Description
The Schneider Electric Easy UPS 3S Pro E3SP10KH is a robust solution designed for reliable power backup and management. This UPS provides a power capacity of 10 kW and operates within a temperature range of 0°C to 40°C, making it suitable for various environments. With its 3-phase input wiring and support for external batteries, this UPS is ideal for applications that require uninterrupted power supply.
Equipped with a touchscreen LCD display, the E3SP10KH enables easy monitoring and management of power usage. It adheres to multiple compliant standards, ensuring safety and performance reliability. The design also boasts low sound emissions of 55 dB, minimizing disruption in any setting. This makes it an essential component for businesses looking to enhance operational resilience while maintaining efficient power management.
- Provides a power capacity of 10 kW
- Supports external batteries for extended backup
- Features a touchscreen LCD display for easy monitoring
- Maintains low sound emissions at 55 dB
- Complies with IEC/EN 62040 standards
- Reliable power management
The Schneider Electric Easy UPS 3S Pro E3SP10KH offers a power capacity of 10 kW, ensuring adequate support for critical operations. - User-friendly interface
Equipped with a touchscreen LCD display, users can efficiently monitor and manage power settings. - High environmental tolerance
With an operating temperature range from 0°C to 40°C and humidity tolerance of 0 to 95%, it performs well in various conditions. - Compliance with industry standards
Meets multiple IEC/EN 62040 standards, ensuring safety and reliability for power solutions. - Minimal sound disruption
Operating at 55 dB, this UPS provides quiet performance, suitable for office environments.
Main Specifications
Product Description | Schneider Electric Easy UPS 3S Pro E3SP10KH – UPS – 3:3, for external batteries – 10 kW – 10000 VA |
Device Type | UPS – external |
Weight | 35 kg |
Input Wiring | 3-phase |
Input Voltage | AC 380/400/415 V |
Output Voltage | AC 400 V |
Power Capacity | 10 kW / 10000 VA |
Included Accessories | Dust filter |
Colour | White |
Dimensions (WxDxH) | 25 cm x 66 cm x 62.9 cm |
Extended Specifications
General
Device Type | UPS – external |
|---|
Colour | White |
|---|
Power Device
Input Voltage | AC 380/400/415 V |
|---|
Frequency Provided | 50/60 Hz |
|---|
Input Wiring | 3-phase |
|---|
Frequency Required | 40 – 70 Hz |
|---|
Output Voltage | AC 400 V 50/60 Hz |
|---|
Power Capacity | 10 kW / 10000 VA |
|---|
Power Factor (PF) | 0.7 |
|---|
Total Harmonic Distortion (THD) | 3 % |
|---|
Miscellaneous
Included Accessories | Dust filter |
|---|
Features | PCE package, touch screen LCD display |
|---|
Compliant Standards | IEC/EN 62040-1, IEC/EN 62040-2, IEC/EN 62040-3, IP20 |
|---|
Environmental Parameters
Min Operating Temperature | 0 °C |
|---|
Max Operating Temperature | 40 °C |
|---|
Humidity Range Operating | 0 – 95% |
|---|
Sound Emission | 55 dB |
|---|
Dimensions & Weight
Width | 25 cm |
|---|
Depth | 66 cm |
|---|
Height | 62.9 cm |
|---|
Weight | 35 kg |
|---|
Dimensions & Weight (Shipping)
Shipping Width | 38 cm |
|---|
Shipping Depth | 78 cm |
|---|
Shipping Height | 81.3 cm |
|---|
Shipping Weight | 50 kg |
|---|
