Description
The HP ZGX Nano G1n Station is an ultra-small form factor workstation designed to deliver workstation-class compute in a compact footprint for space-conscious workspaces. It pairs a 20-core NVIDIA GB10 Grace Blackwell Superchip processor and NVIDIA Blackwell graphics to support demanding AI and compute tasks while preserving a desktop-style experience. The system includes 128 GB of high-speed LPDDR5X memory and a 2 TB NVMe M.2 SSD to provide responsive multitasking and fast local storage, and it offers a wide range of high-bandwidth connectivity options including 10 Gigabit Ethernet, dual 200 Gigabit QSFP ports, multiple USB-C DisplayPort outputs, and Wi-Fi 7 to support modern network and peripheral workflows.
- Compact ultra-small form factor for tight workspaces
- High-performance AI-capable processing with NVIDIA GB10 Grace Blackwell Superchip
- Large soldered LPDDR5X memory and 2 TB NVMe storage for responsive multitasking
- Extensive high-speed networking and display connectivity
- Compact design
Designed as an ultra-small form factor mini desktop, the HP ZGX Nano G1n Station saves desk space while providing the ports and performance expected from a workstation. - Powerful processing
A 20-core NVIDIA GB10 Grace Blackwell Superchip and NVIDIA Blackwell graphics deliver the compute needed for AI workloads and professional applications. - Ample memory and fast storage
With 128 GB of soldered LPDDR5X memory and a 2 TB PCIe 4.0 NVMe M.2 SSD, the system provides smooth multitasking and quick access to large datasets. - Advanced connectivity
Multiple high-bandwidth networking options including 10 Gigabit Ethernet, dual 200 Gigabit QSFP, USB-C DisplayPort outputs, and Wi-Fi 7 enable flexible, high-throughput connections for peripherals and networks. - Trusted security and compliance
Built-in TPM 2.0 and a range of industry compliance standards help protect data and support deployment in regulated environments.
Main Specifications
Product Description | HP ZGX Nano G1n Station – mini desktop – AI PC, AI Workstation – GB10 Grace Blackwell Superchip Cortex-A725 + Cortex-X925 – 128 GB – SSD 2 TB – TAA Compliant |
Type | Workstation – mini desktop – AI PC, AI Workstation |
Processor | 1 x NVIDIA GB10 Grace Blackwell Superchip Cortex-A725 + Cortex-X925 (20-core) |
RAM | 128 GB LPDDR5X SDRAM |
Hard Drive | SSD 2 TB – PCI Express 4.0 – M.2 – NVM Express (NVMe), triple-level cell (TLC) |
Optical Storage | No optical drive |
Graphics Controller | NVIDIA Blackwell |
Networking | 1GbE, 10GbE, 2.5GbE, 200GbE, 802.11a, Wi-Fi 5, Wi-Fi 6, Wi-Fi 7, 802.11b/g/n, Bluetooth, 5GbE |
Power | (50/60 Hz) |
OS Provided | NVIDIA DGX Base OS |
Software Included | NVIDIA AI Software Stack |
Colour | Black |
Dimensions (WxDxH) | 15 cm x 15 cm x 5.45 cm |
Weight | 1.25 kg |
Manufacturer Selling Program | HP Smart Buy |
TAA Compliant | Yes |
Extended Specifications
General
Type | Workstation |
|---|
AI Level | AI PC, AI Workstation |
|---|
Product Form Factor | Mini desktop |
|---|
Embedded Security | Trusted Platform Module (TPM 2.0) Security Chip |
|---|
Colour | Black |
|---|
Processor / Chipset
CPU | NVIDIA GB10 Grace Blackwell Superchip Cortex-A725 + Cortex-X925 |
|---|
Number of Cores | 20-core |
|---|
CPU Qty | 1 |
|---|
Max CPU Qty | 1 |
|---|
RAM
Installed Size | 128 GB |
|---|
Technology | LPDDR5X SDRAM |
|---|
Effective Memory Speed | 8533 MT/s |
|---|
Rated Memory Speed | 8533 MT/s |
|---|
Configuration Features | Provided memory is soldered |
|---|
Hard Drive
Type | SSD – M.2 |
|---|
Capacity | 1 x 2 TB |
|---|
Interface Type | PCI Express 4.0 |
|---|
Features | NVM Express (NVMe), triple-level cell (TLC) |
|---|
Optical Storage
Monitor
Graphics Controller
Graphics Processor | NVIDIA Blackwell |
|---|
Video Interfaces | HDMI |
|---|
Input Device
Type | No keyboard, no mouse |
|---|
Networking
Ethernet Ports | 1 x 10 Gigabit Ethernet, 2 x 200 Gigabit Ethernet QSFP |
|---|
Ethernet Controller | NVIDIA ConnectX-7 |
|---|
Wireless LAN Supported | Yes |
|---|
Wireless NIC | MediaTek Wi-Fi 7 MT7925 |
|---|
Data Link Protocol | Ethernet, Fast Ethernet, Gigabit Ethernet, 10 Gigabit Ethernet, 2.5 Gigabit Ethernet, 200 Gigabit Ethernet, IEEE 802.11a, IEEE 802.11ac, IEEE 802.11ax (Wi-Fi 6), IEEE 802.11b, IEEE 802.11be (Wi-Fi 7), IEEE 802.11g, IEEE 802.11n, Bluetooth 5.4, 5 Gigabit Ethernet |
|---|
Features | Dual stream (2×2) |
|---|
Expansion / Connectivity
Interfaces | 3 x USB-C 3.2 Gen 2×2/DisplayPort 1.4a (3 rear) (30 Watt output)
1 x USB-C (1 rear) (powered 240W)
1 x HDMI (1 rear)
1 x LAN (10Gigabit Ethernet) – RJ-45 (1 rear)
2 x LAN (200 Gigabit Ethernet) – QSFP (2 rear) |
|---|
Miscellaneous
Compliant Standards | Common Criteria EAL4+, FIPS 140-2, CEC, ERP, CECP, CEL, GS, UL, CB, BIS, EMC, FCC, ICES, CCC, RoHS |
|---|
Manufacturer Selling Program | HP Smart Buy |
|---|
TAA Compliant | Yes |
|---|
Power
Device Type | Power adapter |
|---|
Voltage Required | AC 90-264 V (50/60 Hz) |
|---|
Power Provided | 280 watt |
|---|
Efficiency | 92% |
|---|
Power Factor Correction | Yes (active) |
|---|
Operating System / Software
OS Provided | NVIDIA DGX Base OS |
|---|
Software | NVIDIA AI Software Stack |
|---|
Dimensions & Weight
Width | 15 cm |
|---|
Depth | 15 cm |
|---|
Height | 5.45 cm |
|---|
Weight | 1.25 kg |
|---|
Dimensions & Weight (Shipping)
Shipping Width | 21.6 cm |
|---|
Shipping Depth | 14.2 cm |
|---|
Shipping Height | 27.2 cm |
|---|
Shipping Weight | 2.5 kg |
|---|
Environmental Parameters
Min Operating Temperature | 5 °C |
|---|
Max Operating Temperature | 30 °C |
|---|
Humidity Range Operating | 8 – 85% RH (non-condensing) |
|---|
