Description
The ultimate dual-port 10 Gigabit Ethernet controller with the flexibility and scalability required for virtual and unified storage environments. The member of Super Micro’s network adapter family, the AOC-STGN-i2S is the flexible and scalable Ethernet adapter for demanding data center environments. Based on the Intel 10GbE network controller, the AOC-STGN-i2S addresses the demanding needs of the data center by providing unmatched features for virtualization, flexibility for LAN and SAN networking, and proven reliable performance.
- Dual SFP+ connectors
- Low-profile standard form factor
- PCI Express 2.0
- Load balancing on multiple CPUs
- iSCSI remote boot support
- Support for most Network Operating Systems (NOSs)
- RoHS compliant 6/6
- Intel 82599ES 10GbE controller
- Compact size low-profile standard form factor
- Intel QuickData technology – DMA engine that enhances data acceleration and lowers CPU usage
- Direct Cache Access (DCA) to avoid cache misses
- MSI-X support to minimize the overhead of interrupts and allows load-balancing between multiple cores/CPUs
- Advanced packet filtering
- VLAN support to allow creation of multiple VLAN segments
- Preboot eXecution Environment (PXE) support
- iSCSI remote boot
What’s in the Box
- Supermicro Add-on Card AOC-STGN-i2S
- Low-profile bracket
Main Specifications
Product Description | Supermicro AOC-STGN-i2S – network adapter – PCIe 2.0 x8 – 2 ports |
Device Type | Network adapter |
Form Factor | Plug-in card – low profile |
Interface (Bus) Type | PCI Express 2.0 x8 |
Dimensions (WxDxH) | 13.7 cm x 6.4 cm |
Ports Qty | 2 ports |
Data Link Protocol | 10GbE |
Data Transfer Rate | 10 Gbps |
Network / Transport Protocol | TCP/IP, UDP/IP, iSCSI |
Processor | 1 x Intel 82599ES |
System Requirements | FreeBSD, SUSE Linux Enterprise Server, Red Hat Enterprise Linux, Microsoft Windows Server 2008 SP2, Microsoft Windows Vista SP2, Microsoft Windows Server 2003 SP2 |
Designed For | SuperServer 5086B-TRF |
Extended Specifications
General
Device Type | Network adapter – 2 ports |
|---|
Form Factor | Plug-in card – low profile |
|---|
Interface (Bus) Type | PCI Express 2.0 x8 |
|---|
Networking
Connectivity Technology | Wired |
|---|
Data Link Protocol | 10 Gigabit Ethernet |
|---|
Data Transfer Rate | 10 Gbps |
|---|
Network / Transport Protocol | TCP/IP, UDP/IP, iSCSI |
|---|
Remote Management Protocol | SNMP, RMON |
|---|
Features | Load balancing, remote reboot, VLAN support, packet filtering, IPv6 support, ARSC, VMDq, PXE support |
|---|
Processor / Memory
Processor | 1 x Intel 82599ES |
|---|
Expansion / Connectivity
Expansion Slots | 2 (total) / 2 (free) x SFP+ |
|---|
Compatible Slots | 1 x PCI Express x8 |
|---|
Miscellaneous
Included Accessories | Low-profile bracket |
|---|
Compliant Standards | RoHS |
|---|
Software / System Requirements
Software Included | Intel PROSet |
|---|
OS Required | FreeBSD, SUSE Linux Enterprise Server, Red Hat Enterprise Linux, Microsoft Windows Server 2008 SP2, Microsoft Windows Vista SP2, Microsoft Windows Server 2003 SP2 |
|---|
Dimensions & Weight
Environmental Parameters
Min Operating Temperature | 0 °C |
|---|
Max Operating Temperature | 55 °C |
|---|
Compatibility Information
Designed For | Supermicro SuperServer 5086B-TRF |
|---|
