Description
For IT professionals in small to medium businesses, EasyUPS Online provides basic power protection for unstable power conditions, ensuring consistent and reliable connectivity at the most critical moments. APC Easy UPS Online is a versatile, high quality, cost competitive UPS developed to handle a wide voltage range, and inconsistent power conditions; delivering the quality millions of IT professionals trust around the world. That’s Certainty in a Connected World.
- Scalable runtime
- ECO mode/green mode
- Generator compatible
- Intelligent battery management
- OVCD (Overvoltage Cutoff Device) protection
- Input power factor connection
- Excellent power quality and performance
- Built-in automatic bypass
- Power conditioning
- Scalable runtime
The capability to add external battery packs to provide extended runtime, fulfilling the needs of long run time applications. - ECO mode/green mode
This is an energy saving mode and the input voltage regulation range can be set/ modified through the LCD display. - Generator compatible
Ensures clean, uninterrupted power to the loads in the event of an extended power outage. - Intelligent battery management
Maximizes battery performance, life, and reliability through intelligent precision temperature compensated charging. - OVCD (Overvoltage Cutoff Device) protection
Under special application with high voltage condition, OVCD protection will prevent the damage of UPS components and extend the life of the UPS. - Input power factor connection
Minimizes installation costs by enabling the use of smaller generators and cabling. - Excellent power quality and performance
True double conversion – provides tight voltage and frequency regulation and zero transfer time for reactive loads (machinery, lab equipment, etc.). - Built-in automatic bypass
Ensures seamless power to the load even in the event of catastrophic UPS failure. - Power conditioning
Protects connected loads from surges, spikes, lightning, and other power disturbances.
Main Specifications
Product Description | APC Easy UPS SRV SRV10KRIL – UPS – 10000 watt – 10000 VA |
Device Type | UPS – rack-mountable |
Rack Size | 2U |
Weight | 16 kg |
Input Wiring | 1-phase |
Input Voltage | AC 220-240 V |
Output Voltage | AC 220/230/240 V ± 1% |
Power Capacity | 10000 watt / 10000 VA |
Input Connectors | 1 x terminal block |
Output connectors | 1 x terminal block |
Battery | Lead Acid |
Batteries Qty | 1 |
Networking | USB, RS-232 |
Included Accessories | External battery pack |
Dimensions (WxDxH) | 43.8 cm x 61.5 cm x 8.65 cm |
Extended Specifications
Power Device
Frequency Provided | 50/60 Hz ± 4Hz |
|---|
Input Wiring | 1-phase |
|---|
Frequency Required | 50/60 Hz |
|---|
Input Connectors | 1 x terminal block |
|---|
Power Output Connectors Details | 1 x terminal block |
|---|
Output Voltage | AC 220/230/240 V ± 1% – 50/60 Hz |
|---|
Power Capacity | 10000 watt / 10000 VA |
|---|
Output Waveform | Sinewave |
|---|
Surge Energy Rating | 600 joules |
|---|
Circuit Protection | Circuit breaker |
|---|
Efficiency | 94% AC mode |
|---|
Power Factor (PF) | 0.99 |
|---|
Battery
Quantity | 1 |
|---|
Technology | Lead Acid |
|---|
Features | Sealed, maintenance free |
|---|
Networking
Remote Management Interface | USB, RS-232 |
|---|
Expansion / Connectivity
Interfaces | 1 x management (USB)
1 x management (RS-232) |
|---|
Miscellaneous
Included Accessories | External battery pack |
|---|
Features | LCD display, Eco-Mode, generator compatible, over voltage protection, internal bypass, firmware upgradable |
|---|
Software / System Requirements
Software Included | APC Easy Ups Online SNMP Shutdown Wizard |
|---|
Environmental Parameters
Min Operating Temperature | 0 °C |
|---|
Max Operating Temperature | 40 °C |
|---|
Humidity Range Operating | 0 – 95% (non-condensing) |
|---|
Sound Emission | 58 dB |
|---|
Dimensions & Weight
Width | 43.8 cm |
|---|
Depth | 61.5 cm |
|---|
Height | 8.65 cm |
|---|
Weight | 16 kg |
|---|
General
Device Type | UPS – rack-mountable |
|---|
Height (Rack Units) | 2U |
|---|
Power Device
UPS Technology | On-line |
|---|
Input Voltage | AC 220-240 V |
|---|
Input Voltage Range | AC 110 – 300 V |
|---|
