Description
The HPE ProLiant DL340 Gen12 is designed for performance and reliability in demanding environments. With a rack-mountable form factor, it fits seamlessly into standard racks, maximizing space efficiency. The server’s hot-swap storage bays allow for quick maintenance, ensuring minimal downtime during upgrades and repairs.
Equipped with features such as Intel Xeon processors and DDR5 SDRAM memory, the DL340 Gen12 supports enhanced processing capabilities and memory efficiency. The integrated HPE iLO provides effective remote management, enhancing operational flexibility while ensuring secure access to critical systems from anywhere. Built to operate in a wide range of environmental conditions, this server maintains performance even in high-demand settings.
- Rack-mountable design saves space in server rooms
- Hot-swap storage bays simplify maintenance
- Supports Intel Xeon processors for robust performance
- HPE iLO integration enables remote management capabilities
- Operates efficiently in a broad temperature and humidity range
- Versatile storage capabilities
The HPE ProLiant DL340 Gen12 features hot-swap server storage bays, allowing for rapid replacement and addition of drives without downtime, ensuring business continuity during updates. - Robust processing power
With Intel Xeon processors, this server delivers high performance and efficiency, making it suitable for various applications in demanding environments. - Comprehensive remote management
Integrated Lights-Out 7 technology allows for effective remote control and monitoring of server systems, facilitating quick troubleshooting and maintenance from any location. - Enhanced stability in various conditions
Designed to operate within 10°C to 35°C and a humidity range of 8 to 90% RH, it supports stable performance in diverse environmental conditions without compromising reliability. - Secure embedded features
The Trusted Platform Module (TPM 2.0) security chip enhances data protection, providing a secure foundation for the server and ensuring compliance with standards.
Main Specifications
Product Description | HPE ProLiant Compute DL340 Gen12 – rack-mountable Xeon 6505P 2.2 GHz – 32 GB – SSD 2 x 480 GB |
Type | Server – rack-mountable |
Height (Rack Units) | 2U |
Server Scalability | 1-way |
Processor | 1 x Intel Xeon 6505P / 2.2 GHz (up to 4.1 GHz, (12-core) |
Processor Main Features | Intel Turbo Boost Technology 2, Hyper-Threading Technology, 24 Threads, 150W TDP |
Cache Memory | 48 MB L3 Cache |
Cache Per Processor | 48 MB |
RAM | 32 GB (installed) / 4 TB (max) – DDR5 SDRAM |
Storage Controller | RAID (Serial ATA-600 / SAS 3.0 / PCI Express (NVMe)) – OCP 3.0 (HPE MR408i-o Gen11 SPDM) |
Server Storage Bays | Hot-swap 2.5″ |
Hard Drive | 2 x SSD 480 GB |
Optical Storage | No optical drive |
Video Memory | 16 MB |
Power Redundancy | Yes |
Dimensions (WxDxH) | 44.8 cm x 63.95 cm x 8.75 cm |
Weight | 17.6 kg |
Extended Specifications
General
Type | Server |
|---|
Product Form Factor | Rack-mountable – 2U |
|---|
Built-in Devices | Led panel |
|---|
Embedded Security | Trusted Platform Module (TPM 2.0) Security Chip |
|---|
Server Scalability | 1-way |
|---|
Hot-Swap Bays Qty | 8 |
|---|
Processor / Chipset
CPU | Intel Xeon 6505P |
|---|
Clock Speed | 2.2 GHz |
|---|
Max Turbo Speed | 4.1 GHz |
|---|
Number of Cores | 12-core |
|---|
CPU Qty | 1 |
|---|
Max CPU Qty | 1 |
|---|
CPU Upgradability | Upgradable |
|---|
Processor Main Features | Intel Turbo Boost Technology 2, Hyper-Threading Technology, 24 Threads, 150W TDP |
|---|
Cache Memory
Installed Size | L3 Cache – 48 MB |
|---|
Cache Per Processor | 48 MB |
|---|
RAM
Installed Size | 32 GB (installed) / 4 TB (max) |
|---|
Technology | DDR5 SDRAM |
|---|
Form Factor | DIMM 288-pin |
|---|
Slots | 16 (Total) / 15 (empty) |
|---|
Features | HPE SmartMemory, registered |
|---|
Configuration Features | 1 x 32 GB |
|---|
Hard Drive
Type | SSD |
|---|
Capacity | 2 x 480 GB |
|---|
Storage Controller
Type | 1 x RAID – OCP 3.0 |
|---|
Controller Interface Type | Serial ATA-600 / SAS 3.0 / PCI Express (NVMe) |
|---|
Storage Controller Name | HPE MR408i-o Gen11 SPDM |
|---|
Channel Qty | 8 |
|---|
RAID Level | RAID 0, RAID 1, RAID 5, RAID 6, RAID 10, RAID 50, RAID 60 |
|---|
Buffer Size | 4 GB |
|---|
Optical Storage
Monitor
Graphics Controller
Video Memory | 16 MB |
|---|
Video Interfaces | VGA |
|---|
Networking
Remote Management Controller | Integrated Lights-Out 7 |
|---|
Expansion / Connectivity
Bays | 8 (total) / 6 (free) x hot-swap 2.5″ SFF |
|---|
Slots | 3 (total) / 3 (free) x PCIe 5.0 x16
1 (total) / 0 (free) x Open Compute Project mezzanine (OCP) 3.0 (slot A) |
|---|
Interfaces | 1 x HPE iLO – Type C (1 in front) (service port)
1 x management (Gigabit Ethernet) – RJ-45 (1 front) (HPE iLO Service Port)
4 x USB 3.2 Gen 1 – Type A (1 front, 2 rear, 1 internal)
1 x VGA (1 rear) |
|---|
Miscellaneous
Compliant Standards | ACPI 6.4, Energy Star, SMBIOS 3.4, Redfish API, AES, Triple DES, TLS v1.2, Active Directory v1.0, ASHRAE Class A3, ASHRAE Class A4 |
|---|
Power
Device Type | Power supply – hot-plug |
|---|
Power Redundancy | Yes |
|---|
Power Redundancy Scheme | 1+1 |
|---|
Installed Qty | 2 |
|---|
Max Supported Qty | 2 |
|---|
Power Provided | 1000 Watt |
|---|
80 PLUS Certification | 80 PLUS Titanium |
|---|
Dimensions & Weight
Width | 44.8 cm |
|---|
Depth | 63.95 cm |
|---|
Height | 8.75 cm |
|---|
Weight | 17.6 kg |
|---|
Environmental Parameters
Min Operating Temperature | 10 °C |
|---|
Max Operating Temperature | 35 °C |
|---|
Humidity Range Operating | 8 – 90% RH (non-condensing) |
|---|
