Description
The StarTech 30 cm CAT 6a patch cable is designed to provide high-performance connectivity with an ultraslim profile. Featuring aluminum Mylar foil shielding and a durable thermoplastic elastomer (TPE) jacket, this cable minimizes interference and ensures reliable signal transmission. It supports frequencies of up to 500 MHz, enabling data transfer rates of up to 10 Gbps, making it suitable for various networking applications. With gold-plated connectors and a stranded wiring scheme, this cable ensures optimal performance and longevity in any setup. Compatible with RoHS and WEEE standards, this cable emphasizes sustainability without compromising efficiency.
Engineered for versatility and performance, the cable is equipped with translucent connector boots that provide additional strain relief while remaining snagless. Its robust design is functional and resilient against environmental conditions, maintaining operability in temperatures ranging from -20°C to 60°C. This patch cable is a suitable choice for users needing dependable and efficient networking solutions.
- Ultraslim design for easy installation in tight spaces
- Supports data transfer speeds up to 10 Gbps
- Features aluminum Mylar foil shielding for EMI protection
- Gold-plated connectors for improved signal integrity
- Strain relief and snagless design enhance durability
- Reliable performance
This cable supports frequencies up to 500 MHz and enables data transfer rates of up to 10 Gbps, ensuring high-speed connectivity for demanding applications. - Enhanced durability
Constructed with thermoplastic elastomer (TPE) jacket and aluminum Mylar foil shielding, this patch cable offers strength and protection against interference. - Flexible installation
The ultraslim design allows for easy routing in tight spaces, while the snagless connector design prevents damage during installation and use. - Secure connections
Equipped with gold-plated connectors and pure bare copper conductors, this cable ensures reliable and stable connections in any networking setup. - Environmentally compliant
This product adheres to RoHS and WEEE standards, making it a responsible choice for environmentally conscious consumers.
Main Specifications
Product Description | Startech patch cable – 30 cm – black |
Type | Patch cable – CAT 6a |
Packaged Quantity | 10 (specifications are for single item) |
Technology | U/FTP |
Wiring Scheme | T568B |
Shielding Material | Aluminium mylar foil with drain |
Wires per Cable | 8 wires |
Features | Ultra-slim, snagless, stranded, molded, pure bare copper conductors, 50 micron gold-plated connectors, up to 10 Gbps, minimised Near-End Crosstalk (NEXT), reduced Return Loss (RL), translucent connector boots, EMI protection, strain relief |
Cable Length | 30 cm |
Diameter | 3.7 mm |
Connector | RJ-45 – male |
Connector (Second End) | RJ-45 – male |
Colour | Black |
Extended Specifications
General
Packaged Quantity | 10 (specifications are for single item) |
|---|
Network Cable Type | Patch cable – CAT 6a |
|---|
Technology | U/FTP |
|---|
Wiring Scheme | T568B |
|---|
Shielding Material | Aluminium mylar foil with drain |
|---|
Jacket Material | Thermoplastic elastomer (TPE) |
|---|
American Wire Gauge (AWG) | 34 |
|---|
Wires per Cable | 8 wires |
|---|
Pairs per Cable | 4 pairs |
|---|
Plated Connector | Gold |
|---|
Features | Ultra-slim, snagless, stranded, molded, pure bare copper conductors, 50 micron gold-plated connectors, up to 10 Gbps, minimised Near-End Crosstalk (NEXT), reduced Return Loss (RL), translucent connector boots, EMI protection, strain relief |
|---|
Cable Length | 30 cm |
|---|
Diameter | 3.7 mm |
|---|
Weight | 8 g |
|---|
Colour | Black |
|---|
Connectivity
Connector | RJ-45 – male |
|---|
Connector (Second End) | RJ-45 – male |
|---|
Miscellaneous
Compliant Standards | RoHS, WEEE, ANSI/TIA-568-C.2, TIA/EIA-568-B.1-2001 – up to 500 MHz |
|---|
Dimensions & Weight (Shipping)
Shipping Width | 21 cm |
|---|
Shipping Depth | 18 cm |
|---|
Shipping Height | 1.6 cm |
|---|
Shipping Weight | 164 g |
|---|
Environmental Parameters
Min Operating Temperature | -20 °C |
|---|
Max Operating Temperature | 60 °C |
|---|
