Description
The StarTech N6APATSTP34BKS15CM patch cable is designed to deliver reliable and efficient network connectivity. Constructed with pure bare copper conductors and equipped with gold-plated connectors, this cable ensures minimal signal loss and optimal performance. The ultraslim design makes it easy to fit into tight spaces, while the snagless construction prevents damage to the connectors during installation. With a tested frequency of up to 500 MHz and support for data rates of up to 10 Gbps, this CAT 6a cable is ideal for high-speed networking applications.
Featuring aluminum mylar foil shielding, this cable effectively minimizes Electromagnetic Interference (EMI) and reduces Near-End Crosstalk (NEXT) for a stable connection. The flexible jacket made from Thermoplastic elastomer (TPE) enhances durability and provides protection against environmental factors. Compliant with RoHS and ANSI/TIA standards, this patch cable is a reliable choice for both home and office networking needs.
- Designed for high-speed data transfer up to 10 Gbps
- Ultraslim and snagless design for easy installation
- Gold-plated connectors for optimal signal quality
- EMI shielding minimizes interference and enhances performance
- Flexible jacket material ensures durability and longevity
- High-speed connectivity
Supports data rates of up to 10 Gbps, providing sufficient bandwidth for demanding applications. - Durable construction
Constructed with pure bare copper conductors and gold-plated connectors to ensure high performance and longevity. - Effective shielding
Features aluminum mylar foil shielding to minimize EMI and reduce Near-End Crosstalk, ensuring a stable connection. - Flexible and lightweight
The ultraslim design allows for easy maneuverability in tight spaces, and the TPE jacket adds durability. - Compliant with standards
Meets RoHS and ANSI/TIA standards for reliable and safe usage in various environments.
Main Specifications
Product Description | Startech patch cable – 15 cm – black |
Type | Patch cable – CAT 6a |
Technology | U/FTP |
Wiring Scheme | T568B |
Shielding Material | Aluminium mylar foil with drain |
Wires per Cable | 8 wires |
Features | Ultra-slim, snagless, stranded copper, pure bare copper conductors, 50 micron gold-plated connectors, minimised Near-End Crosstalk (NEXT), flexible, reduced Return Loss (RL), translucent connector boots, up to 10 Gbps, EMI shielding |
Cable Length | 15 cm |
Diameter | 3.7 mm |
Connector | RJ-45 – male |
Connector (Second End) | RJ-45 – male |
Colour | Black |
Extended Specifications
General
Network Cable Type | Patch cable – CAT 6a |
|---|
Technology | U/FTP |
|---|
Wiring Scheme | T568B |
|---|
Shielding Material | Aluminium mylar foil with drain |
|---|
Jacket Material | Thermoplastic elastomer (TPE) |
|---|
American Wire Gauge (AWG) | 34 |
|---|
Wires per Cable | 8 wires |
|---|
Pairs per Cable | 4 pairs |
|---|
Plated Connector | Gold |
|---|
Features | Ultra-slim, snagless, stranded copper, pure bare copper conductors, 50 micron gold-plated connectors, minimised Near-End Crosstalk (NEXT), flexible, reduced Return Loss (RL), translucent connector boots, up to 10 Gbps, EMI shielding |
|---|
Cable Length | 15 cm |
|---|
Diameter | 3.7 mm |
|---|
Weight | 6 g |
|---|
Colour | Black |
|---|
Connectivity
Connector | RJ-45 – male |
|---|
Connector (Second End) | RJ-45 – male |
|---|
Miscellaneous
Compliant Standards | RoHS, ANSI/TIA-568-C.2, TIA/EIA-568-B.1-2001, WEEE – up to 500 MHz |
|---|
Dimensions & Weight (Shipping)
Shipping Width | 15 cm |
|---|
Shipping Depth | 12 cm |
|---|
Shipping Height | 1.6 cm |
|---|
Shipping Weight | 10 g |
|---|
Environmental Parameters
Min Operating Temperature | -20 °C |
|---|
Max Operating Temperature | 60 °C |
|---|
