Description
The StarTech U/FTP patch cable is designed for network performance, featuring an ultraslim design that ensures easy routing in tight spaces. With pure bare copper conductors and up to 10 Gbps transmission speed, this cable is suitable for high-speed data transfer and minimizes signal loss and interference. The aluminum mylar foil shielding enhances EMI shielding, while the gold-plated connectors provide durability and reliable connectivity.
This cable is built to last, with a flexible thermoplastic elastomer (TPE) jacket that withstands a range of temperatures, from -20°C to 60°C. It meets various compliance standards, including RoHS and ANSI/TIA-568-C.2, ensuring safe and eco-friendly use. The snagless design and translucent connector boots further enhance usability, making it a reliable choice for all your networking needs.
- Ultraslim design for easy installation in tight spaces
- Up to 10 Gbps transmission speed for reliable data transfer
- Aluminum mylar foil shielding for enhanced EMI protection
- Flexible TPE jacket with a wide operating temperature range
- Gold-plated connectors for improved durability
- Efficient design
The ultraslim and snagless design of this cable allows for easy routing and installation without worrying about cable damage. - High performance
With a tested frequency of up to 500 MHz and data rates of up to 10 Gbps, this cable is suitable for advanced networking applications. - Superior shielding
The aluminum mylar foil shielding minimizes external interference, ensuring a stable and clear signal for reliable connectivity. - Robust connectors
The 50 micron gold-plated connectors provide resistance to corrosion and ensure a strong, reliable connection every time. - Temperature resilience
This cable operates effectively within a broad temperature range, from -20°C to 60°C, making it suitable for various environments.
Main Specifications
Product Description | Startech patch cable – 50 cm – black |
Type | Patch cable – CAT 6a |
Technology | U/FTP |
Wiring Scheme | T568B |
Shielding Material | Aluminium mylar foil with drain |
Wires per Cable | 8 wires |
Features | Ultra-slim, snagless, stranded copper, pure bare copper conductors, 50 micron gold-plated connectors, minimised Near-End Crosstalk (NEXT), flexible, reduced Return Loss (RL), translucent connector boots, up to 10 Gbps, EMI shielding |
Cable Length | 50 cm |
Diameter | 3.7 mm |
Connector | RJ-45 – male |
Connector (Second End) | RJ-45 – male |
Colour | Black |
Extended Specifications
General
Network Cable Type | Patch cable – CAT 6a |
|---|
Technology | U/FTP |
|---|
Wiring Scheme | T568B |
|---|
Shielding Material | Aluminium mylar foil with drain |
|---|
Jacket Material | Thermoplastic elastomer (TPE) |
|---|
American Wire Gauge (AWG) | 34 |
|---|
Wires per Cable | 8 wires |
|---|
Pairs per Cable | 4 pairs |
|---|
Plated Connector | Gold |
|---|
Features | Ultra-slim, snagless, stranded copper, pure bare copper conductors, 50 micron gold-plated connectors, minimised Near-End Crosstalk (NEXT), flexible, reduced Return Loss (RL), translucent connector boots, up to 10 Gbps, EMI shielding |
|---|
Cable Length | 50 cm |
|---|
Diameter | 3.7 mm |
|---|
Weight | 10 g |
|---|
Colour | Black |
|---|
Connectivity
Connector | RJ-45 – male |
|---|
Connector (Second End) | RJ-45 – male |
|---|
Miscellaneous
Compliant Standards | RoHS, ANSI/TIA-568-C.2, TIA/EIA-568-B.1-2001, WEEE – up to 500 MHz |
|---|
Dimensions & Weight (Shipping)
Shipping Width | 15 cm |
|---|
Shipping Depth | 12 cm |
|---|
Shipping Height | 1.6 cm |
|---|
Shipping Weight | 16 g |
|---|
Environmental Parameters
Min Operating Temperature | -20 °C |
|---|
Max Operating Temperature | 60 °C |
|---|
