RF elements HG3-CC-S90, Aerial, horn, radio, 9.6 dBi, pole mount
$130.29 inc GST
✓ In Stock - 1 available
✓ Free NZ Delivery
1 in stock (can be backordered)
- Allow 2–3 days for delivery to the North Island
- Allow 1–2 days for delivery to the South Island
- Add 1–2 days if you are rural
- Collection can be arranged
Description
The RF elements HG3-CC-S90 antenna features a horn design with a gain of 9.6 dBi, ideal for radio applications. It is built to withstand harsh environmental conditions, having an IP55 rating and a maximum wind speed resistance of 160 km/h. This reliability is further enhanced by its dual linear polarization and anti-UV coating, ensuring consistent performance under various circumstances.
Constructed from a combination of UV-resistant polycarbonate, polypropylene, aluminum, zinc, and stainless steel, this antenna provides durability while maintaining an aesthetically pleasing profile. It includes a mounting kit for easy installation on poles. With a frequency range of 5180 – 6400 MHz and a low Voltage Standing Wave Ratio (VSWR) of 1.6 to 1.9, the HG3-CC-S90 is designed to deliver signal quality for all your radio needs.
- Horn design with 9.6 dBi gain for signal strength
- IP55 rating ensures protection against dust and water
- Maximum wind speed resistance of 160 km/h
- Durable construction using UV-resistant materials
- Includes a mounting kit for easy pole installation
- Reliable performance
The antenna operates within a frequency range of 5180 – 6400 MHz, providing flexibility for various radio applications while maintaining a low VSWR of 1.6 for 5180 – 5850 MHz and 1.9 for 5850 – 6400 MHz. - Durable construction
Crafted with materials such as UV-resistant polycarbonate, aluminum, and stainless steel, this antenna is designed to withstand harsh weather and environmental factors, ensuring long-lasting performance. - Easy installation
The included mounting kit allows for simple and secure pole mounting, facilitating quick setup and stable positioning. - High wind resistance
Designed to endure high wind loads up to 10 N at 160 km/h, making it suitable for installations in challenging outdoor conditions. - Flame retardant features
With a UL 94-HB rating, this antenna includes flame retardant properties enhancing its safety in various environments.
Main Specifications
Product Description | RF elements HG3-CC-S90 – aerial |
Device Type | Aerial |
Form Factor | Horn |
Intended For | Radio |
Aerial Placing / Mounting | Pole mount |
Dimensions (WxDxH) | 15.2 cm x 15.7 cm x 15.2 cm |
Weight | 1.8 kg |
Frequency Range | 5180 – 6400 MHz |
Gain | 9.6 dBi |
Features | IP55, UL 94-HB, flame retardant, dual linear polarisation, anti-UV coating, VSWR 1.6 (for 5180 – 5850 MHz), VSWR 1.9 (for 5850 – 6400 MHz) |
Extended Specifications
General
Product Type | Aerial |
|---|---|
Form Factor | Horn |
Intended For | Radio |
Aerial Placing / Mounting | Pole mount |
Width | 15.2 cm |
Depth | 15.7 cm |
Height | 15.2 cm |
Weight | 1.8 kg |
Product Material | UV-resistant polycarbonate, polypropylene, aluminium, zinc, stainless steel |
Aerial
Frequency Range | 5180 – 6400 MHz |
|---|---|
Impedance | 50 ohm |
Gain | 9.6 dBi |
Max Wind Speed | 160 km/h |
Wind Load | 10 N (at 160 km/h) |
Features | IP55, UL 94-HB, flame retardant, dual linear polarisation, anti-UV coating, VSWR 1.6 (for 5180 – 5850 MHz), VSWR 1.9 (for 5850 – 6400 MHz) |
Mounting Kit | Included |
Connector Provided
Type | 2 x antenna – N connector (female) |
|---|
Dimensions & Weight (Shipping)
Shipping Width | 30.5 cm |
|---|---|
Shipping Depth | 23.9 cm |
Shipping Height | 18.3 cm |
Shipping Weight | 2.6 kg |
