|---|
Hard Drive
Quantity Supported | 1 |
|---|
Interface | Serial ATA |
|---|
Removable | Yes |
|---|
Supported Max Total Capacity | 10 TB |
|---|
Video Server
Features | Two-way audio support |
|---|
Networking
Network Interfaces | Ethernet 10Base-T/100Base-TX |
|---|
Supported Protocols | TCP/IP, DHCP, DNS, NTP, UPnP, HTTP, HTTPS |
|---|
Features | 53W PoE+ power budget, ONVIF support, remote access management |
|---|
Connections
Video Input Ports | RJ-45 x 4 |
|---|
Video Output Ports | HDMI x 1, VGA x 1 |
|---|
Audio Input Ports | RCA x 1 |
|---|
Audio Output Ports | RCA x 1 |
|---|
Network Port | 10/100Base-T |
|---|
Other Ports | USB 2.0 x 2 |
|---|
Power
Voltage | 53.5 V |
|---|
Power Consumption | 4.82 watt |
|---|
Power Consumption Details | Without HDD |
|---|
Dimensions & Weight
Width | 20.03 cm |
|---|
Depth | 20.03 cm |
|---|
Height | 4.3 cm |
|---|
Environmental Parameters
Min Operating Temperature | -10 °C |
|---|
Max Operating Temperature | 55 °C |
|---|
