Description
The StarTech N6APATSTP34GRS15CM patch cable offers reliable performance for demanding network environments. With a durable thermoplastic elastomer (TPE) jacket, this patch cable withstands varying temperatures ranging from -20°C to 60°C, ensuring functionality in diverse conditions. Featuring U/FTP technology and aluminum Mylar foil shielding, it minimizes electromagnetic interference while providing robust data transmission capabilities.
Designed for high-speed networks, this CAT 6a patch cable supports data rates of up to 10 Gbps with a tested frequency of 500 MHz. The cable is equipped with snagless connectors and pure bare copper conductors for enhanced conductivity. Each connector is gold-plated for connection quality and to reduce return loss, making this cable an excellent choice for reliable and efficient networking.
- Supports data transfer rates of up to 10 Gbps
- Features aluminum Mylar foil shielding for reduced interference
- Durable thermoplastic elastomer (TPE) jacket
- Snagless design for easy installation
- Gold-plated connectors for improved performance
- Durable construction
The cable features a thermoplastic elastomer (TPE) jacket that provides robust protection and flexibility in various environments. - High-speed capabilities
This patch cable supports data rates of up to 10 Gbps, ideal for high-performance network applications. - Effective shielding
With aluminum Mylar foil shielding, this cable minimizes electromagnetic interference, ensuring a clear and stable signal. - Snagless design
The snagless connectors allow for easy installation and prevent damage during cable management. - Connection quality
Gold-plated connectors enhance conductivity and reduce return loss for reliable data transmission.
Main Specifications
Product Description | Startech patch cable – 15 cm – grey |
Type | Patch cable – CAT 6a |
Technology | U/FTP |
Wiring Scheme | T568B |
Shielding Material | Aluminium mylar foil with drain |
Wires per Cable | 8 wires |
Features | Snagless, ultra-slim, stranded copper, pure bare copper conductors, up to 10 Gbps, 50 micron gold-plated connectors, minimised Near-End Crosstalk (NEXT), EMI shielding, reduced Return Loss (RL) |
Cable Length | 15 cm |
Diameter | 3.7 mm |
Connector | RJ-45 – male |
Connector (Second End) | RJ-45 – male |
Colour | Grey |
Extended Specifications
General
Network Cable Type | Patch cable – CAT 6a |
|---|
Technology | U/FTP |
|---|
Wiring Scheme | T568B |
|---|
Shielding Material | Aluminium mylar foil with drain |
|---|
Jacket Material | Thermoplastic elastomer (TPE) |
|---|
American Wire Gauge (AWG) | 34 |
|---|
Wires per Cable | 8 wires |
|---|
Pairs per Cable | 4 pairs |
|---|
Plated Connector | Gold |
|---|
Features | Snagless, ultra-slim, stranded copper, pure bare copper conductors, up to 10 Gbps, 50 micron gold-plated connectors, minimised Near-End Crosstalk (NEXT), EMI shielding, reduced Return Loss (RL) |
|---|
Cable Length | 15 cm |
|---|
Diameter | 3.7 mm |
|---|
Weight | 6 g |
|---|
Colour | Grey |
|---|
Connectivity
Connector | RJ-45 – male |
|---|
Connector (Second End) | RJ-45 – male |
|---|
Miscellaneous
Compliant Standards | ANSI/TIA-568-C.2, RoHS – up to 500 MHz |
|---|
Dimensions & Weight (Shipping)
Shipping Width | 15 cm |
|---|
Shipping Depth | 12 cm |
|---|
Shipping Height | 1.6 cm |
|---|
Shipping Weight | 10 g |
|---|
Environmental Parameters
Min Operating Temperature | -20 °C |
|---|
Max Operating Temperature | 60 °C |
|---|
