HPE Networking Comware 2150 48p 10M/100M/1G 4p SFP+ 1G/10G, Switch, L3, Managed, 48 x 10/100/1000Base-T + 4 x 1 Gigabit / 10 Gigabit SFP+ (uplink / stacking), rack-mountable
$2,559.50 inc GST
✕ Backorder - Email us for a lead time or ETA
✓ Free NZ Delivery
Available on back-order
- Allow 1–2 days for delivery to the North Island
- Allow 2–3 days for delivery to the South Island
- Add 1–2 days if you are rural
- Collection can be arranged
We are currently experiencing 1-2 day shipping delays from this supplier warehouse
Description
The HPE Networking Comware 2150 48p switch is designed to provide robust performance and flexible connectivity options for modern networking environments. With a capacity for 1500 IPv4 routes and advanced Layer 3 switching capabilities, this switch delivers reliable management and superior data throughput of 176 Gbps, making it suitable for various applications. The fanless design ensures silent operation, while the stackable form factor allows for easy expansion, accommodating up to 9 units for enhanced network functionality.
Featuring 48 10/100/1000Base-T ports and 4 additional 1G/10G SFP+ uplink ports, this switch supports jumbo frames of up to 9000 bytes, enabling efficient data handling for demanding workloads. Advanced features such as Intelligent Resilient Fabric Technology (IRF), Auto-MDI/MDIX support, and IPv6 compatibility further improve network performance and resilience. Designed to function effectively in diverse environmental conditions, it operates within a temperature range of -5°C to 50°C and supports both 5-95% humidity operating conditions.
- Supports 1500 IPv4 routes for comprehensive networking capabilities
- Robust data throughput of 176 Gbps enhances network efficiency
- Stackable design allows for scalable network solutions
- Fanless operation ensures quiet performance in sensitive environments
- Advanced security features with RADIUS and HWTACACS
- Efficient Routing Performance
The switch supports advanced routing protocols like RIP-2 and policy-based routing, enabling efficient traffic management and optimized routing performance for complex networking environments. - Flexible Connectivity Options
Equipped with 48 10/100/1000Base-T ports and 4 SFP+ ports, the switch provides extensive connectivity options for various devices, ensuring seamless integration into existing network infrastructures. - Robust Security Protocols
Supports comprehensive authentication methods including RADIUS and HWTACACS, ensuring secure access and protection for network resources. - Intelligent Traffic Management
Advanced Quality of Service (QoS) features enable prioritization of critical network traffic, ensuring that important data flows smoothly without interruptions. - Operational Resilience
Operating temperature range of -5°C to 50°C and 6 kV surge protection ensure reliability and resilience in various environmental conditions.
Main Specifications
Product Description | HPE Networking Comware 2150 48p 10M/100M/1G 4p SFP+ 1G/10G – switch – 48 ports – Managed – rack-mountable |
Device Type | Switch – 48 ports – L3 – Managed – stackable |
Enclosure Type | Rack-mountable 1U |
Subtype | Gigabit Ethernet |
Ports | 48 x 10/100/1000Base-T + 4 x 1 Gigabit / 10 Gigabit SFP+ (uplink / stacking) |
Performance | Forwarding capacity: 176 Gbps Throughput: 131 Mbps Latency (1 Gbps): < 5 µs Latency (10 Gbps): < 3 µs |
