Description
The StarTech N6PAT50CMBKS10PK patch cable offers reliable connectivity for high-performance networking applications. Constructed with a Low Smoke Zero Halogen (LSZH) jacket, this cable minimizes harmful emissions while providing durability and flexibility. With its Category 6 rating and ability to support data transfer speeds of up to 10 Gbps, users can experience effective performance for demanding tasks. The cable’s stranded design enhances its resilience, making it ideal for various installations.
Each cable includes gold-plated RJ-45 connectors, ensuring consistent signal integrity and reduced return loss. Equipped with features like snagless connectors and strain relief, this patch cable provides a user-friendly experience. Its flame retardant properties and compliance with RoHS and WEEE standards underscore a commitment to safety and environmental considerations. The StarTech patch cable is a solid choice for network setups requiring reliability and efficiency.
- Supports data transfer speeds up to 10 Gbps
- Features Low Smoke Zero Halogen jacket for safety
- Gold-plated RJ-45 connectors for optimal performance
- Snagless design prevents damage to connectors
- Flame retardant material for added security
- Durable design
The cable is built with a Low Smoke Zero Halogen (LSZH) jacket, ensuring it is both durable and safe for use in various environments. - High-performance connectivity
With a tested frequency of up to 250 MHz and support for 100 W PoE, this cable meets the demands of modern networking applications. - Convenient installation
The snagless design and molded connectors help facilitate easy connections while protecting the cable from damage during installation. - Effective signal integrity
Gold-plated connectors and pure bare copper conductors work together to minimize Near-End Crosstalk (NEXT) and ensure strong data transmission. - Versatile use
This patch cable operates effectively in a range of temperatures, from 10°C to 60°C, making it suitable for various settings.
Main Specifications
Connector (Second End) | RJ-45 – male |
Colour | Black |
Product Description | Startech patch cable – 50 cm – black |
Type | Patch cable – CAT 6 – IEEE 802.3bt Type 4 |
Packaged Quantity | 10 (specifications are for single item) |
Technology | Unshielded twisted pair (UTP) |
Wiring Scheme | T568B |
Wires per Cable | 8 wires |
Features | Halogen-free, 100W PoE support, snagless, stranded, slim, molded, flame retardant, strain relief, minimised Near-End Crosstalk (NEXT), reduced Return Loss (RL), pure bare copper conductors, up to 10 Gbps, 50 micron gold-plated connectors |
Cable Length | 50 cm |
Diameter | 3.6 mm |
Connector | RJ-45 – male |
Extended Specifications
General
Plated Connector | Gold |
|---|
Features | Halogen-free, 100W PoE support, snagless, stranded, slim, molded, flame retardant, strain relief, minimised Near-End Crosstalk (NEXT), reduced Return Loss (RL), pure bare copper conductors, up to 10 Gbps, 50 micron gold-plated connectors |
|---|
Cable Length | 50 cm |
|---|
Diameter | 3.6 mm |
|---|
Weight | 18 g |
|---|
Colour | Black |
|---|
Connectivity
Connector | RJ-45 – male |
|---|
Connector (Second End) | RJ-45 – male |
|---|
Miscellaneous
Compliant Standards | RoHS, WEEE, ANSI/TIA-568-C.2, TIA/EIA-568-B.1-2001 – up to 250 MHz |
|---|
Dimensions & Weight (Shipping)
Shipping Width | 22 cm |
|---|
Shipping Depth | 24 cm |
|---|
Shipping Height | 1.5 cm |
|---|
Shipping Weight | 281 g |
|---|
Environmental Parameters
Min Operating Temperature | 10 °C |
|---|
Max Operating Temperature | 60 °C |
|---|
General
Packaged Quantity | 10 (specifications are for single item) |
|---|
Network Cable Type | Patch cable – CAT 6 – IEEE 802.3bt Type 4 |
|---|
Technology | Unshielded twisted pair (UTP) |
|---|
Wiring Scheme | T568B |
|---|
Jacket Material | Low Smoke Zero Halogen (LSZH) |
|---|
American Wire Gauge (AWG) | 28 |
|---|
Wires per Cable | 8 wires |
|---|
Pairs per Cable | 4 pairs |
|---|
