Description
The Teltonika TSF010 switch is engineered to meet the demands of modern industrial environments. With a 10 Gbps non-blocking bandwidth, it ensures smooth and efficient data transmission, making it suitable for a variety of applications. The switch’s aluminum housing and DIN rail mountability offer a robust solution for challenging settings, while its five 10/100 Base-T ports provide flexible connectivity options. It supports key IEEE standards, including 802.3ab and 802.3az, as well as jumbo frames up to 9216 bytes, enhancing network efficiency and reducing energy consumption. Designed to operate within a broad range of temperatures and humidity levels, the TSF010 delivers reliable performance under extreme conditions, making it a versatile choice for any network infrastructure.
- 10 Gbps non-blocking bandwidth for efficient data flow
- Aluminum housing and DIN rail mountable for industrial durability
- Five 10/100 Base-T ports for versatile connectivity
- Supports IEEE 802.3ab, 802.3az, and jumbo frames for optimized network efficiency
- Operates reliably across a wide temperature range and humidity levels
- Robust performance
With a non-blocking bandwidth of 10 Gbps, the Teltonika TSF010 ensures efficient data flow, making it suitable for high-demand environments. - Durable design
The switch features an aluminum housing and is DIN rail mountable, offering a durable solution for industrial settings. - Versatile connectivity
Equipped with five RJ-45 connectors supporting 10/100 Base-T, the TSF010 provides flexible connection options for a variety of network needs. - Enhanced network efficiency
Support for IEEE standards including 802.3ab, 802.3az, and jumbo frame support up to 9216 bytes optimizes network traffic and energy use. - Reliable operation
Designed to operate in a wide range of temperatures and humidity levels, ensuring reliable performance in challenging environmental conditions.
Main Specifications
Product Description | Teltonika TSF010 – switch – 5 ports – unmanaged |
Device Type | Switch – 5 ports – unmanaged |
Ports | 5 x 10/100 |
Performance | Non-blocking bandwidth: 10 Gbps |
Capacity | Packet buffer size: 128 KB |
MAC Address Table Size | 2K entries |
Jumbo Frame Support | 9216 bytes |
Features | Auto-uplink (auto MDI/MDI-X), ground points, anodised aluminium housing |
Compliant Standards | IEEE 802.3i, IEEE 802.3u, IEEE 802.3x, IEEE 802.3ab, IEEE 802.3az |
Dimensions (WxDxH) | 11.3 cm x 5 cm x 2.8 cm |
Weight | 142 g |
Extended Specifications
General
Device Type | Switch – 5 ports – unmanaged |
|---|
Enclosure Type | DIN rail mountable |
|---|
Ports | 5 x 10/100 |
|---|
Performance | Non-blocking bandwidth: 10 Gbps |
|---|
Capacity | Packet buffer size: 128 KB |
|---|
MAC Address Table Size | 2K entries |
|---|
Jumbo Frame Support | 9216 bytes |
|---|
Features | Auto-uplink (auto MDI/MDI-X), ground points, anodised aluminium housing |
|---|
Compliant Standards | IEEE 802.3i, IEEE 802.3u, IEEE 802.3x, IEEE 802.3ab, IEEE 802.3az |
|---|
Status Indicators | Power, Ethernet link/activity |
|---|
Expansion / Connectivity
Interfaces | 5 x 10/100 Base-T RJ-45 |
|---|
Power
Power Consumption Operational | 1 watt |
|---|
Miscellaneous
Included Accessories | 3-pin power terminal block |
|---|
Compliant Standards | IP30 |
|---|
Dimensions & Weight
Width | 11.3 cm |
|---|
Depth | 5 cm |
|---|
Height | 2.8 cm |
|---|
Weight | 142 g |
|---|
Dimensions & Weight (Shipping)
Shipping Width | 14 cm |
|---|
Shipping Depth | 5.5 cm |
|---|
Shipping Height | 3.2 cm |
|---|
Environmental Parameters
Min Operating Temperature | -40 °C |
|---|
Max Operating Temperature | 75 °C |
|---|
Humidity Range Operating | 5 – 95% (non-condensing) |
|---|
