Description
The HPE ProLiant DL145 Gen11 is engineered for performance and flexibility in a rack-mountable design. It features a robust AMD EPYC processor with a maximum turbo speed of 2.95 GHz, ensuring efficient processing capabilities to handle demanding tasks. With the ability to accommodate up to 6 slots of DDR5 SDRAM, this server supports HPE SmartMemory and offers reliable memory speed of 2400 MHz for enhanced data handling and performance.
Designed for seamless operation, the server includes hot-swap bays for easy maintenance and upgrades. Connectivity options include multiple Gigabit Ethernet ports and a range of interfaces such as DisplayPort and USB 3.2 Gen 1 for versatile connections. Compliance with numerous standards ensures that the HPE ProLiant DL145 Gen11 meets various operational requirements, making it a suitable choice for diverse networking and computing environments.
- Rack-mountable form factor allows efficient space utilization
- Hot-swap bays facilitate easy upgrades and maintenance
- Supports up to 6 slots of DDR5 SDRAM for reliable performance
- Equipped with multiple Gigabit Ethernet ports for robust networking
- Compliant with various industry standards for operational reliability
- Efficient processing capabilities
The HPE ProLiant DL145 Gen11 is powered by an AMD EPYC processor, capable of delivering a maximum turbo speed of 2.95 GHz, ensuring high performance for demanding applications. - Flexible memory configuration
With the ability to support up to 6 slots of DDR5 SDRAM, this server is designed to handle extensive workloads and provides reliable memory speed of 2400 MHz for enhanced performance. - Accessible hot-swap bays
Featuring hot-swap bays, the server allows for easy installation and replacement of storage components without downtime, ensuring continuity of service. - Robust networking options
The server includes 4 Gigabit Ethernet ports and multiple connection interfaces, providing flexible networking solutions for a variety of environments. - Compliance with industry standards
The HPE ProLiant DL145 Gen11 meets numerous compliance standards, ensuring it is equipped to perform reliably in a range of operational settings.
Main Specifications
Product Description | HPE ProLiant DL145 Gen11 – rack-mountable EPYC 8024P 2.4 GHz – 32 GB – no HDD |
Type | Server – rack-mountable |
Height (Rack Units) | 2U |
Server Scalability | 1-way |
Processor | 1 x AMD EPYC 8024P / 2.4 GHz (up to 3 GHz, (8-core) |
Cache Memory | 32 MB L3 Cache |
Cache Per Processor | 32 MB |
RAM | 32 GB (installed) / 768 GB (max) – DDR5 SDRAM – Advanced ECC |
Storage Controller | NVMe (HPE NS204i-u) |
Server Storage Bays | Hot-swap 2.5″ |
Hard Drive | No HDD |
Optical Storage | No optical drive |
Video Memory | 16 MB |
Networking | 1GbE |
Power Redundancy | Optional |
OS Provided | No operating system |
Software Included | HPE iLO Standard with Intelligent Provisioning, HPE OneView Standard (free download) |
Dimensions (WxDxH) | 38.44 cm x 50.74 cm x 8.75 cm |
Weight | 15.61 kg |
Environmental Standards | ENERGY STAR Qualified EPEAT Bronze |
Documents
Extended Specifications
General
Type | Server |
|---|
Product Form Factor | Rack-mountable – 2U |
|---|
Built-in Devices | Led panel |
|---|
Embedded Security | Trusted Platform Module (TPM 2.0) Security Chip |
|---|
Server Scalability | 1-way |
|---|
Front Accessible Bays Qty | 2 |
|---|
Hot-Swap Bays Qty | 2 |
|---|
Processor / Chipset
CPU | AMD EPYC 8024P |
|---|
Clock Speed | 2.4 GHz |
|---|
Max Turbo Speed | 3 GHz |
|---|
Number of Cores | 8-core |
|---|
CPU Qty | 1 |
|---|
Max CPU Qty | 1 |
|---|
CPU Upgradability | Upgradable |
|---|
Cache Memory
Installed Size | L3 Cache – 32 MB |
|---|
Cache Per Processor | 32 MB |
|---|
RAM
Installed Size | 32 GB (installed) / 768 GB (max) |
|---|
Technology | DDR5 SDRAM – Advanced ECC |
|---|
Effective Memory Speed | 4800 MT/s |
|---|
Rated Memory Speed | 4800 MT/s |
|---|
Form Factor | DIMM 288-pin |
|---|
Slots | 6 (Total) / 4 (empty) |
|---|
Features | Registered, HPE SmartMemory |
|---|
Configuration Features | 2 x 16 GB |
|---|
Hard Drive
Storage Controller
Type | 1 x NVMe |
|---|
Storage Controller Name | HPE NS204i-u |
|---|
Optical Storage
Monitor
Graphics Controller
Video Memory | 16 MB |
|---|
Video Interfaces | DisplayPort |
|---|
Networking
Interface (Bus) Type | Open Compute Project mezzanine (OCP) 3.0 |
|---|
Ethernet Ports | 4 x Gigabit Ethernet |
|---|
Ethernet Controller | Broadcom BCM5719 |
|---|
Data Link Protocol | Ethernet, Fast Ethernet, Gigabit Ethernet |
|---|
Remote Management Controller | Integrated Lights-Out 6 |
|---|
Expansion / Connectivity
Slots | 2 (total) / 2 (free) x PCIe 5.0 x16 – full-length, full-height
1 (total) / 1 (free) x PCIe 5.0 x16 – half-length, full-height
1 (total) / 0 (free) x PCIe 5.0 x16 / Open Compute Project mezzanine (OCP) 3.0 |
|---|
Interfaces | 1 x HPE iLO (1 front) (service port)
1 x HPE iLO – RJ-45 (1 front) (management port)
4 x USB 3.2 Gen 1 (4 front)
1 x DisplayPort
4 x LAN (Gigabit Ethernet) |
|---|
Miscellaneous
Included Accessories | 4 standard fans |
|---|
Theft/Intrusion Protection | Security lock slot (cable lock sold separately) |
|---|
Security Slot Type | Kensington security slot |
|---|
Compliant Standards | AES, NEBS, TLS v1.2, low halogen, ASHRAE Class A4, ASHRAE Class A3, ACPI 6.1, UL 62368-1, Redfish API, UEFI, SMBIOS 3.1, PCIe 5.0, UEFI 2.7, APML 1.0, DMTF, Active Directory v1.0, UEFI Class 3 |
|---|
Power
Device Type | Power supply – hot-plug |
|---|
Power Redundancy | Optional |
|---|
Installed Qty | 2 |
|---|
Max Supported Qty | 2 |
|---|
Voltage Required | AC 100-240 V |
|---|
Power Provided | 700 watt |
|---|
Operating System / Software
OS Provided | No operating system |
|---|
Software | HPE iLO Standard with Intelligent Provisioning, HPE OneView Standard (free download) |
|---|
Sustainability Information
EPEAT Compliant | EPEAT Bronze |
|---|
ENERGY STAR Certified | Yes |
|---|
ENERGY STAR Version | 4.0 |
|---|
Dimensions & Weight
Width | 38.44 cm |
|---|
Depth | 50.74 cm |
|---|
Height | 8.75 cm |
|---|
Weight | 15.61 kg |
|---|
Environmental Parameters
Min Operating Temperature | 10 °C |
|---|
Max Operating Temperature | 35 °C |
|---|
Humidity Range Operating | 8 – 90% RH (non-condensing) |
|---|
