Description
Upgrade to blazing-fast 5.4Gbps of Wi-Fi 6 on up to 75 devices simultaneously across more space: 7 rooms or up to 7,500 sq. ft. Protected by award-winning NETGEAR security services, the RBK763S includes a dedicated connection for instant router-satellite communication and 7 Gigabit ports to give your most demanding tech products their own wired connection.
- Engineered for blazing fast Wi-Fi
- Unstoppable streaming
- The best coverage, period
- Your peace of mind is the priority
- Connected kids are protected too
- Engineered for blazing fast Wi-Fi
Orbi is engineered for more efficient data transmission through the exclusive Tri-Band technology. The result is faster Wi-Fi performance that doesn’t degrade across the house. - Unstoppable streaming
Orbi keeps everyone in your house streaming Netflix shows, video calls, and gaming, all at the same time with no buffering or drop offs. - The best coverage, period
Orbi’s unique shape and height encase ultra-premium, high-power components to deliver significantly better coverage and overall performance than the competition. - Your peace of mind is the priority
Create an automatic protective bubble around all your devices. Keep sensitive information from being stolen and ensure all your Internet activity remains private. - Connected kids are protected too
Easily manage kids’ time and accessibility online across all connected devices. Promote healthy Internet habits, foster responsibility and build trust with your kids.
What’s in the Box
- NETGEAR Orbi RBK763S
- Router, 2 extenders
- Network cable – 2 m
- External power adapter
- Software
Main Specifications
Product Description | NETGEAR Orbi RBK763S – Wi-Fi system – Wi-Fi 6 – desktop |
Device Type | Wi-Fi system – mesh |
Enclosure Type | Desktop |
Wi-Fi System Components | Router, 2 extenders |
Wi-Fi System Coverage | Up to 525 sq.m |
WAN Ports Qty | 1 |
Data Link Protocol | Ethernet, Fast Ethernet, Gigabit Ethernet, IEEE 802.11b, IEEE 802.11a, IEEE 802.11g, IEEE 802.11n, IEEE 802.11ac, IEEE 802.11ax (Wi-Fi 6) |
Frequency Band | 2.4 GHz (1 band) / 5 GHz (2 bands) |
Data Transfer Rate | 5.4 Gbps |
Performance | Maximum data rate (2.4 GHz): 600 Mbps
Maximum data rate (5 GHz fronthaul): 2400 Mbps
Maximum data rate (5 GHz backhaul): 2400 Mbps |
Capacity | Concurrent devices: up to 75 |
Network / Transport Protocol | TCP/IP, PPTP, PPPoE, DHCP, SMB, DDNS, Bigpond |
Routing Protocol | RIP-1, RIP-2 |
Intelligent Assistant | Google Assistant, Alexa |
Features | Sync button, MU-MIMO technology, Tri-Band, PSK, guest access, Explicit Beamforming, Implicit Beamforming, 4K/8K UHD video streaming, NETGEAR Smart Parental Controls |
Compliant Standards | IEEE 802.11i, UPnP |
Power | AC 240 V (50 Hz) |
Dimensions (WxDxH) | 16.764 cm x 6.35 cm x 21.082 cm |
Weight | 725.75 g |
Documents
Extended Specifications
General
Device Type | Wi-Fi system – mesh – 3-port switch (integrated) |
|---|
Wi-Fi System Components | Router, 2 extenders |
|---|
Wi-Fi System Coverage | Up to 525 sq.m |
|---|
Enclosure Type | Desktop |
|---|
Connectivity Technology | Wireless, wired |
|---|
Data Link Protocol | Ethernet, Fast Ethernet, Gigabit Ethernet, IEEE 802.11b, IEEE 802.11a, IEEE 802.11g, IEEE 802.11n, IEEE 802.11ac, IEEE 802.11ax (Wi-Fi 6) |
|---|
Frequency Band | 2.4 GHz (1 band) / 5 GHz (2 bands) |
|---|
Data Transfer Rate | 5.4 Gbps |
|---|
Performance | Maximum data rate (2.4 GHz): 600 Mbps
Maximum data rate (5 GHz fronthaul): 2400 Mbps
Maximum data rate (5 GHz backhaul): 2400 Mbps |
|---|
Capacity | Concurrent devices: up to 75 |
|---|
Network / Transport Protocol | TCP/IP, PPTP, PPPoE, DHCP, SMB, DDNS, Bigpond |
|---|
Routing Protocol | RIP-1, RIP-2 |
|---|
Encryption Algorithm | TKIP, WPA-PSK, 128-bit AES, WPA2-PSK, WPA3-Personal |
|---|
Wi-Fi Rating | AX5400 |
|---|
Mesh Networking | Yes |
|---|
Features | Sync button, MU-MIMO technology, Tri-Band, PSK, guest access, Explicit Beamforming, Implicit Beamforming, 4K/8K UHD video streaming, NETGEAR Smart Parental Controls |
|---|
Compliant Standards | IEEE 802.11i, UPnP, ICES-003 Class B, AS/NZS CISPR 32 Class B, EN 55032, FCC Part 15 Subpart B Class B, EN 55035 Class B |
|---|
Processor | 1 GHz |
|---|
RAM | 1 GB |
|---|
Flash Memory | 4 GB |
|---|
Line Properties
Line Coding Format | 1024 QAM |
|---|
Internet of Things (IoT)
Internet of Things (IoT) Compatible | Yes |
|---|
Intelligent Assistant | Google Assistant, Alexa |
|---|
Expansion / Connectivity
Interfaces | WAN: 1 x 10Base-T/100Base-TX/1000Base-T – RJ-45
LAN: 3 x 10Base-T/100Base-TX/1000Base-T – RJ-45
LAN: 2 x 10Base-T/100Base-TX/1000Base-T – RJ-45 – on extender |
|---|
Aerial
Aerial | Internal |
|---|
Antenna Qty | 4 |
|---|
Power
Power Device | External power adapter |
|---|
Installed Qty | 3 |
|---|
Voltage Required | AC 240 V (50 Hz) |
|---|
Miscellaneous
Cables Included | 1 x network cable – 2 m |
|---|
Software / System Requirements
Software Included | NETGEAR Armor (1-year subscription) |
|---|
Dimensions & Weight
Width | 16.764 cm |
|---|
Depth | 6.35 cm |
|---|
Height | 21.082 cm |
|---|
Weight | 725.75 g |
|---|
Environmental Parameters
Min Operating Temperature | 0 °C |
|---|
Max Operating Temperature | 40 °C |
|---|
Humidity Range Operating | 90% RH (non-condensing) |
|---|
