Description
The StarTech patch cable offers a reliable connection for various networking applications, featuring U/FTP technology with shielding. It is designed with aluminum mylar foil and a thermoplastic elastomer (TPE) jacket for durability. The cable supports frequencies of up to 500 MHz, ensuring robust data transmission rates of up to 10 Gbps, making it suitable for high-speed networking environments.
This ultraslim and snagless cable is engineered with pure bare copper conductors for performance, along with gold-plated connectors that minimize Near-End Crosstalk (NEXT) and reduce Return Loss (RL). The flexible design accompanied by translucent connector boots adds to its functionality and ease of use, providing an effective solution for both home and professional network setups.
- Supports data transmission speeds up to 10 Gbps
- Ultraslim and snagless design for easy installation
- Constructed with pure bare copper conductors
- Features 50 micron gold-plated connectors
- Minimized Near-End Crosstalk (NEXT) for better performance
- Durable construction
The patch cable is made with a thermoplastic elastomer (TPE) jacket that enhances flexibility and longevity, ensuring it can withstand various environmental conditions. - High-speed capability
With a tested frequency of up to 500 MHz, this CAT 6a cable provides exceptional performance for demanding applications, supporting data rates of up to 10 Gbps. - Advanced shielding
Equipped with aluminum mylar foil shielding, the cable effectively minimizes electromagnetic interference (EMI), promoting clear signal quality and reduced data loss. - Easy to install
The snagless design prevents cable snagging during installation, while the flexible construction makes it easier to route through tight spaces. - Compliance with standards
This patch cable meets several industry standards, including RoHS and ANSI/TIA-568-C.2, ensuring it is environmentally friendly and reliable for use in various settings.
Main Specifications
Product Description | Startech patch cable – 1 m – black |
Type | Patch cable – CAT 6a |
Technology | U/FTP |
Wiring Scheme | T568B |
Shielding Material | Aluminium mylar foil with drain |
Wires per Cable | 8 wires |
Features | Ultra-slim, snagless, stranded copper, pure bare copper conductors, 50 micron gold-plated connectors, minimised Near-End Crosstalk (NEXT), flexible, reduced Return Loss (RL), translucent connector boots, up to 10 Gbps, EMI shielding |
Cable Length | 1 m |
Diameter | 3.7 mm |
Connector | RJ-45 – male |
Connector (Second End) | RJ-45 – male |
Colour | Black |
Extended Specifications
General
Network Cable Type | Patch cable – CAT 6a |
|---|
Technology | U/FTP |
|---|
Wiring Scheme | T568B |
|---|
Shielding Material | Aluminium mylar foil with drain |
|---|
Jacket Material | Thermoplastic elastomer (TPE) |
|---|
American Wire Gauge (AWG) | 34 |
|---|
Wires per Cable | 8 wires |
|---|
Pairs per Cable | 4 pairs |
|---|
Plated Connector | Gold |
|---|
Features | Ultra-slim, snagless, stranded copper, pure bare copper conductors, 50 micron gold-plated connectors, minimised Near-End Crosstalk (NEXT), flexible, reduced Return Loss (RL), translucent connector boots, up to 10 Gbps, EMI shielding |
|---|
Cable Length | 1 m |
|---|
Diameter | 3.7 mm |
|---|
Weight | 16 g |
|---|
Colour | Black |
|---|
Connectivity
Connector | RJ-45 – male |
|---|
Connector (Second End) | RJ-45 – male |
|---|
Miscellaneous
Compliant Standards | RoHS, ANSI/TIA-568-C.2, TIA/EIA-568-B.1-2001, WEEE – up to 500 MHz |
|---|
Dimensions & Weight (Shipping)
Shipping Width | 15 cm |
|---|
Shipping Depth | 12 cm |
|---|
Shipping Height | 1.8 cm |
|---|
Shipping Weight | 23 g |
|---|
Environmental Parameters
Min Operating Temperature | -20 °C |
|---|
Max Operating Temperature | 60 °C |
|---|
