Description
The StarTech 6ASTP34GRS15CM10PK patch cables provide a reliable and efficient solution for your networking needs. Constructed with a U/FTP design and aluminum Mylar foil shielding, these cables minimize interference and enhance performance. The ultraslim and snagless design make them easy to manage in tight spaces, while the stranded construction ensures flexibility and durability. With a tested frequency of up to 500 MHz and data transfer speeds of up to 10 Gbps, these CAT 6a cables are suitable for high-bandwidth applications. Featuring gold-plated connectors and pure bare copper conductors, connectivity is optimized for reduced Return Loss (RL) and minimized Near-End Crosstalk (NEXT), ensuring a stable and fast network connection.
- Ultraslim design for easy cable management
- Up to 10 Gbps data transfer speed
- Gold-plated connectors for enhanced connectivity
- Minimized Near-End Crosstalk (NEXT) for reliable performance
- Snagless design to prevent cable damage
- Efficient construction
The cable features pure bare copper conductors which enhance electrical performance and reliability for seamless data transmission. - Superior shielding
The aluminum Mylar foil shielding reduces electromagnetic interference, ensuring a stable connection and high-quality data transfer. - High-quality connectors
With 50-micron gold-plated connectors, these cables provide excellent conductivity and corrosion resistance, improving durability over time. - Flexible design
The stranded cabling allows for easier routing and flexibility in tight spaces, making installation quicker and more efficient. - Reliable standards compliance
Compliant with RoHS and WEEE standards, along with TIA/EIA-568-B.1-2001 and ANSI/TIA-568-C.2, ensuring adherence to recognized quality benchmarks.
Main Specifications
Product Description | Startech patch cable – 15 cm – grey |
Type | Patch cable – CAT 6a |
Packaged Quantity | 10 (specifications are for single item) |
Technology | U/FTP |
Wiring Scheme | T568B |
Shielding Material | Aluminium mylar foil with drain |
Wires per Cable | 8 wires |
Features | Ultra-slim, snagless, stranded, molded, pure bare copper conductors, 50 micron gold-plated connectors, up to 10 Gbps, minimised Near-End Crosstalk (NEXT), reduced Return Loss (RL), translucent connector boots, EMI protection, strain relief |
Cable Length | 15 cm |
Diameter | 3.7 mm |
Connector | RJ-45 – male |
Connector (Second End) | RJ-45 – male |
Colour | Grey |
Extended Specifications
General
Packaged Quantity | 10 (specifications are for single item) |
|---|
Network Cable Type | Patch cable – CAT 6a |
|---|
Technology | U/FTP |
|---|
Wiring Scheme | T568B |
|---|
Shielding Material | Aluminium mylar foil with drain |
|---|
Jacket Material | Thermoplastic elastomer (TPE) |
|---|
American Wire Gauge (AWG) | 34 |
|---|
Wires per Cable | 8 wires |
|---|
Pairs per Cable | 4 pairs |
|---|
Plated Connector | Gold |
|---|
Features | Ultra-slim, snagless, stranded, molded, pure bare copper conductors, 50 micron gold-plated connectors, up to 10 Gbps, minimised Near-End Crosstalk (NEXT), reduced Return Loss (RL), translucent connector boots, EMI protection, strain relief |
|---|
Cable Length | 15 cm |
|---|
Diameter | 3.7 mm |
|---|
Weight | 6 g |
|---|
Colour | Grey |
|---|
Connectivity
Connector | RJ-45 – male |
|---|
Connector (Second End) | RJ-45 – male |
|---|
Miscellaneous
Compliant Standards | RoHS, WEEE, ANSI/TIA-568-C.2, TIA/EIA-568-B.1-2001 – up to 500 MHz |
|---|
Dimensions & Weight (Shipping)
Shipping Width | 21 cm |
|---|
Shipping Depth | 18 cm |
|---|
Shipping Height | 1.6 cm |
|---|
Shipping Weight | 115 g |
|---|
Environmental Parameters
Min Operating Temperature | -20 °C |
|---|
Max Operating Temperature | 60 °C |
|---|
