Description
The Minix Z100-AERO is an ultra small form factor mini PC designed to fit seamlessly into any workspace. With a powerful quad-core Intel N100 processor, it offers clock speeds up to 3.4 GHz, ensuring smooth performance for both personal and professional tasks. Equipped with 16 GB DDR4 RAM and a 512 GB PCI Express NVMe SSD, this mini PC provides ample storage and fast data access, perfect for multitasking or handling large files. The diverse connectivity options include four USB 3.2 ports, Ethernet support with two LAN ports, and wireless capabilities featuring Intel Wireless-AC 9560 and Bluetooth 5.1, making it a versatile choice for various networking needs. Experience a compact yet powerful computing solution ideal for modern users who value efficiency and style.
- Compact mini PC with ultra small form factor
- Intel N-series quad-core processor with max turbo speed of 3.4 GHz
- 512 GB PCI Express NVMe SSD for high-speed data access
- Multiple connectivity options including USB 3.2 and Ethernet
- Supports wireless connectivity with Intel Wireless-AC and Bluetooth 5.1
- Efficient processing power
The Intel N100 quad-core processor delivers efficient performance with a base clock speed of 0.8 GHz and a maximum turbo speed of 3.4 GHz, suitable for a range of tasks from basic computing to more demanding applications. - Ample storage capacity
Featuring a 512 GB SSD with PCI Express interface, the Z100-AERO provides significant storage space along with rapid boot and data retrieval times, enhancing overall system responsiveness. - Versatile connectivity options
Equipped with four USB 3.2 ports, a USB-C 3.2 port, HDMI, and DisplayPort, this mini PC supports various peripherals and display configurations for added flexibility. - Advanced wireless capabilities
Supported by Intel Wireless-AC 9560, users can enjoy high-speed wireless networking with compatibility across multiple Wi-Fi protocols and Bluetooth 5.1 for seamless device pairing. - Compact design
The ultra small form factor allows the Minix Z100-AERO to occupy minimal desk space, making it ideal for office environments or home setups where space is a premium.
Main Specifications
Product Description | MiniX Z100-AERO – mini PC N-series N100 0.8 GHz – 16 GB – SSD 512 GB |
Type | Personal computer – mini PC |
Processor | Intel N-series N100 / 0.8 GHz (up to 3.4 GHz, (Quad-Core) |
Cache Memory | 6 MB |
Cache Per Processor | 6 MB |
RAM | 16 GB (installed) / 32 GB (max) – DDR4 SDRAM |
Hard Drive | SSD 512 GB – PCI Express 3.0 x4 (NVMe) – M.2 |
Optical Storage | No optical drive |
Graphics Controller | Intel UHD Graphics |
Networking | 802.11a, Wi-Fi 5, 802.11b/g/n, Bluetooth 5.1, 1GbE, 2.5GbE |
OS Provided | Windows 11 Pro |
Dimensions (WxDxH) | 12.7 cm x 12.7 cm x 4.3 cm |
Extended Specifications
General
Type | Personal computer |
|---|
Product Form Factor | Mini PC |
|---|
Processor / Chipset
CPU | Intel N-series N100 |
|---|
Clock Speed | 0.8 GHz |
|---|
Max Turbo Speed | 3.4 GHz |
|---|
Number of Cores | Quad-Core |
|---|
CPU Qty | 1 |
|---|
Max CPU Qty | 1 |
|---|
Cache Memory
Installed Size | 6 MB |
|---|
Cache Per Processor | 6 MB |
|---|
RAM
Installed Size | 16 GB (installed) / 32 GB (max) |
|---|
Technology | DDR4 SDRAM |
|---|
Effective Memory Speed | 3200 MHz |
|---|
Rated Memory Speed | 3200 MHz |
|---|
Form Factor | SO-DIMM 260-pin |
|---|
Slots | 1 (Total) / 0 (empty) |
|---|
Hard Drive
Type | SSD – M.2 |
|---|
Capacity | 1 x 512 GB |
|---|
Interface Type | PCI Express 3.0 x4 (NVMe) |
|---|
Optical Storage
Monitor
Graphics Controller
Graphics Processor | Intel UHD Graphics |
|---|
Video Interfaces | HDMI, USB-C, DisplayPort |
|---|
Networking
Ethernet Ports | 1 x 2.5 Gigabit Ethernet, 1 x Gigabit Ethernet |
|---|
Wireless LAN Supported | Yes |
|---|
Wireless NIC | Intel Wireless-AC 9560 |
|---|
Data Link Protocol | IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, Bluetooth 5.1, Ethernet, Fast Ethernet, Gigabit Ethernet, 2.5 Gigabit Ethernet |
|---|
Expansion / Connectivity
Interfaces | 4 x USB 3.2 Gen 1 – Type A (2 front, 2 rear)
1 x USB-C 3.2 Gen 2/DisplayPort – Type C (1 front)
1 x LAN (Gigabit Ethernet) – RJ-45 (1 rear)
1 x LAN (2.5Gigabit Ethernet) – RJ-45 (1 rear)
1 x headphones/microphone – mini-jack (1 front)
1 x DisplayPort (1 rear) |
|---|
Miscellaneous
Power
Device Type | Power adapter |
|---|
Voltage Required | DC 12 V |
|---|
Operating System / Software
OS Provided | Windows 11 Pro |
|---|
Dimensions & Weight
Width | 12.7 cm |
|---|
Depth | 12.7 cm |
|---|
Height | 4.3 cm |
|---|
