Description
The Cisco Meraki MR74 is a four-radio, cloud-managed 2×2 MIMO 802.11ac Wave 2 access point. Designed for general purpose, next-generation deployments in harsh outdoor locations and industrial indoor conditions, the MR74 offers performance, enterprise-grade security, and intuitive management.
A dedicated third radio provides real-time WIDS/WIPS with automated RF optimization. In addition, an integrated fourth radio delivers Bluetooth Low Energy (BLE) scanning and Beaconing functionality. The MR74 is 100% cloud-managed via the intuitive, browser-based Meraki Dashboard, and includes a rich, out-of-the-box feature set without additional cost or complexity.
With a ruggedized enclosure, an IP67 rating, and extended operating temperature range, the MR74 is designed for general purpose next-generation deployments.
- Ruggedized design suitable for outdoor use
- Supports high-speed 802.11a/b/g/n/ac Wave 2 standards
- Multiple encryption and authentication methods for enhanced security
- Incorporates MU-MIMO and beamforming for efficient network performance
- PoE support for flexible deployment and energy efficiency
- Robust design
Engineered for the outdoors, the Cisco Meraki MR74 Cloud Managed features a ruggedized design that withstands extreme environmental conditions, making it ideal for outdoor deployment. - Enhanced connectivity
With dual-band operation in 2.4 GHz and 5 GHz frequencies and support for 802.11a/b/g/n/ac Wave 2 standards, this wireless access point ensures high-speed connectivity and improved user experience. - Advanced security
The device offers multiple encryption algorithms including AES, TKIP, WPA, and WPA2, alongside a comprehensive suite of authentication methods, ensuring a secure and reliable wireless network environment. - Efficient performance
Features such as MU-MIMO and beamforming technology enable the MR74 to provide high-capacity, efficient wireless connections, optimizing performance for all connected devices. - Power and flexibility
Support for Power over Ethernet (PoE) allows for flexible installation locations and minimal cabling, while the device’s low power consumption of 11 W ensures energy efficiency.
Main Specifications
Product Description | Cisco Meraki MR74 Cloud Managed – radio access point – Bluetooth, Wi-Fi 5 |
Device Type | Radio access point |
Form Factor | External – outdoor |
Data Link Protocol | IEEE 802.11b, IEEE 802.11a, IEEE 802.11g, IEEE 802.11n, Bluetooth 4.0, IEEE 802.11ac Wave 2 |
Frequency Band | 2.4 GHz, 5 GHz |
Power Over Ethernet (PoE) Supported | PoE |
Dimensions (WxDxH) | 25.6 cm x 6.5 cm x 15.8 cm |
Weight | 1.09 kg |
Extended Specifications
General
Device Type | Radio access point |
|---|
Ruggedized Design | Outdoor |
|---|
Width | 25.6 cm |
|---|
Depth | 6.5 cm |
|---|
Height | 15.8 cm |
|---|
Weight | 1.09 kg |
|---|
Networking
Form Factor | External |
|---|
Connectivity Technology | Wireless |
|---|
Data Transfer Rate | 1.3 Gbps |
|---|
Line Coding Format | 256 QAM |
|---|
Data Link Protocol | IEEE 802.11b, IEEE 802.11a, IEEE 802.11g, IEEE 802.11n, Bluetooth 4.0, IEEE 802.11ac Wave 2 |
|---|
Network / Transport Protocol | IPSec |
|---|
Frequency Band | 2.4 GHz, 5 GHz |
|---|
Status Indicators | Status |
|---|
Features | Wireless Intrusion Detection System (WIDS), Quality of Service (QoS), 2T2R MIMO technology, Maximum Ratio Combining (MRC), Wireless Intrusion Prevention System (WIPS), 802.1x authentication, DiffServ Code Point (DSCP) support, MU-MIMO technology, Bluetooth Low Energy Beaconing, Unscheduled Automatic Power Save Delivery (U-APSD), beamforming technology, SU-MIMO technology |
|---|
Encryption Algorithm | AES, TLS, TTLS, TKIP, WPA, WPA2-PSK, WPA2-Enterprise, WEP |
|---|
Authentication Method | Radio Service Set ID (SSID), MS-CHAP v.2, Extensible Authentication Protocol (EAP), EAP-SIM |
|---|
Compliant Standards | IEEE 802.1Q, IEEE 802.1p, IEEE 802.11b, IEEE 802.11a, IEEE 802.3af, IEEE 802.11g, IEEE 802.1x, IEEE 802.11n, IEEE 802.11r, IEEE 802.11ac Wave 2 |
|---|
Expansion / Connectivity
Interfaces | 1 x 1000Base-T (PoE) – RJ-45
4 x aerial – N connector |
|---|
Miscellaneous
Compliant Standards | Plug and Play, IP67 |
|---|
Power
Power Over Ethernet (PoE) Supported | PoE |
|---|
Power Consumption Operational | 11 watt |
|---|
Environmental Parameters
Min Operating Temperature | -40 °C |
|---|
Max Operating Temperature | 55 °C |
|---|
