Description
The StarTech N6APATSTP34WHS15CM patch cable is designed to provide reliable connectivity for high-speed network applications. Built with pure bare copper conductors, this cable supports data transmission rates of up to 10 Gbps, making it suitable for CAT 6a networks. The aluminum mylar foil with drain shielding offers protection against Electromagnetic Interference (EMI), ensuring minimal near-end crosstalk and reduced return loss. The ultraslim, snagless design facilitates easier installation and maneuverability in tight spaces, and its gold-plated connectors enhance durability for consistent signal quality.
Compliant with ANSI/TIA-568-C.2 standards and RoHS-certified, this patch cable is built to last, featuring a TPE jacket that withstands a wide range of temperatures from -20°C to 60°C. With eight wires grouped into four pairs, this cable meets the expectations for reliable high-frequency performance, making it an excellent choice for both home and professional networking needs.
- Supports data transmission rates up to 10 Gbps
- Designed with aluminum mylar foil for EMI shielding
- Snagless and ultraslim cable design for easy installation
- Constructed with pure bare copper conductors for optimal performance
- Gold-plated connectors for enhanced durability
- High-speed connectivity
This patch cable supports data rates up to 10 Gbps, ensuring fast and efficient data transmission for high-performance networking. - Enhanced shielding
Features aluminum mylar foil with drain shielding to protect against electromagnetic interference, resulting in minimized near-end crosstalk. - Durable construction
Constructed with pure bare copper conductors and gold-plated connectors to ensure longevity and consistent connectivity. - Versatile temperature range
Operates efficiently within a temperature range of -20°C to 60°C, making it suitable for various environments. - Compliant standards
Meets ANSI/TIA-568-C.2 standards and is RoHS certified, ensuring quality and safety in network installations.
Main Specifications
Product Description | Startech patch cable – 15 cm – white |
Type | Patch cable – CAT 6a |
Technology | U/FTP |
Wiring Scheme | T568B |
Shielding Material | Aluminium mylar foil with drain |
Wires per Cable | 8 wires |
Features | Snagless, ultra-slim, stranded copper, pure bare copper conductors, up to 10 Gbps, 50 micron gold-plated connectors, minimised Near-End Crosstalk (NEXT), EMI shielding, reduced Return Loss (RL) |
Cable Length | 15 cm |
Diameter | 3.7 mm |
Connector | RJ-45 – male |
Connector (Second End) | RJ-45 – male |
Colour | White |
Extended Specifications
General
Network Cable Type | Patch cable – CAT 6a |
|---|
Technology | U/FTP |
|---|
Wiring Scheme | T568B |
|---|
Shielding Material | Aluminium mylar foil with drain |
|---|
Jacket Material | Thermoplastic elastomer (TPE) |
|---|
American Wire Gauge (AWG) | 34 |
|---|
Wires per Cable | 8 wires |
|---|
Pairs per Cable | 4 pairs |
|---|
Plated Connector | Gold |
|---|
Features | Snagless, ultra-slim, stranded copper, pure bare copper conductors, up to 10 Gbps, 50 micron gold-plated connectors, minimised Near-End Crosstalk (NEXT), EMI shielding, reduced Return Loss (RL) |
|---|
Cable Length | 15 cm |
|---|
Diameter | 3.7 mm |
|---|
Weight | 6 g |
|---|
Colour | White |
|---|
Connectivity
Connector | RJ-45 – male |
|---|
Connector (Second End) | RJ-45 – male |
|---|
Miscellaneous
Compliant Standards | ANSI/TIA-568-C.2, RoHS – up to 500 MHz |
|---|
Dimensions & Weight (Shipping)
Shipping Width | 15 cm |
|---|
Shipping Depth | 12 cm |
|---|
Shipping Height | 1.6 cm |
|---|
Shipping Weight | 10 g |
|---|
Environmental Parameters
Min Operating Temperature | -20 °C |
|---|
Max Operating Temperature | 60 °C |
|---|
