Description
The StarTech C6KEY110180BK24PK keystone jack is designed to provide reliable performance for networking applications. With a single RJ-45 female connector, this product features a 180-degree orientation and supports up to 10 Gbps data transmission. It is compatible with both T568A and T568B wiring schemes and utilizes 110 type punch down termination for secure and efficient connections.
Constructed from durable ABS polycarbonate, this keystone jack offers necessary corrosion protection, ideal for a variety of environments. It also supports Power over Ethernet (PoE) up to 100 W, making it a versatile choice for modern network setups. With a temperature operating range from -10°C to 60°C and a humidity tolerance of 85%, this product ensures reliability under varying conditions.
- 180-degree orientation for flexible installation
- Supports data transmission speeds up to 10 Gbps
- Compatible with T568A/B wiring schemes
- Offers up to 100 W PoE support
- Durable ABS polycarbonate construction
- Efficient punchdown termination
The keystone jack features a 110 type punchdown termination, ensuring a secure and efficient connection for reliable network performance. - High data transmission capacity
Capable of supporting speeds up to 10 Gbps, this keystone jack is suitable for high performance networking environments. - Robust environmental tolerance
With a temperature operating range from -10°C to 60°C and high humidity tolerance, this product is designed to perform reliably in various conditions. - Enhanced power support
This jack supports Power over Ethernet (PoE) up to 100 W, providing power and data through a single cable for convenient network setup. - Corrosion protection feature
Constructed with corrosion protection, this keystone jack is built to withstand environmental challenges, extending its lifespan and reliability.
Main Specifications
Product Description | Startech keystone jack – 180°, 110 punch down – TAA Compliant |
Product Type | Keystone jack – CAT 6 – RJ-45 – 180°, 110 punch down |
Packaged Quantity | 24 (specifications are for single item) |
Dimensions (WxDxH) | 1.45 cm x 3.08 cm x 1.92 cm |
Weight | 7 g |
Product Material | ABS polycarbonate |
Colour | Black |
Port Qty | 1 port |
Wiring Scheme | T568A/B |
Compliant Standards | ANSI/TIA-568-C.2, IEEE 802.3bt Type 4, IEEE 802.3, IEEE 802.3ae, IEEE 802.3bz |
TAA Compliant | Yes |
Extended Specifications
General
Packaged Quantity | 24 (specifications are for single item) |
|---|
Product Type | Keystone jack – CAT 6 – 180°, 110 punch down |
|---|
Product Material | ABS polycarbonate |
|---|
Width | 1.45 cm |
|---|
Depth | 3.08 cm |
|---|
Height | 1.92 cm |
|---|
Weight | 7 g |
|---|
Enclosure Colour | Black |
|---|
Cabling & Wiring
Port Qty | 1 port |
|---|
Termination Type | 110 type termination, punchdown |
|---|
Technology | Unshielded twisted pair (UTP) |
|---|
Wiring Scheme | T568A/B |
|---|
Features | 180 degree, Keystone type, up to 10 Gbps, up to 100W PoE support, gold-plated contacts |
|---|
Connector Provided | 1 x RJ-45 female |
|---|
Miscellaneous
Features | Rear loading, corrosion protection |
|---|
Compliant Standards | ANSI/TIA-568-C.2, IEEE 802.3bt Type 4, IEEE 802.3, IEEE 802.3ae, IEEE 802.3bz |
|---|
TAA Compliant | Yes |
|---|
Dimensions & Weight (Shipping)
Shipping Width | 16.8 cm |
|---|
Shipping Depth | 10.7 cm |
|---|
Shipping Height | 3.5 cm |
|---|
Shipping Weight | 237 g |
|---|
Environmental Parameters
Min Operating Temperature | -10 °C |
|---|
Max Operating Temperature | 60 °C |
|---|
Humidity Range Operating | 85% |
|---|
