Description
The StarTech 30 cm CAT 6a patch cable is designed for efficient networking with a focus on performance and durability. Utilizing U/FTP technology, this cable features aluminum Mylar foil shielding to minimize interference while maintaining high-speed data transfer capabilities of up to 10 Gbps. The ultraslim design and snagless connectors make it an ideal choice for tight spaces, ensuring seamless connections and reducing strain on the cable during installation.
Constructed with pure bare copper conductors and 50-micron gold-plated connectors, this patch cable offers excellent conductivity and low signal loss. The translucent connector boots provide EMI protection, while the strain relief feature enhances the overall durability for both home and professional use. Compliant with RoHS standards, this patch cable is a reliable and environmentally-friendly choice for modern networking needs.
- Up to 10 Gbps data transfer speed
- Aluminum Mylar foil shielding for reduced interference
- Ultraslim and snagless design for easy installation
- Pure bare copper conductors for improved conductivity
- 50-micron gold-plated connectors for enhanced performance
- Reliable connectivity
Equipped with RJ-45 male connectors on both ends, this patch cable ensures a secure and stable connection for network devices. - Environmentally compliant
This product adheres to RoHS and WEEE standards, making it a sustainable choice for networking solutions. - Versatile performance
Tested for frequency up to 500 MHz, this CAT 6a patch cable is suitable for various network applications including VoIP, video streaming, and gaming.
Main Specifications
Type | Patch cable – CAT 6a |
Packaged Quantity | 10 (specifications are for single item) |
Technology | U/FTP |
Wiring Scheme | T568B |
Shielding Material | Aluminium mylar foil with drain |
Wires per Cable | 8 wires |
Features | Ultra-slim, snagless, stranded, molded, pure bare copper conductors, 50 micron gold-plated connectors, up to 10 Gbps, minimised Near-End Crosstalk (NEXT), reduced Return Loss (RL), translucent connector boots, EMI protection, strain relief |
Cable Length | 30 cm |
Diameter | 3.7 mm |
Connector | RJ-45 – male |
Connector (Second End) | RJ-45 – male |
Colour | Grey |
Product Description | Startech patch cable – 30 cm – grey |
Extended Specifications
General
Packaged Quantity | 10 (specifications are for single item) |
|---|
Network Cable Type | Patch cable – CAT 6a |
|---|
Technology | U/FTP |
|---|
Wiring Scheme | T568B |
|---|
Shielding Material | Aluminium mylar foil with drain |
|---|
Jacket Material | Thermoplastic elastomer (TPE) |
|---|
American Wire Gauge (AWG) | 34 |
|---|
Wires per Cable | 8 wires |
|---|
Pairs per Cable | 4 pairs |
|---|
Plated Connector | Gold |
|---|
Features | Ultra-slim, snagless, stranded, molded, pure bare copper conductors, 50 micron gold-plated connectors, up to 10 Gbps, minimised Near-End Crosstalk (NEXT), reduced Return Loss (RL), translucent connector boots, EMI protection, strain relief |
|---|
Cable Length | 30 cm |
|---|
Diameter | 3.7 mm |
|---|
Weight | 8 g |
|---|
Colour | Grey |
|---|
Connectivity
Connector | RJ-45 – male |
|---|
Connector (Second End) | RJ-45 – male |
|---|
Miscellaneous
Compliant Standards | RoHS, WEEE, ANSI/TIA-568-C.2, TIA/EIA-568-B.1-2001 – up to 500 MHz |
|---|
Dimensions & Weight (Shipping)
Shipping Width | 21 cm |
|---|
Shipping Depth | 18 cm |
|---|
Shipping Height | 1.6 cm |
|---|
Shipping Weight | 164 g |
|---|
Environmental Parameters
Min Operating Temperature | -20 °C |
|---|
Max Operating Temperature | 60 °C |
|---|