Capacity | Switched virtual interfaces (SVIs): 32 IPv4 routes: 1500 IPv4 host table (ARP): 1024 IPv6 routes: 512 IPv6 host table (ND): 512 IGMP groups: 500 MLD groups: 500 ACL entries (ingress/egress): 1024 VRF instances: 32 Packet buffer size: 1.5 MB |
MAC Address Table Size | 16K entries |
Jumbo Frame Support | 9000 bytes |
Routing Protocol | RIP-2, policy-based routing (PBR) |
Remote Management Protocol | CLI, SNMP 1, SNMP 2c, SNMP 3, RestAPI |
Features | Fanless, Advanced Quality of Service (QoS), IPv6 support, sFlow, IRF Technology, BFD, DLDP support, IPv4 and IPv6 dual stack, MVR, MLD, IGMP snooping, port mirroring, RRPP, Auto-MDI/MDIX support, 6 KV surge protection |
Compliant Standards | IEEE 802.1ab (LLDP), IEEE 802.1ad, IEEE 802.1x, IEEE 802.1Q |
Power | AC 90-264 V |
Dimensions (WxDxH) | 44 cm x 26 cm x 4.4 cm |
Weight | 3.6 kg |
Extended Specifications
General
Device Type | Switch – 48 ports – L3 – Managed – stackable |
|---|---|
Enclosure Type | Rack-mountable 1U |
Subtype | Gigabit Ethernet |
Ports | 48 x 10/100/1000Base-T + 4 x 1 Gigabit / 10 Gigabit SFP+ (uplink / stacking) |
Performance | Forwarding capacity: 176 Gbps Throughput: 131 Mbps Latency (1 Gbps): < 5 µs Latency (10 Gbps): < 3 µs |
Capacity | Switched virtual interfaces (SVIs): 32 IPv4 routes: 1500 IPv4 host table (ARP): 1024 IPv6 routes: 512 IPv6 host table (ND): 512 IGMP groups: 500 MLD groups: 500 ACL entries (ingress/egress): 1024 VRF instances: 32 Packet buffer size: 1.5 MB |
MAC Address Table Size | 16K entries |
Jumbo Frame Support | 9000 bytes |
Max Units In A Stack | 9 |
Routing Protocol | RIP-2, policy-based routing (PBR) |
Remote Management Protocol | CLI, SNMP 1, SNMP 2c, SNMP 3, RestAPI |
Authentication Method | RADIUS, HWTACACS |
Features | Fanless, Advanced Quality of Service (QoS), IPv6 support, sFlow, IRF Technology, BFD, DLDP support, IPv4 and IPv6 dual stack, MVR, MLD, IGMP snooping, port mirroring, RRPP, Auto-MDI/MDIX support, 6 KV surge protection |
Compliant Standards | IEEE 802.1ab (LLDP), IEEE 802.1ad, IEEE 802.1x, IEEE 802.1Q |
Processor | 1 x ARM: 1.2 GHz |
RAM | 1 GB SDRAM |
Flash Memory | 512 MB |
Expansion / Connectivity
Interfaces | 48 x 10/100/1000Base-T RJ-45 4 x 1/10GBase-X SFP+ uplink/stacking 1 x console USB Type-C 1 x console RJ-45 1 x management RJ-45 out-of-band network management |
|---|
Power
Power Device | Internal power supply |
|---|---|
Voltage Required | AC 90-264 V |
Power Consumption Operational | 31 watt |
Power Consumption Stand by | 13 watt |
Miscellaneous
Rack Mounting Kit | Included |
|---|---|
Compliant Standards | UL 60950-1, EN 60825-1, EN 60825-2, IEC 60950-1, IEC 62368-1, CAN/CSA-C22.2 No. 60950-1, EN 62368-1/A11, FDA 21 CFR Subchapter J, RoHS, EMC 2004/108/EC, FCC CFR 47 Part 15 Class A, EN 61000-4-11:2004, ANSI C63.4-2009, EN 61000-3-3:2008, VCCI V-3/2012.04, EN 61000-3-2:2006+A1:2009+A2:2009, EN 61000-4-3:2006, EN 61000-4-4:2012, EN 61000-4-5:2006, EN 61000-4-6:2009, CISPR 22:2008 (International) Class A, EN 55022:2010 Class A, EN 61000-4-29:2000, CISPR 24:2010, EN 300 386 V1.6.1, VCCI V-3/2013.04 Class A, EN55024, EN 300 386 |
Software / System Requirements
Software Included | HPE Intelligent Management Center |
|---|
Dimensions & Weight
Width | 44 cm |
|---|---|
Depth | 26 cm |
Height | 4.4 cm |
Weight | 3.6 kg |
Environmental Parameters
Min Operating Temperature | -5 °C |
|---|---|
Max Operating Temperature | 50 °C |
Humidity Range Operating | 5 – 95% (non-condensing) |
Min Storage Temperature | -40 °C |
Max Storage Temperature | 70 °C |
Humidity Range Storage | 5 – 95% (non-condensing) |
