Description
The Schneider Electric Easy UPS 3S Pro E3SP20KHB offers reliable power protection for critical applications. Designed to operate within a temperature range of 0°C to 40°C and a humidity range of 0 to 95%, this UPS ensures optimal performance in various environments. With an output power of 20 kW and a power capacity of 20000 VA, it effectively meets the demands of power-intensive equipment while featuring double conversion technology for efficiency. The integrated touchscreen LCD display provides real-time monitoring and control, improving user experience and device management.
Compliant with multiple international standards, including IEC/EN 62040-1, IEC/EN 62040-2, and IEC/EN 62040-3, this UPS demonstrates its reliability and safety. Its external form factor, along with a hardwire input connector and 3-phase input wiring, simplifies installation while ensuring robust connectivity. With low total harmonic distortion (THD) of 3% and a power factor of 0.7, it efficiently provides clean and stable power supply for sensitive electronic equipment.
- Provides reliable power protection for critical applications
- Supports operating temperatures from 0°C to 40°C
- Integrated touchscreen LCD display for user-friendly management
- Compliant with multiple international standards for safety and reliability
- Double conversion technology enhances power efficiency
- Robust power capacity
With a power capacity of 20000 VA and output power of 20 kW, the UPS is equipped to handle high-power demands effectively. - Versatile operating environment
Designed to function in a wide range of environments with operational temperatures from 0°C to 40°C and humidity levels up to 95%. - User-friendly interface
The touchscreen LCD display allows for easy monitoring and management of power settings and status, enhancing user interactions. - Compliance with standards
Meets IEC/EN standards for safety and performance, ensuring the UPS is a reliable choice for various applications. - Efficient power delivery
Features double conversion technology and low total harmonic distortion, providing clean and stable power for sensitive devices.
Main Specifications
Product Description | Schneider Electric Easy UPS 3S Pro E3SP20KHB – UPS – 20 kW – 20000 VA |
Device Type | UPS – external |
Weight | 119 kg |
Input Wiring | 3-phase |
Input Voltage | AC 380/400/415 V |
Output Voltage | AC 380/400/415 V ± 10% |
Power Capacity | 20 kW / 20000 VA |
Input Connectors | Hardwire |
Output connectors | Hardwire – 400 V |
Included Accessories | Dust filter |
Colour | White |
Dimensions (WxDxH) | 38 cm x 90.7 cm x 140 cm |
Extended Specifications
General
Device Type | UPS – external |
|---|
Colour | White |
|---|
Power Device
UPS Technology | On-line |
|---|
Input Voltage | AC 380/400/415 V |
|---|
Frequency Provided | 50/60 Hz ± 0.1% |
|---|
Input Wiring | 3-phase |
|---|
Frequency Required | 40 – 70 Hz |
|---|
Input Connectors | Hardwire |
|---|
Power Output Connectors Details | Hardwire – 400 V |
|---|
Output Voltage | AC 380/400/415 V ± 10% – 50/60 Hz |
|---|
Power Capacity | 20 kW / 20000 VA |
|---|
Power Factor (PF) | 0.7 |
|---|
Total Harmonic Distortion (THD) | 3 % |
|---|
Miscellaneous
Included Accessories | Dust filter |
|---|
Features | PCE package, 3:1 max crest factor, double conversion, touch screen LCD display |
|---|
Compliant Standards | IEC/EN 62040-1, IEC/EN 62040-2, IEC/EN 62040-3, ISTA 2B, IP20 |
|---|
Environmental Parameters
Min Operating Temperature | 0 °C |
|---|
Max Operating Temperature | 40 °C |
|---|
Humidity Range Operating | 0 – 95% |
|---|
Sound Emission | 57 dB |
|---|
Dimensions & Weight
Width | 38 cm |
|---|
Depth | 90.7 cm |
|---|
Height | 140 cm |
|---|
Weight | 119 kg |
|---|
