Description
HP EliteDesk Series desktops provide businesses with powerful, expandable, highly secure, and reliable PCs designed for power users.
The HP Elite Mini 800 Desktop PC delivers the high-performance needed to develop complex presentations, crunch big numbers, and quickly create compelling content. Equipped with a powerful Intel processor, responsive graphics, and smart deployment options, this is the right PC for big jobs done in small spaces.
- Small size. Big impact. Get breakthrough performance with the latest Intel processor and DDR5 memory.
- Office and home deployment. Take the HP Elite Mini 800 home with you so you can stay productive in the hybrid work world.
- Protected by HP Wolf Security. HP Wolf Security for Business creates a hardware-enforced, always-on, resilient defense.
- Help protect our shared future. At least 45 percent of all plastic used in this PC is post-consumer recycled plastic.
- HP recommends Windows 11 Pro for business
Work anywhere without compromising on performance with Windows 11 and HP collaboration, security, and connectivity technology. Summarize and rewrite content, get relevant content recommendations, and stay organized with Microsoft Copilot. - Powerful Intel processor
Help speed up demanding business applications with the latest generation Intel Core processors. - Fast and efficient wireless LAN
The portability of your PC and the reliability of a fast connection determines where you can work. Get a fast and reliable connection in dense wireless environments with gigabit-speed Wi-Fi 6. - HP Sure Sense
Malware is evolving rapidly beyond traditional antivirus capabilities. Protect your PC against never-before-seen attacks with HP Sure Sense, which combines behavioral analysis with advanced AI techniques to provide exceptional protection. - Protect critical security processes
Keep your critical applications and processes running even if malware tries to shut them down with the self-healing protection of HP Sure Run. - Browse confidently
Help protect your PC from websites and read only Microsoft Office and PDF attachments with embedded malware, ransomware, or viruses with hardware-enforced security from HP Sure Click.
Main Specifications
Product Description | HP Elite 800 G9 – mini desktop Core i7 i7-14700T 1.3 GHz – vPro Enterprise – 16 GB – SSD 512 GB |
Type | Personal computer – mini desktop |
Platform Technology | Intel vPro Enterprise |
Processor | Intel Core i7 (14th Gen) i7-14700T / 1.3 GHz (up to 5.2 GHz, (20-core) |
Processor Main Features | Intel Turbo Boost Technology 2, Hyper-Threading Technology, Intel Turbo Boost Max 3.0, Intel Smart Cache, 28 Threads |
Cache Memory | 33 MB L3 Cache |
Cache Per Processor | 33 MB |
RAM | 16 GB (installed) / 64 GB (max) – DDR5 SDRAM |
Storage Controller | SATA/NVMe (SATA-600 / NVMe) |
Hard Drive | SSD 512 GB – PCI Express – M.2 – NVM Express (NVMe) |
Optical Storage | No optical drive |
Graphics Controller | Intel UHD Graphics 770 Dynamic Video Memory Technology |
Audio Output | Stereo |
Networking | 1GbE, 802.11a, 802.11b/g/n, Wi-Fi 5, Wi-Fi 6E, Bluetooth 5.3 |
Power | (50/60 Hz) |
OS Provided | Windows 11 Pro |
Software Included | HP Support Assistant, HP PC Hardware Diagnostics UEFI, Microsoft 365 (Trial), HP Secure Erase, HP Setup Integrated OOBE, HP Notifications, HP Connection Optimizer, HP Sure Click, HP Privacy Settings, HP Cloud Recovery, HP Sure Sense, HP Sure Admin, HP QuickDrop, HP BIOSphere Gen6, HP DriveLock, myHP, HP Desktop Support Utilities, HP Client Security Manager Gen7, HP Sure Start Gen7, HP Touchpoint Customizer, HP Easy Clean, HP Smart Support, HP Connect for Microsoft Endpoint Manager, HP SureRun Gen5, HP Sure Recover Gen5, HP Wolf Security for Business, HP UEFI BIOS Certification level 2.7B |
Colour | Jack black |
Dimensions (WxDxH) | 17.7 cm x 17.5 cm x 3.4 cm |
Weight | 1.42 kg |
Environmental Standards | ENERGY STAR Qualified |
Documents
Extended Specifications
General
Platform Technology | Intel vPro Enterprise |
|---|
Type | Personal computer |
|---|
Product Form Factor | Mini desktop |
|---|
Built-in Devices | Speaker |
|---|
Sensors | HP Tamper Lock |
|---|
Embedded Security | Trusted Platform Module (TPM 2.0) Security Chip |
|---|
Colour | Jack black |
|---|
Processor / Chipset
CPU | Intel Core i7 (14th Gen) i7-14700T |
|---|
Clock Speed | 1.3 GHz (P-core) / 900 MHz (E-core) |
|---|
Max Turbo Speed | 5.2 GHz (P-core) / 3.7 GHz (E-core) |
