TP-Link Omada SG2008P V3.36, switch, 8 ports, smart
$193.83 inc GST TP-Link Omada SG2008P V3.36, Switch, smart, 4 x 10/100/1000 + 4 x 10/100/1000 (PoE+), desktop, wall-mountable, PoE+ (62 W), for TP-Link MC200CM, MC210CS, MC220L

$193.83 inc GST

Available on back-order

Ships from Auckland, Wellington, or Christchurch
- Allow 1-2 days for delivery
- add 1-2 days if you are rural
- Collection can be arranged
Description
The TP-Link Omada SG2008P V3.36 is a powerful and efficient Gigabit Ethernet switch designed to meet the demands of modern networking. With a versatile 8-port configuration, it allows for seamless connectivity and enhanced network performance. Its support for Power over Ethernet (PoE+) ensures that devices can be powered directly through the Ethernet cable, simplifying installation and reducing the need for additional power sources. It comes equipped with advanced features such as Quality of Service (QoS), multicast filtering, and VLAN support, allowing for optimized traffic management and enhanced security within your network environment.
Built with reliability in mind, this switch operates in a wide temperature range, making it suitable for various environments. The fanless design ensures silent operation while the sturdy metal housing contributes to durability. Managed remotely through various protocols, such as HTTPS and SSH, it offers easy and efficient control over network settings. Whether for small businesses or home networks, the TP-Link Omada SG2008P V3.36 is an effective choice for a robust and manageable networking solution.
- 8 Gigabit Ethernet ports for fast and reliable connectivity
- Power over Ethernet (PoE+) capability for simplified device power management
- Quality of Service (QoS) features for optimized network traffic control
- Remote management options for efficient network administration
- Robust design with metal housing and fanless operation for durability
- Efficient bandwidth management
With a bandwidth capacity of 16 Gbps, the switch provides ample resources for high-speed data transfer across devices, ensuring smooth network performance. - High port capacity
The switch includes 8 ports, each capable of handling 10/100/1000 Mbps connections, accommodating a variety of devices for flexibility in network design. - Enhanced security features
Offering features such as DHCP snooping, ARP inspection, and 802.1x authentication, this switch helps safeguard the network against unauthorized access and attacks. - Temperature resilient design
Designed to function effectively in temperatures ranging from -5 °C to 40 °C, it can be deployed in diverse environments without compromising performance. - User-friendly management options
Supports multiple remote management protocols including HTTPS and SNMP, allowing for straightforward network monitoring and configuration from anywhere.
Main Specifications
Product Description | TP-Link Omada SG2008P V3.36 – switch – 8 ports – smart |
Device Type | Switch – 8 ports – smart |
Subtype | Gigabit Ethernet |
Ports | 4 x 10/100/1000 + 4 x 10/100/1000 (PoE+) |
Power Over Ethernet (PoE) | PoE+ |
PoE Budget | 62 W |
Performance | Bandwidth: 16 Gbps Packet forwarding rate: 11.90 Mpps Packet buffer size: 4.1 Mbit |
Capacity | Priority queues: 8 IPv4 groups (Multicast): 511 IPv6 groups (Multicast): 511 ACL entries: 230 Layer 2 multicast filtering entries per profile: 16 IP multicast profiles: 256 VLAN groups: 4000 MAC VLAN address entries: 12 IPv6 MAC port binding entries: 512 IPv4 source guard entries: 253 IPv6 source guard entries: 183 MAC addresses per port: 64 |
MAC Address Table Size | 8K entries |
Jumbo Frame Support | 9KB |
Routing Protocol | Static IP routing |
Remote Management Protocol | CLI, IPv4, IPv6, HTTPS, SSH, SSH-2, Telnet, HTTP, MIB 2, MIB, RMON 1, RMON 2, RMON 3, RMON 9, SNMP 1, SNMP 2c, SNMP 3, UDP, TCP/IP, BOOTP, TFTP |
