Description
The MSI Modern AM242TP 1M 2404NZ all-in-one is designed for everyday productivity and collaborative work in home and office settings. The 23.8-inch Full HD IPS touchscreen with anti-glare coating and adjustable stand supports 10-point multi-touch interaction and wide viewing angles for comfortable shared use and hands-on control. A 10-core Intel Core 5 120U processor teamed with 8 GB of DDR5 memory and a 512 GB NVMe PCIe 4.0 SSD delivers responsive multitasking and fast application load times while integrated Intel graphics handle everyday visual tasks. Connectivity includes Wi-Fi 6E, Bluetooth 5.3, Gigabit Ethernet, HDMI input and output, USB-C and multiple USB ports to support peripherals and external displays. The built-in Full HD webcam with Windows Hello, stereo speakers, TPM 2.0 security chip, and a Kensington security slot help protect data and enable secure, convenient collaboration.
- Responsive performance for multitasking
- Interactive Full HD touchscreen with adjustable stand
- Fast NVMe storage and DDR5 memory for quick access
- Modern connectivity with Wi-Fi 6E Bluetooth 5.3 and HDMI input
- Built-in webcam with Windows Hello and TPM 2.0 security
- Vibrant touchscreen display
The 23.8-inch Full HD IPS touchscreen provides wide 178-degree viewing angles, anti-glare coating, and adjustable height and tilt for comfortable, shared viewing and precise touch control. - Efficient performance
A 10-core Intel Core 5 120U processor with Intel Smart Cache and 8 GB of DDR5 memory helps maintain smooth responsiveness for everyday productivity and multitasking. - High-speed storage
The 512 GB M.2 NVMe PCIe 4.0 SSD delivers fast system boot and application load times while offering ample space for files and projects. - Comprehensive connectivity
Integrated Wi-Fi 6E, Bluetooth 5.3, Gigabit Ethernet, HDMI input and output, USB-C and multiple USB ports provide flexible options for networks, displays, and peripherals. - Secure collaboration
A Full HD webcam with Windows Hello support, TPM 2.0 security chip, and a Kensington security slot enable secure sign-in and physical protection for shared work environments.
Main Specifications
Product Description | MSI Modern AM242TP 1M 2404NZ – all-in-one Core 5 120U 1.4 GHz – 8 GB – SSD 512 GB – LED 23.8″ |
Type | Personal computer – all-in-one |
Processor | Intel Core 5 (Series 1) 120U / 1.4 GHz (up to 5 GHz, (10-core) |
Processor Main Features | Intel Smart Cache |
Cache Memory | 12 MB |
Cache Per Processor | 12 MB |
RAM | 8 GB (installed) / 64 GB (max) – DDR5 SDRAM |
Storage Controller | SATA (SATA 6Gb/s) |
Hard Drive | SSD 512 GB – PCI Express 4.0 x4 – M.2 – NVM Express (NVMe) |
Optical Storage | No optical drive |
Monitor | 23.8″ – LED – 1920 x 1080 (Full HD) @ 75 Hz – touchscreen |
Graphics Controller | Intel Graphics |
Camera | Yes |
Audio Output | Stereo |
Networking | 1GbE, Wi-Fi 6E, 802.11a, Wi-Fi 5, 802.11b/g/n, Bluetooth 5.3 |
OS Provided | Windows 11 Home |
Colour | White |
Documents
Extended Specifications
General
Type | Personal computer |
|---|
Product Form Factor | All-in-one – with adjustable stand |
|---|
Embedded Security | Discrete Trusted Platform Module (TPM 2.0) Security Chip |
