Description
Combining a flatbed scanner with the convenience of a 50-page ADF makes it possible to scan a wide range of challenging documents, including books, bound documents, passports and delicate items while quickly and simply scanning stacks of office documents. Its small footprint makes it easy to position in front office and customer-facing environments, as well as back office workgroups.
- Scan a wide range of documents: including books, bound documents, passports and delicate items
- Intelligent color and image adjustments: auto crop, skew correction, blank page and background removal
- USB 3.0 connectivity: no slow down, even when scanning at 300 dpi high resolution
- Intelligent features
Smart color and image adjustments, including auto crop, skew correction, blank page and background removal, with Epson’s Image Processing technology. With long document mode it’s possible scan over three meters (3048 mm) of paper single sided. - Boost your office efficiency
This is a fast scanner with a 25 ppm scan speed. USB 3.0 connectivity means there is no slow down, even when scanning at 300 dpi high resolution. Scan both sides of a page with double-sided scanning capability for greater convenience.
What’s in the Box
- Epson WorkForce DS-1630
- Drivers & Utilities, ABBYY FineReader, NewSoft Presto! PageManager, EPSON Document Capture Pro, EPSON Scan 2
Main Specifications
Product Description | Epson WorkForce DS-1630 – document scanner – desktop – USB 3.0 |
Device Type | Document scanner – desktop |
Interface Type | USB 3.0 |
Scanning Sensor Type | Contact Image Sensor (CIS) |
Light Source | 3-colour RGB LED |
Additional Functions | Scan to print, scan to cloud, scan to FTP, scan to folder, scan to email |
Max Supported Document Size | A4 (210 x 297 mm) |
Input Type | Colour |
Grayscale / Color Depth | 8-bit (256 colours) / 30-bit colour |
Grayscale / Color Depth (External) | 8-bit (256 colours) / 24-bit (16.7 million colours) |
Optical Resolution | 1200 dpi x 1200 dpi |
Max Document Scan Speed | 25 ppm (mono) / 25 ppm (colour) |
Max Document Size | 216 mm x 356 mm |
Automatic Duplexing | Yes |
Supported Document Type | Plain paper |
Document Feeder Type | Automatic |
Document Storage Capacity | 50 sheets |
Duty Cycle | 1500 scans per day |
Power | AC 120/230 V (50 – 60 Hz) |
System Requirements | Microsoft Windows 7, Windows 8, Windows 8.1, Windows 10, Apple MacOS X 10.6.8 – 10.11.x |
Dimensions (WxDxH) | 45.1 cm x 31.8 cm x 12.1 cm |
Weight | 6 kg |
Environmental Standards | ENERGY STAR Qualified |
Extended Specifications
General
Type | Document scanner – desktop |
|---|
Interface Type | USB 3.0 |
|---|
Additional Functions | Scan to print, scan to cloud, scan to FTP, scan to folder, scan to email |
|---|
Max Supported Document Size | A4 (210 x 297 mm) |
|---|
Scanner
Input Type | Colour |
|---|
Grayscale Depth | 8-bit (256 colours) |
|---|
Grayscale Depth (External) | 8-bit (256 colours) |
|---|
Colour Depth | 30-bit colour |
|---|
Colour Depth (External) | 24-bit (16.7 million colours) |
|---|
Optical Resolution | 1200 dpi x 1200 dpi |
|---|
Scan Mode | Single-pass |
|---|
Automatic Duplexing | Yes |
|---|
Scanning Sensor Type | Contact Image Sensor (CIS) |
|---|
Bulb / Light Source Type | 3-colour RGB LED |
|---|
Max Document Scan Speed B/W | 25 ppm |
|---|
Max Document Scan Speed Colour | 25 ppm |
|---|
Control Panel Buttons Functions | Scan, stop |
|---|
Duty Cycle | 1500 scans per day |
|---|
Scanner Speed Details | 25 ppm – black & white – A4 – 300 dpi
10 ipm – duplex – black & white – A4 – 300 dpi
25 ppm – colour – A4 – 300 dpi
10 ipm – duplex – colour – A4 – 300 dpi |
|---|
Scanner Features | De-skewing, blank page skipping, Text Enhancement, Color Enhancement, skew correction, Unsharp Mask, searchable PDF |
|---|
Compliant Standards | TWAIN, ISIS |
|---|
Media Handling
Max Document Size | 216 mm x 356 mm |
|---|
Supported Document Type | Plain paper |
|---|
Document Feeder Type | Automatic |
|---|
Document Storage Capacity | 50 sheets |
|---|
Expansion / Connectivity
Interfaces Details | USB 3.0 |
|---|
Environmental Standards
Power
Power Device | Internal power supply |
|---|
Voltage Required | AC 120/230 V (50 – 60 Hz) |
|---|
Power Consumption Operational (Standby) | 11 watt |
|---|
Power Consumption Stand by | 5.8 watt |
|---|
Power Consumption Sleep | 0.8 watt |
|---|
Software / System Requirements
Software Included | Drivers & Utilities, ABBYY FineReader, NewSoft Presto! PageManager, EPSON Document Capture Pro, EPSON Scan 2 |
|---|
OS Required | Microsoft Windows 7, Windows 8, Windows 8.1, Windows 10, Apple MacOS X 10.6.8 – 10.11.x |
|---|
Dimensions & Weight
Width | 45.1 cm |
|---|
Depth | 31.8 cm |
|---|
Height | 12.1 cm |
|---|
Weight | 6 kg |
|---|
Environmental Parameters
Min Operating Temperature | 10 °C |
|---|
Max Operating Temperature | 35 °C |
|---|
Humidity Range Operating | 20 – 80% (non-condensing) |
|---|
