Description
The StarTech N6APATUTP34BKS1M patch cable is designed to ensure reliable network performance with its capabilities. This CAT 6a cable features pure bare copper conductors and gold-plated connectors, allowing for data transfer speeds of up to 10 Gbps. The ultraslim, snagless design helps reduce clutter and provides flexibility for easy installation in tight spaces. Additionally, the cable minimizes Near-End Crosstalk (NEXT) and reduces Return Loss (RL), enhancing overall network integrity at high frequencies of up to 500 MHz.
Made with thermoplastic elastomer (TPE) jacket material, this cable is both durable and flexible, making it suitable for a range of environments. The RJ-45 connectors on both ends ensure compatibility with common networking devices, while the translucent connector boots protect the connection points. This patch cable meets various compliance standards, adhering to environmental regulations.
- Supports data transfer speeds up to 10 Gbps
- Ultraslim and snagless design for easy installation
- Pure bare copper conductors enhance signal quality
- Minimizes Near-End Crosstalk (NEXT) for reliable performance
- Durable thermoplastic elastomer (TPE) jacket material
- Reliable connection
The StarTech patch cable utilizes pure bare copper conductors that provide a solid and consistent link, essential for demanding network applications. - Flexible design
Its ultraslim and snagless design makes routing through tight spaces easier while minimizing the risk of damage during installation. - High performance
Engineered to support frequencies up to 500 MHz, this cable is ideal for high-bandwidth applications and ensures stable data transfer rates. - Protected connectors
With gold-plated connectors and translucent boots, this patch cable provides protection against physical wear, ensuring longevity and reliable performance. - Compliance standards
This product meets RoHS and WEEE standards, contributing to environmentally friendly networking solutions.
Main Specifications
Product Description | Startech patch cable – 1 m – black |
Type | Patch cable – CAT 6a |
Technology | Unshielded twisted pair (UTP) |
Wiring Scheme | T568B |
Wires per Cable | 8 wires |
Features | Snagless, ultra-slim, stranded copper, pure bare copper conductors, 50 micron gold-plated connectors, flexible, minimised Near-End Crosstalk (NEXT), reduced Return Loss (RL), translucent connector boots, up to 10 Gbps |
Cable Length | 1 m |
Diameter | 2.6 mm |
Connector | RJ-45 – male |
Connector (Second End) | RJ-45 – male |
Colour | Black |
Extended Specifications
General
Network Cable Type | Patch cable – CAT 6a |
|---|
Technology | Unshielded twisted pair (UTP) |
|---|
Wiring Scheme | T568B |
|---|
Jacket Material | Thermoplastic elastomer (TPE) |
|---|
American Wire Gauge (AWG) | 34 |
|---|
Wires per Cable | 8 wires |
|---|
Pairs per Cable | 4 pairs |
|---|
Plated Connector | Gold |
|---|
Features | Snagless, ultra-slim, stranded copper, pure bare copper conductors, 50 micron gold-plated connectors, flexible, minimised Near-End Crosstalk (NEXT), reduced Return Loss (RL), translucent connector boots, up to 10 Gbps |
|---|
Cable Length | 1 m |
|---|
Diameter | 2.6 mm |
|---|
Weight | 16 g |
|---|
Colour | Black |
|---|
Connectivity
Connector | RJ-45 – male |
|---|
Connector (Second End) | RJ-45 – male |
|---|
Miscellaneous
Compliant Standards | RoHS, ANSI/TIA-568-C.2, TIA/EIA-568-B.1-2001, WEEE – up to 500 MHz |
|---|
Dimensions & Weight (Shipping)
Shipping Width | 14 cm |
|---|
Shipping Depth | 20 cm |
|---|
Shipping Height | 1.8 cm |
|---|
Shipping Weight | 19 g |
|---|
Environmental Parameters
Min Operating Temperature | -20 °C |
|---|
Max Operating Temperature | 60 °C |
|---|