|---|
Colour | White |
|---|
Processor / Chipset
CPU | Intel Core 5 (Series 1) 120U |
|---|
Clock Speed | 1.4 GHz (P-core) / 900 MHz (E-core) |
|---|
Max Turbo Speed | 5 GHz (P-core) / 3.8 GHz (E-core) |
|---|
Number of Cores | 10-core |
|---|
CPU Qty | 1 |
|---|
Max CPU Qty | 1 |
|---|
Processor Main Features | Intel Smart Cache |
|---|
Cache Memory
Installed Size | 12 MB |
|---|
Cache Per Processor | 12 MB |
|---|
RAM
Installed Size | 8 GB (installed) / 64 GB (max) |
|---|
Technology | DDR5 SDRAM |
|---|
Effective Memory Speed | 5600 MT/s |
|---|
Rated Memory Speed | 5600 MT/s |
|---|
Form Factor | SO-DIMM 262-pin |
|---|
Slots | 2 (Total) / 1 (empty) |
|---|
Configuration Features | 1 x 8 GB |
|---|
Hard Drive
Type | SSD – M.2 |
|---|
Capacity | 1 x 512 GB |
|---|
Interface Type | PCI Express 4.0 x4 |
|---|
Features | NVM Express (NVMe) |
|---|
Storage Controller
Type | 1 x SATA |
|---|
Controller Interface Type | SATA 6Gb/s |
|---|
Optical Storage
Monitor
Monitor Type | LED – IPS |
|---|
Touchscreen | Yes (10-point multi-touch) |
|---|
Diagonal Size | 23.8″ |
|---|
Native Resolution | 1920 x 1080 (Full HD) |
|---|
V-Sync Rate at Max Res. | 75 Hz |
|---|
Widescreen Display | Yes |
|---|
Horizontal Viewing Angle | 178 |
|---|
Vertical Viewing Angle | 178 |
|---|
Response Time | 14 ms |
|---|
Image Brightness | 250 cd/m² |
|---|
Image Contrast Ratio | 1000:1 |
|---|
Monitor Features | Anti-glare, adjustable height (130 mm), tilt stand (-5°- 20°) |
|---|
Graphics Controller
Graphics Processor | Intel Graphics |
|---|
Video Interfaces | HDMI |
|---|
Audio Output
Sound Output Mode | Stereo |
|---|
Speakers Included | 2 |
|---|
Camera
Camera | Yes |
|---|
Resolution | Full HD |
|---|
Features | Windows Hello |
|---|
Mouse
Mouse Name | SM9023MW |
|---|
Interface | USB |
|---|
Networking
Ethernet Controller | Realtek RTL8111H |
|---|
Wireless LAN Supported | Yes |
|---|
Wireless NIC | Intel Wireless-AC 9462 |
|---|
Data Link Protocol | Ethernet, Fast Ethernet, Gigabit Ethernet, IEEE 802.11ax (Wi-Fi 6E), IEEE 802.11b, IEEE 802.11a, IEEE 802.11ac, IEEE 802.11g, IEEE 802.11n, Bluetooth 5.3 |
|---|
Expansion / Connectivity
Bays | 1 (total) / 1 (free) x internal 2.5″ |
|---|
Interfaces | 1 x headphones/microphone (1 side)
1 x LAN (Gigabit Ethernet) (1 rear)
1 x HDMI output (1 rear)
2 x USB 2.0 (2 rear)
2 x USB 3.2 Gen 2 (2 side)
1 x HDMI input (1 rear)
2 x USB-C 3.2 Gen 2 (2 side) |
|---|
Miscellaneous
Included Accessories | Power adapter, power cord |
|---|
Theft/Intrusion Protection | Security lock slot (cable lock sold separately) |
|---|
Security Slot Type | Kensington security slot |
|---|
VESA Mounting Interface | 75 x 75 mm |
|---|
Compliant Standards | FCC Class B certified, CB, UL, BSMI, RCM, C-Tick, cUL, VCCI |
|---|
Power
Device Type | Power adapter |
|---|
Power Provided | 120 watt |
|---|
Operating System / Software
OS Provided | Windows 11 Home |
|---|
Dimensions & Weight (Shipping)
Shipping Width | 65.2 cm |
|---|
Shipping Depth | 22.2 cm |
|---|
Shipping Height | 45.5 cm |
|---|
Environmental Parameters
Min Operating Temperature | 0 °C |
|---|
Max Operating Temperature | 35 °C |
|---|
Humidity Range Operating | 0 – 85% |
|---|
