HPE Aruba Networking BR-150 5G Cellular, Bridge 5G, 2.5GbE, 5G, 4G, BTO
$3,985.73 inc GST
Available on back-order
Ships from Auckland
- Allow 1-2 days for delivery to the North Island
- Allow 2-3 days for delivery to the South Island
- add 1-2 days if you are rural
- Collection can be arranged
We are currently experiencing shipping delays from this supplier warehouse
Description
The HPE Aruba Networking 100 Series Cellular Bridge is a cloud-managed 5G cellular wireless bridge for reliable, fast internet connectivity. Designed for primary, secondary, or backup cellular WAN connectivity, this cellular bridge provides fast and reliable 5G fixed wireless access for mission-critical use cases. Ideal for remote locations, branch offices, and pop-up sites, the cellular bridge supports 5G across major public and private cellular including CBRS, enabling reliable internet services with choice of connectivity. This cellular bridge is supported by HPE Aruba Networking Central that helps streamline IT operations with unified infrastructure management across wired, wireless, and SD-WAN with intelligent automation, and AI insights.
- The HPE Aruba Networking 100 Series Cellular Bridge provides 5G fixed wireless access for mission-critical connectivity in WLAN, SD-Branch, and SD-WAN use cases.
- The HPE Aruba Networking 100 Series Cellular Bridge customizes 5G cellular connectivity to branch offices and remote sites.
- The HPE Aruba Networking 100 Series Cellular Bridge is supported by cloud-native HPE Aruba Networking Wireless Operating System (AOS-10) which is the distributed network operating system working with HPE Aruba Networking Central that acts as the control layer for wireless devices.
- Simplicity and Performance
The HPE Aruba Networking 100 Series Cellular Bridge provides 5G fixed wireless access for mission-critical connectivity in WLAN, SD-Branch, and SD-WAN use cases.
The series supports the 5G SA standard, and backwards compatibility with 5G NSA and LTE.
The series provides two high-speed 2.5 GbE ports ideal for wired connectivity to Hewlett Packard Enterprise edge devices.
It has compact and fanless form factor with internal antennas and conveniently powered by either PoE (802.3at) or DC power. DC power adapter not included.
Enhanced security with Trusted Platform Module (TPM) that provides storage of credentials and keys, and boot code. - Cellular Bridge Connectivity for Branch Offices
The HPE Aruba Networking 100 Series Cellular Bridge customizes 5G cellular connectivity to branch offices and remote sites.
The series is configured as either primary, secondary, or backup 5G cellular link for business continuity.
It provides subscriber identity module (SIM) supports nano-SIM and eSIM deployments. - AI-powered Cloud Management
The HPE Aruba Networking 100 Series Cellular Bridge is supported by cloud-native HPE Aruba Networking Wireless Operating System (AOS-10) which is the distributed network operating system working with HPE Aruba Networking Central that acts as the control layer for wireless devices.
Intelligent automation, AI insights, and unified infrastructure management, delivered by AOS-10 and HPE Aruba Networking Central, simplify and power IT operations.
Flexible consumption with HPE Aruba Networking Central subscription-based licenses purchased on a per-device basis.