Features | Reset button, fanless, metal housing, auto-negotiation, auto-uplink (auto MDI/MDI-X), security lock slot (cable lock sold separately), QoS, SP, WRR, Broadcast Storm Control, Multicast Storm Control, Unicast Storm Control, Unknown Storm Control, DHCP server, DHCP relay, Link Aggregation, loopback detection, flow control, port mirroring, DLDP support, LLDP-MED, IGMP snooping, Multicast filtering function, MVR, automatic device discovery, schedule reboot, VLAN support, IP-MAC binding, 802.1x authentication, AAA, MAB, Guest VLAN, DHCP snooping, DHCPv6 snooping, ARP inspection, ND detection, DoS protection, port isolation, MLD, Cable Diagnostics Function, ZTP |
Compliant Standards | IEEE 802.3af, IEEE 802.3at, IEEE 802.1p, IEEE 802.3x, IEEE 802.1ab (LLDP), IEEE 802.1Q, IEEE 802.1x |
Dimensions (WxDxH) | 20.9 cm x 12.6 cm x 2.6 cm |
Weight | 600 g |
System Requirements | Microsoft Windows 98SE/2000/NT/XP/Vista/7/8, Microsoft Windows 10 / 11, Apple MacOS, Novell NetWare, UNIX, Linux |
Designed For | TP-Link MC200CM, MC210CS, MC220L |
Extended Specifications
General
Device Type | Switch – 8 ports – smart |
|---|---|
Enclosure Type | Desktop, wall-mountable |
Subtype | Gigabit Ethernet |
Ports | 4 x 10/100/1000 + 4 x 10/100/1000 (PoE+) |
Power Over Ethernet (PoE) | PoE+ |
PoE Budget | 62 W |
Performance | Bandwidth: 16 Gbps Packet forwarding rate: 11.90 Mpps Packet buffer size: 4.1 Mbit |
Capacity | Priority queues: 8 IPv4 groups (Multicast): 511 IPv6 groups (Multicast): 511 ACL entries: 230 Layer 2 multicast filtering entries per profile: 16 IP multicast profiles: 256 VLAN groups: 4000 MAC VLAN address entries: 12 IPv6 MAC port binding entries: 512 IPv4 source guard entries: 253 IPv6 source guard entries: 183 MAC addresses per port: 64 |
MAC Address Table Size | 8K entries |
Jumbo Frame Support | 9KB |
Routing Protocol | Static IP routing |
Remote Management Protocol | CLI, IPv4, IPv6, HTTPS, SSH, SSH-2, Telnet, HTTP, MIB 2, MIB, RMON 1, RMON 2, RMON 3, RMON 9, SNMP 1, SNMP 2c, SNMP 3, UDP, TCP/IP, BOOTP, TFTP |
Encryption Algorithm | SSL 3.0, TLS 1.2 |
Authentication Method | PAP, EAP-MD5, RADIUS, Secure Shell (SSH), Secure Shell v.2 (SSH2) |
Features | Reset button, fanless, metal housing, auto-negotiation, auto-uplink (auto MDI/MDI-X), security lock slot (cable lock sold separately), QoS, SP, WRR, Broadcast Storm Control, Multicast Storm Control, Unicast Storm Control, Unknown Storm Control, DHCP server, DHCP relay, Link Aggregation, loopback detection, flow control, port mirroring, DLDP support, LLDP-MED, IGMP snooping, Multicast filtering function, MVR, automatic device discovery, schedule reboot, VLAN support, IP-MAC binding, 802.1x authentication, AAA, MAB, Guest VLAN, DHCP snooping, DHCPv6 snooping, ARP inspection, ND detection, DoS protection, port isolation, MLD, Cable Diagnostics Function, ZTP |
Compliant Standards | IEEE 802.3af, IEEE 802.3at, IEEE 802.1p, IEEE 802.3x, IEEE 802.1ab (LLDP), IEEE 802.1Q, IEEE 802.1x |
RAM | 256 MB |
Flash Memory | 32 MB |
Status Indicators | PoE activity, PoE max, power, system, link/activity/speed |
Expansion / Connectivity
Interfaces | 4 x 1000Base-T RJ-45 4 x 1000Base-T RJ-45 PoE+ – 30 W |
|---|
Power
Power Device | External power adapter |
|---|---|
Power Provided | DC 53.5 V – 1.31 A |
Miscellaneous
Included Accessories | Rubber feet, power cord |
|---|---|
Compliant Standards | FCC, RoHS |
Software / System Requirements
OS Required | Microsoft Windows 98SE/2000/NT/XP/Vista/7/8, Microsoft Windows 10 / 11, Apple MacOS, Novell NetWare, UNIX, Linux |
|---|
Dimensions & Weight
Width | 20.9 cm |
|---|---|
Depth | 12.6 cm |
Height | 2.6 cm |
Weight | 600 g |
Environmental Parameters
Min Operating Temperature | -5 °C |
|---|---|
Max Operating Temperature | 40 °C |
Humidity Range Operating | 10 – 90% RH (non-condensing) |
Min Storage Temperature | -40 °C |
Max Storage Temperature | 70 °C |
Humidity Range Storage | 5 – 90% RH (non-condensing) |
Compatibility Information
Designed For | TP-Link MC200CM, MC210CS, MC220L |
|---|
