Description
The StarTech network patch cable combines efficient technology and robust construction for reliable performance. Featuring U/FTP technology and a shielded aluminum mylar foil with drain, this cable minimizes interference and maximizes data integrity. With a tested frequency of up to 500 MHz and the capability to support speeds of up to 10 Gbps, it is ideal for high-speed networking applications. The snagless design ensures easy installation without concerns over cable snagging, while the ultraslim profile allows for flexible routing in tight spaces.
Constructed with pure bare copper conductors and gold-plated connectors, the StarTech patch cable provides excellent conductivity and reduced signal loss. Its compatibility with the T568B wiring scheme and compliance with ANSI/TIA-568-C.2 standards support high performance. Operating within a wide temperature range, this cable is well-suited for various environments, making it an essential part of any networking setup.
- Supports data transfer rates up to 10 Gbps
- Features snagless design for easy installation
- Constructed with pure bare copper conductors
- Gold-plated connectors ensure minimal signal loss
- Slim profile allows for versatile routing in tight areas
- Reliable performance
This patch cable is designed with U/FTP technology and aluminum mylar foil shielding to minimize interference, ensuring stable and high-quality data transmission. - High speed capability
With a tested frequency of up to 500 MHz, this cable can support data transfer speeds of up to 10 Gbps, making it suitable for demanding network applications. - Durable construction
Made from thermoplastic elastomer (TPE) and featuring pure bare copper conductors, this cable is built to withstand rigorous use while maintaining connectivity. - Gold-plated connectors
The connectors are plated with 50 microns of gold to reduce signal loss and provide enhanced conductivity for a reliable connection. - Temperature resistant
Operating efficiently in temperatures ranging from -20°C to 60°C, this cable adapts to various environments, ensuring consistent performance.
Main Specifications
Product Description | Startech patch cable – 4 m – white |
Type | Patch cable – CAT 6a |
Technology | U/FTP |
Wiring Scheme | T568B |
Shielding Material | Aluminium mylar foil with drain |
Wires per Cable | 8 wires |
Features | Snagless, ultra-slim, stranded copper, pure bare copper conductors, up to 10 Gbps, 50 micron gold-plated connectors, minimised Near-End Crosstalk (NEXT), EMI shielding, reduced Return Loss (RL) |
Cable Length | 4 m |
Diameter | 3.7 mm |
Connector | RJ-45 – male |
Connector (Second End) | RJ-45 – male |
Colour | White |
Extended Specifications
General
Network Cable Type | Patch cable – CAT 6a |
|---|
Technology | U/FTP |
|---|
Wiring Scheme | T568B |
|---|
Shielding Material | Aluminium mylar foil with drain |
|---|
Jacket Material | Thermoplastic elastomer (TPE) |
|---|
American Wire Gauge (AWG) | 34 |
|---|
Wires per Cable | 8 wires |
|---|
Pairs per Cable | 4 pairs |
|---|
Plated Connector | Gold |
|---|
Features | Snagless, ultra-slim, stranded copper, pure bare copper conductors, up to 10 Gbps, 50 micron gold-plated connectors, minimised Near-End Crosstalk (NEXT), EMI shielding, reduced Return Loss (RL) |
|---|
Cable Length | 4 m |
|---|
Diameter | 3.7 mm |
|---|
Weight | 51 g |
|---|
Colour | White |
|---|
Connectivity
Connector | RJ-45 – male |
|---|
Connector (Second End) | RJ-45 – male |
|---|
Miscellaneous
Compliant Standards | ANSI/TIA-568-C.2, RoHS – up to 500 MHz |
|---|
Dimensions & Weight (Shipping)
Shipping Width | 21 cm |
|---|
Shipping Depth | 18 cm |
|---|
Shipping Height | 2.8 cm |
|---|
Shipping Weight | 80 g |
|---|
Environmental Parameters
Min Operating Temperature | -20 °C |
|---|
Max Operating Temperature | 60 °C |
|---|