Main Specifications
Product Description | HPE Aruba Networking BR-150 5G Cellular – bridge – LTE – 5G, 4G – desktop |
Device Type | Bridge |
Enclosure Type | Desktop |
Mobile Communication Protocol | 4G LTE, 5G, LTE Advanced Cat 18, WCDMA |
Generation | 5G, 4G |
Cellular Band | 5G n1, 5G n2, 5G n3, 5G n5, 5G n7, 5G n8, 5G n12, 5G n13, 5G n14, 5G n18, 5G n20, 5G n25, 5G n26, 5G n28, 5G n29, 5G n30, 5G n38, 5G n40, 5G n41, 5G n48, 5G n66, 5g n70, 5G n71, 5G n75, 5G n76, 5G n77, 5G n78, 5G n79, LTE B1, LTE B2, LTE B3, LTE B4, LTE B5, LTE B7, LTE B8, LTE B12, LTE B13, LTE B14, LTE B17, LTE B18, LTE B19, LTE B20, LTE B25, LTE B26, LTE B28, LTE B29, LTE B30, LTE B32, LTE B66, LTE B71, LTE B34, LTE B38, LTE B39, LTE B40, LTE B41, LTE B42, LTE B43, LTE B48 |
Data Link Protocol | 5G, LTE, 2.5 Gigabit Ethernet |
Performance | 5G SA downstream: 2.4 Gbps 5G SA upstream: 900 Mbps 5G NSA downstream: 3.4 Gbps 5G NSA upstream: 500 Mbps LTE downstream: 1.6 Gbps LTE upstream: 200 Mbps WCDMA downstream: 42 Mbps WCDMA upstream: 5.76 Mbps |
Features | TPM, security slot (Kensington security lock compatible), PoE |
Compliant Standards | IEEE 802.3at |
Dimensions (WxDxH) | 22.3 cm x 14.5 cm x 5.1 cm |
Weight | 1.54 kg |
System Requirements | ArubaOS 10.7.1 |
Pricing Type | BTO |
Extended Specifications
General
Device Type | Bridge |
|---|---|
Enclosure Type | Desktop |
Connectivity Technology | Wireless, wired |
Data Link Protocol | 5G, LTE, 2.5 Gigabit Ethernet |
Performance | 5G SA downstream: 2.4 Gbps 5G SA upstream: 900 Mbps 5G NSA downstream: 3.4 Gbps 5G NSA upstream: 500 Mbps LTE downstream: 1.6 Gbps LTE upstream: 200 Mbps WCDMA downstream: 42 Mbps WCDMA upstream: 5.76 Mbps |
Features | TPM, security slot (Kensington security lock compatible), PoE |
Compliant Standards | IEEE 802.3at, UL 2043, UL 62368-1, IEC 62368-1, EN 62368-1, CAN/CSA-C22.2 No. 62368-1 Second Edition, CNS 15598-1, FCC Part 15 Class B, CISPR 32 Class B, EN55032 Class B, ICES-003 Class B, EN 61000-3-2, EN 61000-3-3, EN55035, EN 301 489-1, EN 301 489-19, EN 301 489-52, KN32 Class B, KN 301 489-1, KN 301 489-19, KN 301 489-52, EN 60601-1-2, CNS 15936, FCC, IC, RCM, PTCRB, GCF, ICASA, WHQL, RED 2014/53/EU, VCCI, NCC, ANATEL, IFETEL, CCC |
Status Indicators | System, cellular, status |
Communications
Mobile Communication Protocol | 4G LTE, 5G, LTE Advanced Cat 18, WCDMA |
|---|---|
Generation | 5G, 4G |
Cellular Band | 5G n1, 5G n2, 5G n3, 5G n5, 5G n7, 5G n8, 5G n12, 5G n13, 5G n14, 5G n18, 5G n20, 5G n25, 5G n26, 5G n28, 5G n29, 5G n30, 5G n38, 5G n40, 5G n41, 5G n48, 5G n66, 5g n70, 5G n71, 5G n75, 5G n76, 5G n77, 5G n78, 5G n79, LTE B1, LTE B2, LTE B3, LTE B4, LTE B5, LTE B7, LTE B8, LTE B12, LTE B13, LTE B14, LTE B17, LTE B18, LTE B19, LTE B20, LTE B25, LTE B26, LTE B28, LTE B29, LTE B30, LTE B32, LTE B66, LTE B71, LTE B34, LTE B38, LTE B39, LTE B40, LTE B41, LTE B42, LTE B43, LTE B48 |
Expansion / Connectivity
Interfaces | 2 x 2.5G Gigabit Ethernet – RJ-45 – interface 1 x USB – Type A – data port Console: 1 x USB – Type C |
|---|---|
Expansion Slots | 1 (total) / 1 (free) x Nano-SIM |
Power
Power Device | External power adapter / power injector (not included) |
|---|
Miscellaneous
MTBF | 1,715,003 hours |
|---|---|
Pricing Type | BTO |
Software / System Requirements
OS Required | ArubaOS 10.7.1 |
|---|
Dimensions & Weight
Width | 22.3 cm |
|---|---|
Depth | 14.5 cm |
Height | 5.1 cm |
Weight | 1.54 kg |
Environmental Parameters
Min Operating Temperature | 0 °C |
|---|---|
Max Operating Temperature | 50 °C |
Humidity Range Operating | 5 – 93% |
