Description
The TP-Link Tapo C236 V1 is a versatile network surveillance camera designed for both indoor and outdoor use, providing reliable monitoring capabilities. Equipped with features like AI Person Detection, Smart AI Notification, and motion tracking, it ensures security and peace of mind by accurately identifying movement and notifying users through the Tapo app. The camera’s 3K digital video resolution of 2880 x 1620 captures clear images, even in low-light conditions thanks to its Starlight Technology and infrared LEDs with a range of up to 20 m. With an operational temperature range from -20 °C to 50 °C and an IP65 weather-resistant rating, the Tapo C236 V1 is built to withstand various environmental conditions. Users can enjoy the convenience of voice control through Google Assistant and Alexa, making it easier to integrate into smart home systems. The camera supports various mounting options, including wall, ceiling, and table mounts, allowing for flexible placement in any setting.
- 3K digital video resolution for clarity
- AI Person Detection and motion tracking for surveillance
- Weather-resistant design suitable for indoor and outdoor use
- Voice control compatibility with Google Assistant and Alexa
- Flexible mounting options for various installation needs
- Surveillance technology
The Tapo C236 V1 incorporates various intelligent features such as Smart AI Detection, AI vehicle detection, and AI pet detection, allowing for efficient monitoring and reduced false alarms. - Connectivity options
With both wired and wireless connectivity technologies, this camera offers easy installation and reliable network access, ensuring seamless operation regardless of the setup. - Weather-resistant design
Designed with an IP65 rating, this surveillance camera is built to endure different weather conditions, making it a reliable choice for outdoor placements. - Night vision capabilities
Equipped with Starlight Technology and infrared LEDs, the camera provides clear video capture even in low-light environments, ensuring a secure watch around the clock. - Viewing angles
The pan and tilt mechanical design allows for a 360-degree panning range and a 151-degree tilting range, enabling users to cover large areas with precision and ease.
What’s in the Box
- Tapo C236 V1
- USB adapter cable – 2 m
- Power adapter, mounting bracket, 4 screws, 4 anchors, mounting template
Main Specifications
Product Description | Tapo C236 V1 – network surveillance camera |
Device Type | Network surveillance camera – pan / tilt – indoor, outdoor – weather resistant |
Audio | Yes: built-in speaker, two-way audio capability, built-in microphone |
Camera Mount Type | Wall mount, ceiling mount, pole mount, table mount |
Dimensions (WxDxH) | 10.53 cm x 7.78 cm x 6.98 cm |
Weight | 220 g |
Connectivity Technology | Wireless, wired |
Camera | Colour – Day&Night |
Max Resolution | 2880 x 1620 |
Frame Rate (max) | 30 frames per second |
Motion Detection | Yes |
Video Modes | 3K |
Optical Sensor Type | Progressive Scan CMOS – 1/2.7" – 5 MP |
Focal Length Control | Fixed focal |
Focal Length | 4 mm |
Lens Iris | F/1.6 |
Panning Range (degree) | 360 |
Tilting Range (degree) | 151 |
Interfaces | IEEE 802.11b, IEEE 802.11g, IEEE 802.11n |
Platform | Tapo Care, Google Home, SmartThings |
Intelligent Assistant | Alexa, Google Assistant – indirect |
Cables Included | 1 – USB adapter cable – 2 m |
Voltage | AC 100-240 V, DC 5 V |
Features | Smart AI Detection, Smart AI Notification, motion tracking, smart tracking, customised activity zone, privacy zones, IR-cut filter, auto-switching, reset button, 24/7 live view, AI Line Crossing Detection, AI Person Detection, AI Pet Detection, AI vehicle detection, AI Camera Tampering Detection, Snapshot notification, Starlight Technology |
Environmental Parameters (operating) | -20 °C – 50 °C; 10 – 90% RH (non-condensing) relative humidity |
Extended Specifications
General
Device Type | Network surveillance camera |
|---|
Audio Support | Yes: built-in speaker, two-way audio capability, built-in microphone |
|---|
Camera Mount Type | Wall mount, ceiling mount, pole mount, table mount |
|---|
Connectivity Technology | Wireless, wired |
|---|
Width | 10.53 cm |
|---|
Depth | 7.78 cm |
|---|
Height | 6.98 cm |
|---|
Weight | 220 g |
|---|
Camera
Type | Colour – Day&Night – pan / tilt – indoor, outdoor – weather resistant |
|---|
Digital Video Format | H.264 |
|---|
Max Digital Video Resolution | 2880 x 1620 |
|---|
Motion Detection | Yes |
|---|
Video Modes | 3K |
|---|
Infrared LEDs | 1 |
|---|
Infrared Distance | 20 m |
|---|
Digital Video Capture Resolution | 2880 x 1620 |
|---|
Frame Rate (max) | 30 frames per second |
|---|
Features | Smart AI Detection, Smart AI Notification, motion tracking, smart tracking, customised activity zone, privacy zones, IR-cut filter, auto-switching, reset button, 24/7 live view, AI Line Crossing Detection, AI Person Detection, AI Pet Detection, AI vehicle detection, AI Camera Tampering Detection, Snapshot notification, Starlight Technology |
|---|
Image Sensor
Type | 5 MP Progressive Scan CMOS 1/2.7" |
|---|
Lens Construction
Type | Fixed focal |
|---|
Focal Length | 4 mm |
|---|
Lens Iris | F/1.6 |
|---|
Horizontal Field of View (degree) | 88 |
|---|
Vertical Field of View (degree) | 46 |
|---|
Diagonal Field of View (degree) | 105 |
|---|
Panning
Tilting
Interfaces
Network Interface | IEEE 802.11b, IEEE 802.11g, IEEE 802.11n |
|---|
Network Protocols | TCP/IP, DHCP, ICMP, DNS, NTP, HTTPS, TCP, UDP, RTSP, ONVIF |
|---|
Expansion / Connectivity
Ports | USB – Type C |
|---|
Supported Memory Cards | microSD Card |
|---|
Encryption Algorithm | 128-bit AES, SSL, TLS, WPA, WPA2-PSK |
|---|
Miscellaneous
Included Accessories | 4 anchors, 4 screws, mounting bracket, mounting template |
|---|
Cables Included | 1 x USB adapter cable – 2 m |
|---|
Compliant Standards | IP65 |
|---|
Power
Power Requirements | DC 5 V – 1 A |
|---|
Power Device | Power adapter – external AC 100-240 V (50/60 Hz) 2.3 watt |
|---|
Internet of Things (IoT)
Internet of Things (IoT) Compatible | Yes |
|---|
Platform | Tapo Care, Google Home, SmartThings |
|---|
Compatible Application | Tapo app |
|---|
Communications Type | Cloud |
|---|
Communications Technology | Wi-Fi |
|---|
Intelligent Assistant | Alexa, Google Assistant |
|---|
Voice Controlled | Indirect |
|---|
Environmental Parameters
Min Operating Temperature | -20 °C |
|---|
Max Operating Temperature | 50 °C |
|---|
Relative Humidity (operating) | 10 – 90% RH (non-condensing) |
|---|
