Description
The StarTech N6APATSTP34GRS4M patch cable offers reliable connectivity and performance for networking needs. Built with U/FTP technology and equipped with aluminum mylar foil shielding, this cable minimizes interference while delivering signal integrity. The thermoplastic elastomer jacket ensures durability and flexibility, making it suitable for various environments. With pure bare copper conductors and a tested frequency of up to 500 MHz, it supports data transfer speeds of up to 10 Gbps, ensuring smooth and fast connections whether at home or in an office setting.
This CAT 6a cable is designed for a maximum operating temperature of 60°C and a minimum of -20°C, making it resilient in varying conditions. Featuring gold-plated connectors that enhance durability and reduce corrosion, the snagless and ultraslim design makes installation easy and efficient. With compliance to ANSI/TIA-568-C.2 standards and RoHS, the StarTech patch cable is a dependable choice for effective networking solutions.
- Supports data transfer speeds of up to 10 Gbps
- Features aluminum mylar foil shielding for minimized interference
- Durable thermoplastic elastomer jacket enhances flexibility
- Includes gold-plated connectors for improved conductivity
- Designed with a snagless profile for easy installation
- Reliable connectivity
The cable is constructed with pure bare copper conductors, ensuring efficient data transmission and reliable performance for both small and large networking tasks. - Enhanced shielding
Aluminum mylar foil shielding minimizes Near-End Crosstalk (NEXT) and electromagnetic interference (EMI), providing clear signals even in challenging environments. - High-speed performance
With a tested frequency of up to 500 MHz, this patch cable can support high-speed data transfer, making it ideal for bandwidth-intensive applications. - Flexible design
The ultraslim and snagless design allows for easy routing and installation, ensuring a clutter-free workspace without sacrificing performance. - All-weather operation
This cable can operate in temperatures ranging from -20°C to 60°C, making it suitable for various indoor and outdoor applications.
Main Specifications
Product Description | Startech patch cable – 4 m – grey |
Type | Patch cable – CAT 6a |
Technology | U/FTP |
Wiring Scheme | T568B |
Shielding Material | Aluminium mylar foil with drain |
Wires per Cable | 8 wires |
Features | Snagless, ultra-slim, stranded copper, pure bare copper conductors, up to 10 Gbps, 50 micron gold-plated connectors, minimised Near-End Crosstalk (NEXT), EMI shielding, reduced Return Loss (RL) |
Cable Length | 4 m |
Diameter | 3.7 mm |
Connector | RJ-45 – male |
Connector (Second End) | RJ-45 – male |
Colour | Grey |
Extended Specifications
General
Network Cable Type | Patch cable – CAT 6a |
|---|
Technology | U/FTP |
|---|
Wiring Scheme | T568B |
|---|
Shielding Material | Aluminium mylar foil with drain |
|---|
Jacket Material | Thermoplastic elastomer (TPE) |
|---|
American Wire Gauge (AWG) | 34 |
|---|
Wires per Cable | 8 wires |
|---|
Pairs per Cable | 4 pairs |
|---|
Plated Connector | Gold |
|---|
Features | Snagless, ultra-slim, stranded copper, pure bare copper conductors, up to 10 Gbps, 50 micron gold-plated connectors, minimised Near-End Crosstalk (NEXT), EMI shielding, reduced Return Loss (RL) |
|---|
Cable Length | 4 m |
|---|
Diameter | 3.7 mm |
|---|
Weight | 51 g |
|---|
Colour | Grey |
|---|
Connectivity
Connector | RJ-45 – male |
|---|
Connector (Second End) | RJ-45 – male |
|---|
Miscellaneous
Compliant Standards | ANSI/TIA-568-C.2, RoHS – up to 500 MHz |
|---|
Dimensions & Weight (Shipping)
Shipping Width | 21 cm |
|---|
Shipping Depth | 18 cm |
|---|
Shipping Height | 2.8 cm |
|---|
Shipping Weight | 80 g |
|---|
Environmental Parameters
Min Operating Temperature | -20 °C |
|---|
Max Operating Temperature | 60 °C |
|---|