|---|
Number of Cores | 20-core |
|---|
CPU Qty | 1 |
|---|
Max CPU Qty | 1 |
|---|
L2 cache | 28 MB |
|---|
CPU Upgradability | Upgradable |
|---|
Processor Main Features | Intel Turbo Boost Technology 2, Hyper-Threading Technology, Intel Turbo Boost Max 3.0, Intel Smart Cache, 28 Threads |
|---|
Chipset Type | Intel Q670 |
|---|
Cache Memory
Installed Size | L3 Cache – 33 MB |
|---|
Cache Per Processor | 33 MB |
|---|
RAM
Installed Size | 16 GB (installed) / 64 GB (max) |
|---|
Technology | DDR5 SDRAM |
|---|
Effective Memory Speed | 5600 MT/s |
|---|
Rated Memory Speed | 5600 MT/s |
|---|
Form Factor | SO-DIMM 262-pin |
|---|
Slots | 2 (Total) / 1 (empty) |
|---|
Configuration Features | 1 x 16 GB |
|---|
Hard Drive
Type | SSD – M.2 |
|---|
Capacity | 1 x 512 GB |
|---|
Interface Type | PCI Express |
|---|
Features | NVM Express (NVMe) |
|---|
Storage Controller
Type | 1 x SATA/NVMe |
|---|
Controller Interface Type | SATA-600 / NVMe |
|---|
Optical Storage
Monitor
Graphics Controller
Graphics Processor | Intel UHD Graphics 770 Dynamic Video Memory Technology |
|---|
Video Interfaces | DisplayPort, HDMI |
|---|
HDCP Compatible | Yes |
|---|
Audio Output
Sound Output Mode | Stereo |
|---|
Max Sampling Rate | 192 kHz |
|---|
Compliant Standards | High Definition Audio |
|---|
Input Device
Keyboard
Mouse
Networking
Ethernet Controller | Intel I219-LM |
|---|
Wireless LAN Supported | Yes |
|---|
Wireless NIC | Intel Wi-Fi 6E AX 211 |
|---|
Data Link Protocol | Ethernet, Fast Ethernet, Gigabit Ethernet, IEEE 802.11a, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.11ac, IEEE 802.11ax (Wi-Fi 6E), Bluetooth 5.3 |
|---|
Remote Management Protocol | SNMP 2 |
|---|
Features | ACPI support, auto-uplink (auto MDI/MDI-X), dual stream (2×2), MU-MIMO Support, PXE 2.1 support, Wake on LAN (WoL) |
|---|
Compliant Standards | IEEE 802.3, IEEE 802.3u, IEEE 802.3i, IEEE 802.1Q, IEEE 802.3ab, IEEE 802.1p, IEEE 802.3x, IEEE 802.11d, IEEE 802.1x, IEEE 802.11i, Wi-Fi CERTIFIED, IEEE 802.11h, IEEE 802.11e, IEEE 802.11k, IEEE 802.3az, IEEE 802.11r, IEEE 802.11v |
|---|
Expansion / Connectivity
Bays | 1 (total) / 1 (free) x internal 2.5″ |
|---|
Slots | 1 (total) / 0 (free) x M.2 Card – 2230 (for wireless module)
2 (total) / 1 (free) x M.2 Card – 2280 (for internal storage) |
|---|
Interfaces | 1 x USB-C 3.2 Gen 2×2 (1 in front) (charging)
5 x USB 3.2 Gen 2 (2 front, 3 rear) (two of them with wake functionality, one of them is charging)
1 x headphones/microphone (CTIA and OMTP headset support)
2 x DisplayPort 1.4a
1 x HDMI
1 x LAN (Gigabit Ethernet) |
|---|
Miscellaneous
Theft/Intrusion Protection | Security lock slot (cable lock sold separately), chassis intrusion sensor, retractable padlock loop |
|---|
Security Slot Type | Kensington security slot |
|---|
Compliant Standards | FCC Class B certified, ICES-003, CCC, FIPS 140-2 Level 2, RoHS, UL 60950-1, CSA C22.2 No. 60950-1-07, WEEE, KCC Class B, Common Criteria EAL4+, CECP, VCCI Class B, SEPA, low halogen, UL 62368-1, CAN/CSA-C22.2 No. 62368-1-14, IEEE 1680.1 |
|---|
Power
Device Type | Power adapter |
|---|
Voltage Required | AC 90-264 V (50/60 Hz) |
|---|
Power Provided | 90 Watt |
|---|
Efficiency | 89% (230VAC), 88% (115VAC) |
|---|
Power Factor Correction | Yes (active) |
|---|
Operating System / Software
OS Provided | Windows 11 Pro |
|---|
Software | HP Support Assistant, HP PC Hardware Diagnostics UEFI, Microsoft 365 (Trial), HP Secure Erase, HP Setup Integrated OOBE, HP Notifications, HP Connection Optimizer, HP Sure Click, HP Privacy Settings, HP Cloud Recovery, HP Sure Sense, HP Sure Admin, HP QuickDrop, HP BIOSphere Gen6, HP DriveLock, myHP, HP Desktop Support Utilities, HP Client Security Manager Gen7, HP Sure Start Gen7, HP Touchpoint Customizer, HP Easy Clean, HP Smart Support, HP Connect for Microsoft Endpoint Manager, HP SureRun Gen5, HP Sure Recover Gen5, HP Wolf Security for Business, HP UEFI BIOS Certification level 2.7B |
|---|
Sustainability Information
Dimensions & Weight
Width | 17.7 cm |
|---|
Depth | 17.5 cm |
|---|
Height | 3.4 cm |
|---|
Weight | 1.42 kg |
|---|
Dimensions & Weight (Shipping)
Shipping Width | 49.8 cm |
|---|
Shipping Depth | 13.2 cm |
|---|
Shipping Height | 23.5 cm |
|---|
Shipping Weight | 2.95 kg |
|---|
Environmental Parameters
Min Operating Temperature | 10 °C |
|---|
Max Operating Temperature | 35 °C |
|---|
Humidity Range Operating | 10 – 90% RH (non-condensing) |
|---|
